LCD Game

An Arduino plays with menus and sounds.

BeginnerShowcase (no instructions)36,989
LCD Game

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Jumper wires (generic)
Jumper wires (generic)
×1
Buzzer
Buzzer
×1
Standard LCD - 16x2 White on Blue
Adafruit Standard LCD - 16x2 White on Blue
with YwRobot LCM1602 IIC V1
×1
Pushbutton switch 12mm
SparkFun Pushbutton switch 12mm
×3
YwRobot Arduino LCM1602 IIC V1 conventer
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Code

Game code and scheme

Arduino
Library: https://bitbucket.org/fmalpartida/new-liquidcrystal/downloads/
Sometimes you can find polish words.
// SCHEME
// GND and Pin 3 - Buzzer
// GND and Reset - button
// GND and Pin 4 - button
// GND and Pin 2 - button
// --------DISPLAY---------
// SCL - A5
// SDA - A4
// GND - GND
// VCC - 5V


#include <LiquidCrystal_I2C.h>
volatile int grasw;
volatile int napis;
volatile int podmenu;
#define PIN_BUTTON 2
#define PIN_AUTOPLAY 1
#define PIN_READWRITE 10
#define PIN_CONTRAST 12
#define SPRITE_RUN1 1
#define SPRITE_RUN2 2
#define SPRITE_JUMP 3
#define SPRITE_JUMP_UPPER '.'
#define SPRITE_JUMP_LOWER 4
#define SPRITE_TERRAIN_EMPTY ' '
#define SPRITE_TERRAIN_SOLID 5
#define SPRITE_TERRAIN_SOLID_RIGHT 6
#define SPRITE_TERRAIN_SOLID_LEFT 7
#define HERO_HORIZONTAL_POSITION 1
#define TERRAIN_WIDTH 16
#define TERRAIN_EMPTY 0
#define TERRAIN_LOWER_BLOCK 1
#define TERRAIN_UPPER_BLOCK 2
#define HERO_POSITION_OFF 0
#define HERO_POSITION_RUN_LOWER_1 1
#define HERO_POSITION_RUN_LOWER_2 2
#define HERO_POSITION_JUMP_1 3
#define HERO_POSITION_JUMP_2 4
#define HERO_POSITION_JUMP_3 5
#define HERO_POSITION_JUMP_4 6
#define HERO_POSITION_JUMP_5 7
#define HERO_POSITION_JUMP_6 8
#define HERO_POSITION_JUMP_7 9
#define HERO_POSITION_JUMP_8 10
#define HERO_POSITION_RUN_UPPER_1 11
#define HERO_POSITION_RUN_UPPER_2 12

LiquidCrystal_I2C lcd(0x27, 2, 1, 0, 4, 5, 6, 7, 3, POSITIVE);
static char terrainUpper[TERRAIN_WIDTH + 1];
static char terrainLower[TERRAIN_WIDTH + 1];
static bool buttonPushed = false;
char wybor;
char wyborpoz;


void initializeGraphics(){
  static byte graphics[] = {
    // Run position 1
    B01100,
    B01100,
    B00000,
    B01110,
    B11100,
    B01100,
    B11010,
    B10011,
    // Run position 2
    B01100,
    B01100,
    B00000,
    B01100,
    B01100,
    B01100,
    B01100,
    B01110,
    // Jump
    B01100,
    B01100,
    B00000,
    B11110,
    B01101,
    B11111,
    B10000,
    B00000,
    // Jump lower
    B11110,
    B01101,
    B11111,
    B10000,
    B00000,
    B00000,
    B00000,
    B00000,
    // Ground
    B11111,
    B11111,
    B11111,
    B11111,
    B11111,
    B11111,
    B11111,
    B11111,
    // Ground right
    B00011,
    B00011,
    B00011,
    B00011,
    B00011,
    B00011,
    B00011,
    B00011,
    // Ground left
    B11000,
    B11000,
    B11000,
    B11000,
    B11000,
    B11000,
    B11000,
    B11000,
  };
  int i;


  for (i = 0; i < 7; ++i) {
    lcd.createChar(i + 1, &graphics[i * 8]);
  }
  for (i = 0; i < TERRAIN_WIDTH; ++i) {
    terrainUpper[i] = SPRITE_TERRAIN_EMPTY;
    terrainLower[i] = SPRITE_TERRAIN_EMPTY;
  }
}

void advanceTerrain(char* terrain, byte newTerrain){
  for (int i = 0; i < TERRAIN_WIDTH; ++i) {
    char current = terrain[i];
    char next = (i == TERRAIN_WIDTH-1) ? newTerrain : terrain[i+1];
    switch (current){
      case SPRITE_TERRAIN_EMPTY:
        terrain[i] = (next == SPRITE_TERRAIN_SOLID) ? SPRITE_TERRAIN_SOLID_RIGHT : SPRITE_TERRAIN_EMPTY;
        break;
      case SPRITE_TERRAIN_SOLID:
        terrain[i] = (next == SPRITE_TERRAIN_EMPTY) ? SPRITE_TERRAIN_SOLID_LEFT : SPRITE_TERRAIN_SOLID;
        break;
      case SPRITE_TERRAIN_SOLID_RIGHT:
        terrain[i] = SPRITE_TERRAIN_SOLID;
        break;
      case SPRITE_TERRAIN_SOLID_LEFT:
        terrain[i] = SPRITE_TERRAIN_EMPTY;
        break;
    }
  }
}
void gl (int czas, int glos){

tone(3, glos);
delay(czas);
noTone(3);
}


bool drawHero(byte position, char* terrainUpper, char* terrainLower, unsigned int score) {
  bool collide = false;
  char upperSave = terrainUpper[HERO_HORIZONTAL_POSITION];
  char lowerSave = terrainLower[HERO_HORIZONTAL_POSITION];
  byte upper, lower;
  switch (position) {
    case HERO_POSITION_OFF:
      upper = lower = SPRITE_TERRAIN_EMPTY;
      break;
    case HERO_POSITION_RUN_LOWER_1:
      upper = SPRITE_TERRAIN_EMPTY;
      lower = SPRITE_RUN1;
      break;
    case HERO_POSITION_RUN_LOWER_2:
      upper = SPRITE_TERRAIN_EMPTY;
      lower = SPRITE_RUN2;
      break;
    case HERO_POSITION_JUMP_1:
    case HERO_POSITION_JUMP_8:
      upper = SPRITE_TERRAIN_EMPTY;
      lower = SPRITE_JUMP;
      break;
    case HERO_POSITION_JUMP_2:
    case HERO_POSITION_JUMP_7:
      upper = SPRITE_JUMP_UPPER;
      lower = SPRITE_JUMP_LOWER;
      break;
    case HERO_POSITION_JUMP_3:
    case HERO_POSITION_JUMP_4:
    case HERO_POSITION_JUMP_5:
    case HERO_POSITION_JUMP_6:
      upper = SPRITE_JUMP;
      lower = SPRITE_TERRAIN_EMPTY;
      break;
    case HERO_POSITION_RUN_UPPER_1:
      upper = SPRITE_RUN1;
      lower = SPRITE_TERRAIN_EMPTY;
      break;
    case HERO_POSITION_RUN_UPPER_2:
      upper = SPRITE_RUN2;
      lower = SPRITE_TERRAIN_EMPTY;
      break;
  }
  if (upper != ' ') {
    terrainUpper[HERO_HORIZONTAL_POSITION] = upper;
    collide = (upperSave == SPRITE_TERRAIN_EMPTY) ? false : true;

  }
  if (lower != ' ') {
    terrainLower[HERO_HORIZONTAL_POSITION] = lower;
    collide |= (lowerSave == SPRITE_TERRAIN_EMPTY) ? false : true;
  }

  byte digits = (score > 9999) ? 5 : (score > 999) ? 4 : (score > 99) ? 3 : (score > 9) ? 2 : 1;

  // Draw the scene
  terrainUpper[TERRAIN_WIDTH] = '\0';
  terrainLower[TERRAIN_WIDTH] = '\0';
  char temp = terrainUpper[16-digits];
  terrainUpper[16-digits] = '\0';
  lcd.setCursor(0,0);
  lcd.print(terrainUpper);
  terrainUpper[16-digits] = temp;
  lcd.setCursor(0,1);
  lcd.print(terrainLower);

  lcd.setCursor(16 - digits,0);
  lcd.print(score);

  terrainUpper[HERO_HORIZONTAL_POSITION] = upperSave;
  terrainLower[HERO_HORIZONTAL_POSITION] = lowerSave;
  return collide;
}

// Handle the button push as an interrupt
void buttonPush() {
  buttonPushed = true;

}

void poczatek(){
  lcd.setCursor(0,0);
  lcd.print("Avoid it");
  lcd.setCursor(2,4);
  lcd.print("And jump");

  gl(100,400);
  gl(100,300);
  gl(100,200);
  gl(100,300);
  gl(100,400);
  gl(100,600);
  delay(1000);
  lcd.clear();

}

void gra(int poziomgry){
  static byte heroPos = HERO_POSITION_RUN_LOWER_1;
  static byte newTerrainType = TERRAIN_EMPTY;
  static byte newTerrainDuration = 1;
  static bool playing = false;
  static bool blink = false;
  static unsigned int distance = 0;
  if (!playing) {
    drawHero((blink) ? HERO_POSITION_OFF : heroPos, terrainUpper, terrainLower, distance >> 3);
    if (blink) {
      lcd.clear();
      lcd.setCursor(0,0);
      lcd.print("Press  JUMP");
    }
    delay(250);
    blink = !blink;
    if (buttonPushed) {
      gl(100,400);
      gl(100,600);
      gl(100,400);
      initializeGraphics();
      heroPos = HERO_POSITION_RUN_LOWER_1;
      playing = true;
      buttonPushed = false;
      distance = 0;

    }
    return;
  }

  // Shift the terrain to the left
  advanceTerrain(terrainLower, newTerrainType == TERRAIN_LOWER_BLOCK ? SPRITE_TERRAIN_SOLID : SPRITE_TERRAIN_EMPTY);
  advanceTerrain(terrainUpper, newTerrainType == TERRAIN_UPPER_BLOCK ? SPRITE_TERRAIN_SOLID : SPRITE_TERRAIN_EMPTY);

  // Make new terrain to enter on the right
  if (--newTerrainDuration == 0) {
    if (newTerrainType == TERRAIN_EMPTY) {
      newTerrainType = (random(3) == 0) ? TERRAIN_UPPER_BLOCK : TERRAIN_LOWER_BLOCK;
      newTerrainDuration = 2 + random(10);
    } else {
      newTerrainType = TERRAIN_EMPTY;
      newTerrainDuration = 10 + random(10);
    }
  }

  if (buttonPushed) {

    if (heroPos <= HERO_POSITION_RUN_LOWER_2)
    gl(100,300);
    heroPos = HERO_POSITION_JUMP_1;
    buttonPushed = false;

  }

  if (drawHero(heroPos, terrainUpper, terrainLower, distance >> 3)) {
    playing = false; // The hero collided with something. Too bad.
    gl(100,500);
    gl(100,400);
    gl(120,300);
    gl(160,400);
    lcd.clear();
  } else {
    if (heroPos == HERO_POSITION_RUN_LOWER_2 || heroPos == HERO_POSITION_JUMP_8) {
      heroPos = HERO_POSITION_RUN_LOWER_1;
    } else if ((heroPos >= HERO_POSITION_JUMP_3 && heroPos <= HERO_POSITION_JUMP_5) && terrainLower[HERO_HORIZONTAL_POSITION] != SPRITE_TERRAIN_EMPTY) {
      heroPos = HERO_POSITION_RUN_UPPER_1;
    } else if (heroPos >= HERO_POSITION_RUN_UPPER_1 && terrainLower[HERO_HORIZONTAL_POSITION] == SPRITE_TERRAIN_EMPTY) {
      heroPos = HERO_POSITION_JUMP_5;
    } else if (heroPos == HERO_POSITION_RUN_UPPER_2) {
      heroPos = HERO_POSITION_RUN_UPPER_1;
    } else {
      ++heroPos;
    }
    ++distance;

    digitalWrite(PIN_AUTOPLAY, terrainLower[HERO_HORIZONTAL_POSITION + 2] == SPRITE_TERRAIN_EMPTY ? HIGH : LOW);
  }
  delay(poziomgry);
  }

void setup(){
  pinMode(4, INPUT_PULLUP);
  pinMode(3, OUTPUT);
  pinMode(PIN_BUTTON, INPUT);
  digitalWrite(PIN_BUTTON, HIGH);
  napis = 1;

  attachInterrupt(0/*PIN_BUTTON*/, buttonPush, FALLING);

  initializeGraphics();

  lcd.begin(16, 2);
   poczatek();
   do{menu();}while(digitalRead(2) == HIGH);


}


void loop() {
switch (grasw) {
case 1:
gra(70);
break;
case 2:
gra(50);
break;
case 3:
gra(15);
break;
case 4:
gra(1);
break;
    }
  }

void menu() {

if (napis > 4 || napis < 0) {napis == 0;}
if (digitalRead(4) == LOW) { napis++;}
  switch (napis) {

    case 1:
    lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<     Easy     >");
  delay(500);
  lcd.clear();
  lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<              >");
  delay(500);
  if(digitalRead(2) == LOW) {
    grasw = 1;
    grasw;}

  break;
    case 2:
lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<    Medium    >");
  delay(500);
  lcd.clear();
  lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<              >");
  delay(500);
if(digitalRead(2) == LOW) {
    grasw = 2;
    grasw;}
    break;

    case 3:
lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<     Hard     >");
  delay(500);
  lcd.clear();
  lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<              >");
  delay(500);
  if(digitalRead(2) == LOW) {
    grasw = 3;
    grasw;}

    break;
    case 4:
lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<  impossible  >");
  delay(500);
  lcd.clear();
  lcd.setCursor(0,0);
  lcd.print("Select mode:");
  lcd.setCursor(0,1);
  lcd.print("<              >");
  delay(500);
  if(digitalRead(2) == LOW) {
    grasw = 4;
    grasw;}
    break;

  default:
napis = 0;
  break;
    }
  }
