DHT11?Learn Temperature Humidity with DHT11 with micropython

Hi~ I'm irina but My nickname is "Y"

When we think of temperature/humidity sensors in IoT, DHT-11 comes to mind the most. So today, I would like to introduce the working principle of DHT11 to the source code.​

STEP 1. What is DHT11?

If you look for it, surprisingly, it is a temperature/humidity sensor that is often used when you want to check the temperature and humidity of products specialized for IoT such as Arduino or Raspberry Pi.

humidity : 20~95%

temperature: 0~50ºC

As explained in the figure, the pins are in order from left to right.

VCC,Signal, NC, GND

​

NC is an unused pin, so only 3 pins are actually used.

When using the above product, a normal value is output only when a resistor (5K) is connected between VCC and Signal.

If there is no resistor, you can also use a module.

Since the module already has a resistor connected to the signal, the wiring is simple and easy to use.

​

STEP 2. Operation Principle

​When I first dealt with it, I didn't even know how it works and didn't write it.

As I write it, I wonder what kind of principle it is,

​

There are two types of electrical humidity measurement methods: capacitance sensing type nd resistance sensing type, but the capacitive sensing type sensor has high precision but is expensive.

So DHT11 uses resistance sensing type.

The two electrodes are not connected to each other, but a small amount of current flows due to the moisture in the air. So, when there is more moisture in the air, more current flows, so the resulting resistance value is measured as humidity.

​

​In the temperature measurement of DHT11, the resistance value of the material changes according to the temperature, and a temperature sensor called thermistor is included in the DHT11 and is used together with the humidity sensor!

STEP 3. Source code

Next, This code is micropython of DHT11.​

Depending on the version of micropython, the corresponding code may be built-in.

If there is no error when "import DHT" enter to the code that is actually executed, you do not need to use the DHT code below.

import array

import micropython
import utime
from machine import Pin
from micropython import const


class InvalidChecksum(Exception):
    pass


class InvalidPulseCount(Exception):
    pass


MAX_UNCHANGED = const(100)
MIN_INTERVAL_US = const(200000)
HIGH_LEVEL = const(50)
EXPECTED_PULSES = const(84)


class DHT11:
    _temperature: float
    _humidity: float

    def __init__(self, pin):
        self._pin = pin
        self._last_measure = utime.ticks_us()
        self._temperature = -1
        self._humidity = -1

    def measure(self):
        current_ticks = utime.ticks_us()
        if utime.ticks_diff(current_ticks, self._last_measure) < MIN_INTERVAL_US and (
            self._temperature > -1 or self._humidity > -1
        ):
            # Less than a second since last read, which is too soon according
            # to the datasheet
            return

        self._send_init_signal()
        pulses = self._capture_pulses()
        buffer = self._convert_pulses_to_buffer(pulses)
        self._verify_checksum(buffer)

        self._humidity = buffer[0] + buffer[1] / 10
        self._temperature = buffer[2] + buffer[3] / 10
        self._last_measure = utime.ticks_us()

    @property
    def humidity(self):
        self.measure()
        return self._humidity

    @property
    def temperature(self):
        self.measure()
        return self._temperature

    def _send_init_signal(self):
        self._pin.init(Pin.OUT, Pin.PULL_DOWN)
        self._pin.value(1)
        utime.sleep_ms(50)
        self._pin.value(0)
        utime.sleep_ms(18)

    @micropython.native
    def _capture_pulses(self):
        pin = self._pin
        pin.init(Pin.IN, Pin.PULL_UP)

        val = 1
        idx = 0
        transitions = bytearray(EXPECTED_PULSES)
        unchanged = 0
        timestamp = utime.ticks_us()

        while unchanged < MAX_UNCHANGED:
            if val != pin.value():
                if idx >= EXPECTED_PULSES:
                    raise InvalidPulseCount(
                        "Got more than {} pulses".format(EXPECTED_PULSES)
                    )
                now = utime.ticks_us()
                transitions[idx] = now - timestamp
                timestamp = now
                idx += 1

                val = 1 - val
                unchanged = 0
            else:
                unchanged += 1
        pin.init(Pin.OUT, Pin.PULL_DOWN)
        if idx != EXPECTED_PULSES:
            raise InvalidPulseCount(
                "Expected {} but got {} pulses".format(EXPECTED_PULSES, idx)
            )
        return transitions[4:]

    def _convert_pulses_to_buffer(self, pulses):
        """Convert a list of 80 pulses into a 5 byte buffer

        The resulting 5 bytes in the buffer will be:
            0: Integral relative humidity data
            1: Decimal relative humidity data
            2: Integral temperature data
            3: Decimal temperature data
            4: Checksum
        """
        # Convert the pulses to 40 bits
        binary = 0
        for idx in range(0, len(pulses), 2):
            binary = binary << 1 | int(pulses[idx] > HIGH_LEVEL)

        # Split into 5 bytes
        buffer = array.array("B")
        for shift in range(4, -1, -1):
            buffer.append(binary >> shift * 8 & 0xFF)
        return buffer

    def _verify_checksum(self, buffer):
        # Calculate checksum
        checksum = 0
        for buf in buffer[0:4]:
            checksum += buf
        if checksum & 0xFF != buffer[4]:
            raise InvalidChecksum()

STEP 4. Example code

There is no need for the "pin clear" part, but depending on the board, there is a part where the pin is working, so I put it in.

I made it so that the temperature and humidity were well expressed, and I made it print out once every 2 seconds.

from machine import Pin
import time
from dht import DHT11, InvalidChecksum

# Pin Clear
for i in range(0,29):
    led = machine.Pin(i, machine.Pin.OUT)
    led.value(0)
    time.sleep(0.1) # sleep 100ms

sensor = DHT11(Pin(15, Pin.OUT, Pin.PULL_DOWN)) #DHT11 Pin15
while True:
    temp = sensor.temperature
    humidity = sensor.humidity
    print("Temperature: {}°C   Humidity: {:.0f}% ".format(temp, humidity))
    time.sleep(2)

The output is as below...

I am using a tool called Thonny to easily compile and use MicroPython!!

STEP 5. Conclusion
