<!-- HTML Example -->
<html>
<head>
<meta name="viewport" content="width=device-width, initial-scale=1">
<script src="https://obniz.io/js/jquery-3.2.1.min.js"></script>
<script src="https://unpkg.com/obniz@2.0.2/obniz.js" crossorigin="anonymous"></script>
</head>
<body>
<div id="obniz-debug"></div>
<script>
const obniz = new Obniz("OBNIZ_ID_HERE");
obniz.onconnect = async function () {
const leds = obniz.wired("WS2812B", {gnd:2, vcc: 1, din: 0});
let positions = [0,0,0];
obniz.repeat(()=>{
var date = new Date();
positions[0] = date.getHours() % 12;
positions[1] = parseInt(date.getMinutes() / 5);
positions[2] = parseInt(date.getSeconds() / 5);
updateLED();
var ctx = obniz.display._ctx();
ctx.fillStyle='#000'
ctx.fillRect(0, 0, obniz.display.width, obniz.display.height);
ctx.fillStyle='#FFF';
ctx.strokeStyle='#FFF';
obniz.display.font('Avenir', 50)
obniz.display.pos(0,0);
obniz.display.print(`${date.getHours()}:${date.getMinutes()}`)
}, 1000);
function updateLED() {
let brightness = 20;
let arr = [];
for (let i=0; i<12; i++){
arr.push([0, 0, 0]);
}
arr[positions[0]][0] = brightness;
arr[positions[0]][1] = brightness;
arr[positions[1]][1] = brightness;
arr[positions[1]][2] = brightness;
if ((new Date()).getSeconds()%2==0) {
arr[positions[2]][0] = brightness;
arr[positions[2]][1] = brightness;
arr[positions[2]][2] = brightness;
}
arr.unshift(arr.splice(-1, 1)[0])
leds.rgbs(arr);
}
}
</script>
</body>
</html>
