Making a Honey Stand with Stripe, Thingio, and an ESP32

#include <WiFiClientSecure.h>
#include <MQTTClient.h>
#include <ArduinoJson.h>

#include "secrets.h"

#define SLEEP_MS 1000

#define SOLENOID_1_PIN 2
#define SOLENOID_2_PIN 3

#define SOLENOID_FB_1 20
#define SOLENOID_FB_2 9

//Mux control pins
#define EN_PIN 4

#define MUX_S0 5
#define MUX_S1 6
#define MUX_S2 7
#define MUX_S3 21

//Mux in "SIG" pin
#define SIG_PIN 10

int jarPositions[] = {
  2, 3, 4, 5, 6, 7, 8, 10, 12, 13, 14, 15
};

WiFiClientSecure net = WiFiClientSecure();
MQTTClient client = MQTTClient(256);

void handleUnlock() {
  digitalWrite(SOLENOID_1_PIN, HIGH);
  delay(500);
  digitalWrite(SOLENOID_1_PIN, LOW);
  delay(500);

  digitalWrite(SOLENOID_2_PIN, HIGH);
  delay(500);
  digitalWrite(SOLENOID_2_PIN, LOW);
  delay(500);
}

void callback(String &topic, String &payload) {
  StaticJsonDocument<512> doc;
  deserializeJson(doc, payload);
  const bool paymentCompleted = doc["paymentCompleted"];
  if (paymentCompleted) {
    Serial.println("Payment completed!");
    handleUnlock();
  }
}


void connectThingioCloud() {
  WiFi.mode(WIFI_STA);
  WiFi.begin(WIFI_SSID, WIFI_PASSWORD);

  Serial.println("Connecting to Wi-Fi");

  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }
  Serial.println();

  net.setCACert(CERT_CA);
  net.setCertificate(DEVICE_CERTIFICATE);
  net.setPrivateKey(PRIVATE_KEY);

  client.begin(ENDPOINT, 8883, net);
  client.onMessage(callback);  // Add the incoming message handler

  Serial.println("Connecting to Thingio Cloud");

  while (!client.connect(THING_NAME)) {
    Serial.print(".");
    delay(100);
  }

  if (!client.connected()) {
    Serial.println("Cannot connect to cloud, re-trying.");
    ESP.restart();
    return;
  }
  client.subscribe(THINGIO_CLOUD_SUB);  // Subscribe to the "listener" endpoint
  Serial.println("Thingio Cloud Connected!");
}

void reconnect() {
  // Loop until we're reconnected
  while (!client.connected()) {
    Serial.print("Attempting connection...");
    // Attempt to connect
    if (client.connect(THING_NAME)) {
      client.subscribe(THINGIO_CLOUD_SUB);
      Serial.println("connected");
    } else {
      Serial.println("Failed, try again in 5 seconds");
      // Wait 5 seconds before retrying
      delay(5000);
    }
  }
}


int readMux(int channel) {
  int controlPin[] = { MUX_S0, MUX_S1, MUX_S2, MUX_S3 };

  int muxChannel[16][4] = {
    { 0, 0, 0, 0 },  //channel 0
    { 1, 0, 0, 0 },  //channel 1
    { 0, 1, 0, 0 },  //channel 2
    { 1, 1, 0, 0 },  //channel 3
    { 0, 0, 1, 0 },  //channel 4
    { 1, 0, 1, 0 },  //channel 5
    { 0, 1, 1, 0 },  //channel 6
    { 1, 1, 1, 0 },  //channel 7
    { 0, 0, 0, 1 },  //channel 8
    { 1, 0, 0, 1 },  //channel 9
    { 0, 1, 0, 1 },  //channel 10
    { 1, 1, 0, 1 },  //channel 11
    { 0, 0, 1, 1 },  //channel 12
    { 1, 0, 1, 1 },  //channel 13
    { 0, 1, 1, 1 },  //channel 14
    { 1, 1, 1, 1 }   //channel 15
  };

  //loop through the 4 sig
  for (int i = 0; i < 4; i++) {
    digitalWrite(controlPin[i], muxChannel[channel][i]);
  }

  //read the value at the SIG pin
  int val = digitalRead(SIG_PIN);

  //return the value
  return val;
}


void setup() {
  delay(1000);
  Serial.begin(115200);
  Serial.println("Starting Stripe Thing");

  pinMode(SOLENOID_1_PIN, OUTPUT);
  pinMode(SOLENOID_2_PIN, OUTPUT);

  pinMode(SOLENOID_FB_1, INPUT_PULLUP);
  pinMode(SOLENOID_FB_2, INPUT_PULLUP);

  pinMode(MUX_S0, OUTPUT);
  pinMode(MUX_S1, OUTPUT);
  pinMode(MUX_S2, OUTPUT);
  pinMode(MUX_S3, OUTPUT);

  pinMode(SIG_PIN, INPUT);

  digitalWrite(MUX_S0, LOW);
  digitalWrite(MUX_S1, LOW);
  digitalWrite(MUX_S2, LOW);
  digitalWrite(MUX_S3, LOW);

  digitalWrite(SOLENOID_1_PIN, LOW);
  digitalWrite(SOLENOID_2_PIN, LOW);

  // Connect to the cloud
  connectThingioCloud();
}

void loop() {
  client.loop();
  if (!client.connected()) {
    reconnect();
  }

  int jarsRemaining = 0;
  for (int i = 0; i < 12; i++) {
    int isJarPresent = readMux(jarPositions[i]);
    Serial.print(isJarPresent);
    jarsRemaining += isJarPresent;
  }
  Serial.println("");
  Serial.println("------------");

  bool lidClosed = readMux(0);
  bool bothDoorsOpen = digitalRead(SOLENOID_FB_1) & digitalRead(SOLENOID_FB_2);

  Serial.print("Doors: ");
  Serial.print(bothDoorsOpen ? "Open. " : "Closed. ");

  Serial.print(" Lid: ");
  Serial.print(lidClosed ? "Closed. " : "Open. ");

  Serial.print("Jars Remaining: ");
  Serial.println(jarsRemaining);

  Serial.println("------------");

  if ((!bothDoorsOpen) & (jarsRemaining == 0) & lidClosed) {
    handleUnlock();
    Serial.println("No jars left, keep doors open!");
  }

  if (!lidClosed & !bothDoorsOpen) {
    handleUnlock();
  }

  delay(SLEEP_MS);
}
