Arduino HMI Using State Machines

Finite State Machines (FSM) are a powerful design pattern to develop complex Human Machine Interfaces (HMI). As the functionality of an HMI can increase, it is useful to use a design pattern like state machines.

The complete example is embedded in YAKINDU Statechart Tools. Additionally, the Eclipse C++ IDE for Arduino Plugin has been used for compiling and flashing in the IDE.

The Hardware

The LCD Keypad Shield can simply be plugged into the Arduino. It has a 16x2 LCD Display and additionally got six pushbuttons:

• Left
• Right
• Up
• Down
• Select
• (Reset)

Obviously, five of them can be used. The keys are wired to a voltage divider and are detected by using Pin A0 depending on the voltage. I've used software debouncing to detect them correctly.

Define How It Should Work

The application should be capable to do three things.

• Handle StatesHere I want to use the buttons to navigate between five states: Top, Middle, Bottom, Left and Right
• StopwatchA simple stopwatch, which can be started, stopped and reset. It should be incremented every 100 milliseconds
• CounterThe third part contains a simple up/down counter. It should be able to count positive numbers and it should be resettable

The active menu (or the state) will be displayed on the 16x2 LCD on the top line. The application (State, Timer or Counter) will be displayed on the bottom line. For navigation, the left and right pushbutton should be used.

Interfacing the State Machine

The buttons will be debounced and wire to the state machine. They can be used as in events in the state machine. Additionally, operations are defined to display the current menu. And at least two variables, one for the timer and one for the counter, are defined.

After generating the C++ code, the in events must be debounced and wired to the interface. This code snippet shows how to do this.

At first, the buttons will be defined:

#define NONE 0
#define SELECT 1
#define LEFT 2
#define DOWN 3
#define UP 4
#define RIGHT 5

Then there is a function defined to read the button. The values may vary, depending on the LCD Shield manufacturer.

static int readButton() {
    int result = 0;
    result = analogRead(0);
    if (result < 50) {
        return RIGHT;
    }
    if (result < 150) {
        return UP;
    }
    if (result < 300) {
        return DOWN;
    }
    if (result < 550) {
        return LEFT;
    }
    if (result < 850) {
        return SELECT;
    }
    return NONE;
}

At the end, the buttons will be debounced. I did good results with 80 ms. Once a button will be released, it will raise the according in event.

int oldState = NONE;
static void raiseEvents() {
    int buttonPressed = readButton();
    delay(80);
    oldState = buttonPressed;
    if (oldState != NONE && readButton() == NONE) {
        switch (oldState) {
        case SELECT: {
            stateMachine->raise_select();
            break;
        }
        case LEFT: {
            stateMachine->raise_left();
            break;
        }
        case DOWN: {
            stateMachine->raise_down();
            break;
        }
        case UP: {
            stateMachine->raise_up();
            break;
        }
        case RIGHT: {
            stateMachine->raise_right();
            break;
        }
        default: {
            break;
        }
        }
    }
}

HMI Control

Each state is used for one part of the menu. There are sub-states, where the application - for example the stopwatch - will be executed.

With this design, the interface can be easily expanded. Additional menus can be simply added by using the same design pattern. Reading a value of a sensor and display it in a fourth menu item is no big deal.

For now, only left and right is used as a the control. But up and down can also be used as a navigation extension in the main menu. Only the select button will be used to enter a specific menu item.

In the following I will have a detailed look at the different functionalities.

Handle States

The handle states menu is only used as a further example of navigation. Using up, down, right or left allows switching between the states. The current state will always be printed on the second line on the LCD Display.

Stopwatch

The stopwatch is quite simple. Initially, the timer value will be reset. The timer can be started by using the left button and toggled by using left and right. Using up or down resets the timer. The timer can also be set back to zero by using the select button twice - leaving the menu and entering it once again, as the timer will be set to zero by initially entering the stopwatch.

Counter

At least, there is a counter implemented. Entering the counter state resets the counter. It can be started by using any pushbutton, except for the select button. It's implemented as a simple up/down counter, which value cannot be smaller than 0.

Simulation

A cool feature in YAKINDU Statechart Tools is the simulation. Before even writing a single line of code you can check the functionality with the simulation.

Get the Example

You can download the IDE here: YAKINDU Statechart Tools

Once you have downloaded the IDE, you find the example via File -> New -> Example -> HMI with LCD Keypad Shield (C++)

It's free to use for hobbyists, but you also can use a 30 days trial.
