555 Timer to Emit Signal to Interrupt Atmega328Untitled

Use 555 timer and Arduino interrupts to save energy in battery powered projects

IntermediateFull instructions provided1,198
555 Timer to Emit Signal to Interrupt Atmega328Untitled

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
555 Timers
555 Timers
×1
Capacitor 100 µF
Capacitor 100 µF
×1
Resistor 221 ohm
Resistor 221 ohm
×1
Resistor 1M ohm
Resistor 1M ohm
×1
Jumper wires (generic)
Jumper wires (generic)
×1
Breadboard (generic)
Breadboard (generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

555 Arduino Interrupt

The scheme in the image is how to wire up the Arduino and the other components

555 Timer interrupt Arduino

This circuit will power up a DTH11 and use a 555 in astable mode to send a interrupt signal to Arduino

Code

555 Arduino Interrupt

Arduino
This code will setup Arduino to power up a DHT11
#include <dht_nonblocking.h>
#include <avr/sleep.h>
#define DHT_SENSOR_TYPE DHT_TYPE_11

static const int DHT_SENSOR_PIN = 7;
DHT_nonblocking dht_sensor( DHT_SENSOR_PIN, DHT_SENSOR_TYPE );

#define interrupPin 2 // pin to receive the interrupt signal
#define DHT_POWER_PIN 6 // this is to power the device using an Arduino pin. That way, the device will go off when Arduino is sleeping

float temperature;
float humidity;

void setup() {
  Serial.begin(9600);
  // put your setup code here, to run once:
  pinMode(DHT_POWER_PIN, OUTPUT);
  pinMode(interrupPin, INPUT_PULLUP);

  //digitalWrite(DHT_POWER_PIN,HIGH);
  set_sleep_mode (SLEEP_MODE_PWR_DOWN);
  Serial.println("All set up");
}

/*
 * Poll for a measurement, keeping the state machine alive.  Returns
 * true if a measurement is available.
 */
static bool measure_environment( float *temperature, float *humidity )
{
  static unsigned long measurement_timestamp = millis( );

  /* Measure once every four seconds. */
  if( millis( ) - measurement_timestamp > 3000ul )
  {
    if( dht_sensor.measure( temperature, humidity ) == true )
    {
      measurement_timestamp = millis( );
      return( true );
    }
  }

  return( false );
}

bool read100TimesOrReady() {
  bool ret = false;
  int i;
  for (i=0; i< 10000; i++) {
    if (measure_environment( &temperature, &humidity ) == true) {
      ret = true;
      break;
    } else {
      i++;
    }
  }
  if(ret == true) {
    Serial.print("Found after ");
    Serial.print(i);
    Serial.println(" attempts");
  }
  return ret;
}

void wakeUp() {
  Serial.println("Something woke me up");
  sleep_disable();
  detachInterrupt(digitalPinToInterrupt(interrupPin));
}

void goingToSleep() {
  attachInterrupt(digitalPinToInterrupt(interrupPin), wakeUp, LOW);
  digitalWrite(LED_BUILTIN,LOW);
  sleep_enable();
  sleep_cpu();

  //LowPower.powerDown(SLEEP_8S, ADC_OFF, BOD_OFF);
}
void loop() {
  //first power the device
  // wait it to get stable for x seconds
  digitalWrite(DHT_POWER_PIN,HIGH);
  digitalWrite(LED_BUILTIN,HIGH);
  if (read100TimesOrReady() == true) {
    Serial.print("T: ");
    Serial.print(temperature);
    Serial.print(" C");
    Serial.print("   H: ");
    Serial.print(humidity);
    Serial.println(" %");
    digitalWrite(DHT_POWER_PIN,LOW);
    Serial.println(" going to sleep");
    delay(100);
    //set some time to update stuff in the serial monitor
    goingToSleep();
  }
}

555 Arduino Interrupt

Uses arduino to power device and a trigger pin to power down Arduino
