Screen Time Break for Arduino UNO

A simple and smart Arduino time keeping code that reminds computer users to take a visual break from their screen.

IntermediateFull instructions provided606
Screen Time Break for Arduino UNO

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
DFRobot 1602 LCD Keypad Shield
×1
USB-A to B Cable
USB-A to B Cable
×1
5 mm LED: Red
5 mm LED: Red
×1
Wire, Wrapping Wire
Wire, Wrapping Wire
×1

Software apps and online services

Arduino IDE
Arduino IDE

Hand tools and fabrication machines

Soldering iron (generic)
Soldering iron (generic)
Solder Flux, Soldering
Solder Flux, Soldering

Story

Read more

Custom parts and enclosures

Arduino LCD Shield Enclosure Case

Schematics

Screen Time Break for Arduino UNO and LCD Keypad Shield.

Code

Screen Time Break for Arduino UNO and LCD Keypad Shield

Arduino
A simple and smart Arduino time keeping code that reminds computer users to take a visual break from their screen.
/*
Screen Time Break 1.0.0 for Arduino UNO and LCD Keypad Shield.
Copyright (c) 2022, Alex Aldridge
Created on Oct 7, 2022
www.alexaldridge.co

A simple and smart Arduino time keeping code that reminds computer users to take a visual break from their screen.
Every 20 minutes an LED light indicates that the computer user should take a visual break from their screen.
If the timer has been operating for more than 2 hours, the user is reminded to take a 20 minute break.

Press the RIGHT button for 2 seconds to start the timer.
Press the LEFT button to pause the timer.
Press the RIGHT button after pressing the LEFT button to resume the timer.
Press the RST button to reset the timer.
The timer has a limit of 24 hours and will automatically reset after 24 hours.

This software is free and open-source; anyone can redistribute it and/or modify it.
*/

#include <LiquidCrystal.h>
//LCD pin to Arduino
const int pin_RS = 8;
const int pin_EN = 9;
const int pin_d4 = 4;
const int pin_d5 = 5;
const int pin_d6 = 6;
const int pin_d7 = 7;

LiquidCrystal lcd( pin_RS,  pin_EN,  pin_d4,  pin_d5,  pin_d6,  pin_d7);

int sec = 0;
int min = 0;
int hou = 0;
int bulkmin= 0, bulksec = 0, bulkhou = 0;
long start_time = 0;
boolean time_two_hour = false;


int button = 0;
int safe=0;
int pause = 0 ;

void setup(){
    pinMode(2, OUTPUT);


    lcd.begin(16, 2);
    lcd.clear();
    lcd.setCursor(2,0);
    lcd.print("Screen Time");


    Serial.begin(9600);

}

void loop(){

 button = analogRead(0);

    if ( button <= 60){

      pause = 1;

    }
    if (button >=400 && button <= 600){


      pause = 2;

    }
  if(pause == 1){


       sec = sec + 1;
          if(sec == 20){

           digitalWrite(2, LOW);
                      }

         if(sec == 60){
            lcd.setCursor(11,1);
            lcd.print(" ");
            lcd.setCursor(12,1);
            lcd.print(" ");
            bulksec = sec;
            sec = 00;
            min = min + 1;


              if (min == 20 || min == 40 || min == 60){

                digitalWrite(2, HIGH);

                                                }

                    if(min == 60){
                       lcd.setCursor(8,1);
                       lcd.print(" ");
                       lcd.setCursor(9,1);
                       lcd.print(" ");
                       bulkmin = min;
                       min = 00;
                       hou = hou + 1;

                        if((hou % 2) ==0){

                          digitalWrite(2, HIGH);
                            time_two_hour = true;
                            start_time = millis();


                        }

                          if(hou == 23 && bulkmin == 60){

                              lcd.setCursor(5,1);
                              lcd.print(" ");
                              lcd.setCursor(6,1);
                              lcd.print(" ");
                              hou = 00;
                                          }

                   }
         }
      printTime();
      Timer_Time();
  }
  else{




     printTime();
     Timer_Time();
  }


 delay(1000);
    }

void Timer_Time()
{

if(time_two_hour == true)
{
if(start_time + 90000 <= millis())
{
    digitalWrite(2, LOW);
    time_two_hour = false;
}

}

}

void printTime()
{
    if(hou<=9)
    { lcd.setCursor(4,1); lcd.print("0");
     lcd.setCursor(5,1); lcd.print(hou); }
    else
    {lcd.setCursor(4,1); lcd.print(hou); }
    lcd.setCursor(6,1);
    lcd.print(":");
    if(min<=9)
    { lcd.setCursor(7,1); lcd.print("0");
      lcd.setCursor(8,1); lcd.print(min); }
    else
    {lcd.setCursor(7,1); lcd.print(min); }

    lcd.setCursor(9,1);
    lcd.print(":");
     if(sec<=9)
    {
      lcd.setCursor(10,1);
      lcd.print("0");
      lcd.setCursor(11,1);
      lcd.print(sec);
    }
    else{
      lcd.setCursor(10,1);
      lcd.print(sec);
    }
}
