Temperature Monitoring Using mcThings and Wia.io

Using the mcThings IoT platform and Wia.io for visualization, we'll measure temperatures and display the data for visualization!

BeginnerFull instructions provided30 minutes1,155
Temperature Monitoring Using mcThings and Wia.io
Ad

Things used in this project

Hardware components

mcModule120 Dev Kit
mcThings mcModule120 Dev Kit
We recommend a kit for this example so that you have multiple modules to gather information from (Not required but you will need at least one mcModule, one mcGateway and an mcDongle)
×1
mcMod120 Module
mcThings mcMod120 Module
You'll need at least one mcModule120 for this project
×1
mcGateway110
mcThings mcGateway110
You'll need an mcGateway for this project
×1
mcDongle
mcThings mcDongle
You'll need one of these to complete your firmware updates! Be sure to update your firmware to the latest versions before starting
×1

Software apps and online services

mcStudio
mcThings mcStudio
Wia
Wia
MQTT
MQTT

Story

Read more

Schematics

mcModule120 Product brief

Code

mcModule120 Temp code for Wia.io

mcScript
Class TempLogger
    // Device ID in Wia
    Const wiaDeviceId As String = "Wia Device ID"
    // MQTT topic in Wia
    Const wiaTopic As String = "devices/" + wiaDeviceId + "/events/temperature"

    Shared Event CheckTemp() RaiseEvent Every 30 Seconds
        Dim temp As Float = TempSensor.GetTemp() // Get Temp from sensor
        Dim tempString As String = temp.ToString()

        // Create temp JSON object - { "temperature" : "23.06" }
        Dim tempJson As Json = New Json
        tempJson.Add("temperature", tempString)

        // Create Wia preferred JSON object - { "data" : {"temperature" : "23.06"}}
        Dim wiaPayload As Json = New Json
        wiaPayload.Add("data", tempJson)

        // Publish to wia MQTT
        Lplan.Publish(wiaTopic, wiaPayload.ToListOfByte)
    End Event
End Class

Temperature sensor library

mcScript
Temperature sensor library for the mcModule120
Class TempSensor
    // Function returns the temperature in degree celcius or
    // Float.NaN if something is wrong
    Shared Function GetTemp() As Float
        // Define the properties of the I2C peripheral and device address
        Dim sensor As I2c
        sensor = I2c.Create(250000, Pin.SCL, Pin.SDA, 0x48)

        // Power up the sensor and give it some time to settle
        Device.EnableTempSensor()
        Thread.Sleep(40000) // See page 13 of the datasheet

        // Read the sensor (only 2 bytes to read
        Dim res As ListOfByte = sensor.Read(2)

        // See Tmp102 documentation how to interpret the data (page 8)
        Dim temp As Float = Float.NaN
        If res <> Nothing Then
            // Shift the partial part to the right nibble
            Dim part As Float = res(1) >> 4
            // Temperature partial is 1/16*n where n is between 0 and 15
            part = part / 16
            // Sign extend the byte to an integer
            temp = res(0).SignExtend() + part
        End If

        // power off
        Device.DisableTempSensor()
        Return temp
    End Function

    Shared Function GetDieTemp() As Float
        // Just get the temperature and return
        Return Device.TempDie
    End Function

    Shared Function ToFarenheit(celcius As Float) As Float
        Return (celcius * 9) / 5 + 32
    End Function

    Shared Function ToCelcius(farenheit As Float) As Float
        Return (farenheit - 32) * 5 / 9
    End Function

End Class
