Guitar Pickguard Wireless MIDI Controller

/* Scratchplate Midi Controller
 * Version 1.0.0 - ALPHA
 *
 * This midi controller should work with any MIDI compatible synth.
 * I have been using it with Audio Synth One on iOS with good results.
 *
 * The capacitive sensor allows 12 chromatic notes to be played.
 *
 * Octave can be changed via two push buttons. The default range is 4 octaves but this can easily be changed.
 *
 * A third push button allows you to change the device from normal mode to sustain mode. In sustain mode only one note can be played at a time.
 * This is equivalent to setting 'MONO' and 'HOLD' on a synth.
 *
 * Finally two potentiometers control MIDI CC 1 and MIDI CC 7.
 * These are traditionally mod wheel and volume knobs, but through MIDI learn can usually be set to anything you like.
 *
 * For full instructions please see: https://create.arduino.cc/projecthub/projects/238dd5
 *
 * Acknowledgements: This sketch is adapted from ble_neopixel_mpr121.ino, by Todd Treece, copyright of Adafruit

 (C) MIT Kzra 2021
 */

// libraries
#include "Wire.h"
#include "Adafruit_MPR121.h"
#include "Adafruit_BLE.h"
#include "Adafruit_BluefruitLE_SPI.h"
#include "Adafruit_BLEMIDI.h"
#include "BluefruitConfig.h"

// defined constants
#define FACTORYRESET_ENABLE         1
#define MINIMUM_FIRMWARE_VERSION    "0.7.0"
#define IRQ_PIN  A4
#define MOD_POT A0
#define VOL_POT A1
#define OCTAVE_UP 13
#define OCTAVE_DOWN 12
#define SUSTAIN 11

//set up capacitive sensor and bluetooth LE
Adafruit_MPR121 cap = Adafruit_MPR121();
Adafruit_BluefruitLE_SPI ble(BLUEFRUIT_SPI_CS, BLUEFRUIT_SPI_IRQ, BLUEFRUIT_SPI_RST);
Adafruit_BLEMIDI blemidi(ble);

// prime dynamic values
int channel = 0;
int octave = 4;
int potVal;
int modVal;
int lastModVal;
int volVal;
int lastVolVal;
bool sustainMode = false;
int prevNote;
uint16_t lasttouched = 0;
uint16_t currtouched = 0;
bool isConnected = false;

// constant values
const int pitch[] = {0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11};
const int PADS = 12;
const int vel = 127;

// A small helper
void error(const __FlashStringHelper*err) {
  Serial.println(err);
  while (1);
}
void connected(void)
{
  isConnected = true;
  Serial.println(F(" CONNECTED!"));
}

void disconnected(void)
{
  Serial.println("disconnected");
  isConnected = false;
}


void setup() {
   Serial.print(F("Initialising the Bluefruit LE module: "));

  if ( !ble.begin(VERBOSE_MODE) )
  {
    error(F("Couldn't find Bluefruit, make sure it's in CoMmanD mode & check wiring?"));
  }
  Serial.println( F("OK!") );

  if ( FACTORYRESET_ENABLE )
  {
    /* Perform a factory reset to make sure everything is in a known state */
    Serial.println(F("Performing a factory reset: "));
    if ( ! ble.factoryReset() ) {
      error(F("Couldn't factory reset"));
    }
  }

  //ble.sendCommandCheckOK(F("AT+uartflow=off"));
  ble.echo(false);

  Serial.println("Requesting Bluefruit info:");
  /* Print Bluefruit information */
  ble.info();

  /* Set BLE callbacks */
  ble.setConnectCallback(connected);
  ble.setDisconnectCallback(disconnected);

  Serial.println(F("Enable MIDI: "));
  if ( ! blemidi.begin(true) )
  {
    error(F("Could not enable MIDI"));
  }

  ble.verbose(false);
  Serial.print(F("Waiting for a connection..."));

  // set mpr121 IRQ pin to input
  pinMode(IRQ_PIN, INPUT);

  // bail if the mpr121 init fails
  if (! cap.begin(0x5A))
    while (1);

}

void loop() {
  // check for sustain
  if(digitalRead(SUSTAIN) == HIGH){
    if(sustainMode == false){
      sustainMode = true;
    }else {
      sustainMode = false;
      }
    // send a note off event on every pitch in current octave range
    for (uint8_t i=0; i < PADS; i++) {
       midi(channel, 0x8, pitch[i] + (12 * octave), 0x0);
    }
    Serial.println(sustainMode);
    delay(500);
  }
  // if mpr121 irq goes low, there have been
  // changes to the button states, so read the values
  if(digitalRead(IRQ_PIN) == LOW){
    // read current values
    currtouched = cap.touched();
    // normal mode
    if(sustainMode == false){
      cap_midi_normal();
    // sustain mode
    } else {
      cap_midi_sustain();
    }
    lasttouched = currtouched;
  }
  if(digitalRead(OCTAVE_UP) == HIGH){
    // send a note off event on every pitch in prev octave range
    for (uint8_t i=0; i < PADS; i++) {
          midi(channel, 0x8, pitch[i] + (12 * octave), 0x0);
    }
    octave++;
    if(octave == 7){
      octave = 3;
    }
    Serial.println(octave);
    delay(500);
  }
  if(digitalRead(OCTAVE_DOWN) == HIGH){
    // send a note off event on every pitch in prev octave range
    for (uint8_t i=0; i < PADS; i++) {
          midi(channel, 0x8, pitch[i] + (12 * octave), 0x0);
    }
    octave--;
    if(octave == 2){
      octave = 6;
    }
    Serial.println(octave);
    delay(500);
  }
  //  read the volume pot
  potVal = analogRead(VOL_POT);
  volVal= map(potVal, 0, 1023, 0, 127);
  if (lastVolVal != volVal) {
    Serial.print("volWheel = ");
    Serial.println(volVal);
    // It's a nibble for a CC change
    midi(channel, 0xB, 7, volVal);
    lastVolVal = volVal;
  }
  // finally read the modulation pot
  potVal = analogRead(MOD_POT);
  modVal = map(potVal, 0, 1023, 0, 127);
  //send new mod value if it has changed
  if (lastModVal != modVal) {
    Serial.print("modWheel = ");
    Serial.println(modVal);
    // It's a nibble for a CC change
    midi(channel, 0xB, 1, modVal);
    lastModVal = modVal;
  }

}

/* standard mode
 * (i) notes on only while touched
 * (ii) can play multiple notes at once
 */
void cap_midi_normal(){
    for (uint8_t i=0; i < PADS; i++) {
    // note on check
    if ((currtouched & _BV(i)) && !(lasttouched & _BV(i))) {
      // play pressed note
      midi(channel, 0x9, pitch[i] + (12 * octave), vel);
    }
    // note off check
    if ( !(currtouched & _BV(i)) && (lasttouched & _BV(i)) ) {
      // play note off
      midi(channel, 0x8, pitch[i] + (12 * octave), 0x0);
    }
   }
}

/* in sustain mode you can only play one note at a time, and it will stay on until you
 * (i) press the note again, or (ii) press another note
 */
void cap_midi_sustain(){
    for (uint8_t i=0; i < PADS; i++) {
    // note on check
    if ((currtouched & _BV(i))) {
      // play pressed note
      midi(channel, 0x9, pitch[i] + (12 * octave), vel);
      // turn off last pressed note
      midi(channel, 0x9, prevNote + (12 * octave), 0x0);
      // reset the index
      prevNote = i;
      // delay to allow user to remove hand
      delay(500);
    }
   }
}

// the callback that will be called by the sequencer when it needs
// to send midi commands over BLE.
void midi(byte channel, byte command, byte arg1, byte arg2) {
  // init combined byte
  byte combined = command;
  // shift if necessary and add MIDI channel
  if(combined < 128) {
    combined <<= 4;
    combined |= channel;
  }
  blemidi.send(combined, arg1, arg2);
}
