Play Polyphonic Tones!

This project is using my MusicWithoutDelay library to play multiple sounds at the same time.

IntermediateProtip24,431
Play Polyphonic Tones!

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Speaker: 0.25W, 8 ohms
Speaker: 0.25W, 8 ohms
×1
Resistor 221 ohm
Resistor 221 ohm
×2
Pushbutton switch 12mm
SparkFun Pushbutton switch 12mm
×3
Breadboard (generic)
Breadboard (generic)
×1
RGB Diffused Common Cathode
RGB Diffused Common Cathode
×1
Jumper wires (generic)
Jumper wires (generic)
×1
SparkFun vibrating motor
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

Schematics

Follow schematic.

Code

Legend Of Zelda

Arduino
A demonstration of my MusicWithoutDelay library. It plays the Legend of Zelda and allows the user to pause/play, skip, and reverse the song at any time. Best of all, since it doesn't use delay(), you can easily add more code to it and make it do other cool things, like read the Serial monitor or display on an Oled.
/*Example for the MusicWithoutDelay Library by Nathan Ramanathan. nathan6ramanathan@gmail.com
   This sketch puts all the functions to the test.

*/
//To learn more about this project go to https://github.com/nathanRamaNoodles/MusicWithoutDelay-LIbrary
#include <MusicWithoutDelay.h>
#include <Button.h>  //https://github.com/JChristensen/Button  acquired by JChristensen's popular button library
#include <Tone.h>                //https://github.com/bhagman/Tone
char *Soprano  = "Zelda:o=5,b=160,f=aeb:4b,4f+8.f,16b,16b,16c1,16d1,16e1,2f1,8p,8f1,12f1,12g_1,12a1,2b1,12p,12b1,12b1,12b1,12a1,12g_1,8.a1,16g_1,2f1,4f1,8e1,16e1,16f1,2g_1,8f1,8e1,8d_1,16d_1,16e1,2f1,8e1,8d_1,8c1,16c1,16d1,2e#1,4g1,8f1,16f,16f,8f,16f,16f,8f,16f,16f,8f,8f";
char *Bass     = ":b=160,f=aeb:4d,12d,12d,12c,8.d,16d,16d,16e,16f,16g,8.a,16b,16b,16c1,16d1,16e1,4f1,12a,12b,12c1,8.d_1,16g_,16g_,16a,16b,16c1,12d_1,12p,12d_1,12d_1,12c1,12b,8.d_,16a,12a,12a,12g_,8.a,16a,12a,12g_,12a,8g_,16g_,16f,8g_,16g_,16a,4b,8a,8g_,8f,16f,16e,8f,16f,16g_,4a,8g_,8f,4e#,8e#,16e#,16f,8g,16g,16a#,8b,8c1,8a#,16a#-1,16a#-1,8a#-1,16a#-1,16a#-1,8a#-1,16a#-1,16a#-1,8a#-1,8a#-1";
MusicWithoutDelay instrument(Soprano);          //o=5 means that the instrument will play at the 5th Octave. o=4 is default
MusicWithoutDelay instrument2(Bass);          //f=aeb, means all a's, e's, and b's are flats
Tone myTone;                                    //b=160, means the bpm(tempo) is 160, default is 100
Tone myTone2;
#define BUTTON_PIN 2       //Connect a tactile button switch (or something similar) from Arduino pin 2 to ground.
#define BUTTON_PIN2 3       //Connect a tactile button switch (or something similar) from Arduino pin 3 to ground.
#define BUTTON_PIN3 4       //Connect a tactile button switch (or something similar) from Arduino pin 3 to ground.

#define PULLUP true        //To keep things simple, we use the Arduino's internal pullup resistor.
#define INVERT true        //Since the pullup resistor will keep the pin high
#define DEBOUNCE_MS 70     //A debounce time of 70 milliseconds usually works well for noisy button switches. if not, try 20.
Button pauseButton(BUTTON_PIN, PULLUP, INVERT, DEBOUNCE_MS);    //Declare the button
Button randomSkipButton(BUTTON_PIN2, PULLUP, INVERT, DEBOUNCE_MS);
Button reverseButton(BUTTON_PIN3, PULLUP, INVERT, DEBOUNCE_MS);

const int potPin = A1;
const int vibratingMotor = A0;
unsigned long motorMillis = 0;

int rgbLeds[] = {13, 12, 11};
int ledCursor = 0;
bool pState;
bool state;
bool stopped = true;
void setup() {
  // put your setup code here, to run once:
  myTone.begin(7);        //attach both pins to same speaker with one 1k resistor to pin 11,
  myTone2.begin(6);       //and another 1k resistor to pin 10.
  for (int i = 0; i < 3; i++) {
    pinMode(rgbLeds[i], OUTPUT);
  }
  pinMode(vibratingMotor, OUTPUT);
}

void loop() {
  // put your main code here, to run repeatedly:
  unsigned long cMillis = millis();
  instrument.play(cMillis, myTone);
  instrument2.play(cMillis, myTone2);
  pauseButton.read();
  randomSkipButton.read();
  reverseButton.read();
  boundsCheck(instrument);
  boundsCheck(instrument2);
  if (instrument.isPaused() && instrument2.isPaused() && stopped) {
    Pause();
  }
  if (pauseButton.wasPressed()) {
    Pause();        // stop or play song
    stopped = false;
  }
  if (reverseButton.wasPressed()) {
    instrument.reverse();         //reverse direction of song
    instrument2.reverse();
  }
  if (randomSkipButton.wasPressed()) {   //skip to location in song depending on value of potentiometer
    int val = analogRead(potPin);
    val = map(val, 0, 1023, 0, instrument.getTotalTime());
    instrument.skipTo(val);
    val = analogRead(potPin);
    val = map(val, 0, 1023, 0, instrument2.getTotalTime());
    instrument2.skipTo(val);
  }
  if (instrument2.isNote()) {
    digitalWrite(vibratingMotor, HIGH);
    motorMillis = cMillis;
  }
  if (cMillis - motorMillis >= 40) {
    digitalWrite(vibratingMotor, LOW);
  }
  state = instrument.isNote();
  if (state != pState) {
    pState = state;
    if (pState) {
      digitalWrite(rgbLeds[ledCursor], LOW);
    }
    else {
      digitalWrite(rgbLeds[ledCursor], LOW);
      ledCursor++;
      if (ledCursor == 3) {
        ledCursor = 0;
      }
      digitalWrite(rgbLeds[ledCursor], HIGH);
    }
  }
  if (instrument.isRest()) {
    digitalWrite(rgbLeds[ledCursor], LOW);
  }
}
void boundsCheck(MusicWithoutDelay &m) {  //This function fixes songs that may have multiple instruments containing different TotalTimes
  if (m.isEnd()) {
    m.pause();
    stopped = true;
  }
}
void Pause() {
  instrument.pause();
  instrument2.pause();
}
