Temperature Logger With Arduino And Artik Cloud

Sending temperature from Arduino MKR1000 to Artik Cloud.

IntermediateFull instructions provided2 hours3,505
Temperature Logger With Arduino And Artik Cloud

Things used in this project

Story

Read more

Schematics

ARDUINO_PIN_CONNECTION

Code

TEMP_ARTIK.ino

Arduino
Used to detect temperature in LM35 and send in to ARTIKcloud ,
#include <WiFi101.h>
#include <ArduinoJson.h>
int temp = 9; //temperature pin
int val;

// Web REST API params
char server[] = "api.artik.cloud";
int port = 443; //(port 443 is default for HTTPS)

String AuthorizationData = "Authorization: Bearer  <YOUR DEVICE TOKEN>";


char buf[200];
int LED = 6;
int ledState = 0;

WiFiSSLClient client;
char ssid[] = "YOUR SSID";      //  your network SSID (name)
char pass[] = "YOUR PASSWORD";
int status = WL_IDLE_STATUS;

void setup() {

  pinMode(LED,OUTPUT);
  pinMode(temp, INPUT); // LM35 pin

  Serial.begin(9600);
  while (status != WL_CONNECTED){
    Serial.println("Attempting to connect to WiFi");
    status = WiFi.begin(ssid,pass);
  }
  Serial.println("connected to WiFi ");

}

void loop() {
  Serial.println("loop");
  ledToggle();
  client.connect(server, port);
  delay(1000);
  if (!client.connected()) {
    Serial.println(" error ");
  } else {
      //int t = dht.readTemperature();
      //int h = dht.readHumidity();
      val = analogRead(temp);
float mv = ( val/1024.0)*5000; //FInd temperature
float cel = mv/100;            //convert in to celsius
float farh = (cel*9)/5 + 32;   //convert in to fahrenheat (optional)
      Serial.println("Sending data"+String(cel)); // sending data
      client.println("POST /v1.1/messages HTTP/1.1");
      client.println("Host: api.artik.cloud");
      client.println("Accept: */*");
      client.println("Content-Type: application/json");
      client.println("Connection: close");
      client.println(AuthorizationData);

       // Automated POST data section
       client.print("Content-Length: ");
       client.println(loadBuffer(cel,farh)); // loads buf, returns length
       client.println();
       client.println(buf);
       Serial.println("Data posted");
       client.stop();
  }

  delay(3*60*1000); // setting delay foe 3 minutes

}

int loadBuffer(int insTemp, int insHumid ) {
   StaticJsonBuffer<200> jsonBuffer; // reserve spot in memory

   JsonObject& root = jsonBuffer.createObject(); // create root objects
     root["sdid"] = "<YOUR DEVICE ID>"; // FIX
     root["type"] = "message";

   JsonObject& dataPair = root.createNestedObject("data"); // create nested objects
     dataPair["temp"] = insTemp;
     dataPair["humid"] = insHumid;

   root.printTo(buf, sizeof(buf)); // JSON-print to buffer

   return (root.measureLength()); // also return length
 }

 void ledToggle(){
  if (ledState == 0){
    digitalWrite(LED,LOW);
    ledState = 1;
  } else {
    digitalWrite(LED,HIGH);
    ledState = 0;
  }
 }
