Alexa Skills - Rest API Using HTTP

This story is how I used an existing Rest API that was available and added Alexa Voice engine for my Rasberry Echo. By using Alexa I was able to have her dictate the text and allow her to enter manually the desired question/rest api calls, as well as allowed the response to also be spoken and displayed visually on the app.

If you have not ever created skill than I highly recommend going through the Amazon Skill to create a "Trivia Skill" to get a basic understanding of how the services work and how the intents match up to the lambda functions.

This example will help show you how Lambda Functions can communicating with the Rest API to get the desired text response.

Where does the Rest API fit in the Alexa flow?

1. Alexa [Wake Word], ask 'Gospel Library' to Read Matthew 10 14

2. Attempts to match Invocation Name to the skill from those enabled on the device to match 'Gospel Library' from your developer.amazon.com/alexa

3. Once it matches the Invocation Name then the 'Intent' will be matched based on the text provided after the Invocation Name. 'Read Matthew 10 14'

4. This then matched my intent named: ReadBookChapterVerseIntent. Which sends the request to aws.amazon.com/lambda with the provided paramters mapped in the sample utterances.

5. The function is then started whether that is the welcome or the specific intent in this is called because of the 'onIntent' function in the lambda function.

6. The onIntent then triggers the `function ReadBookChapterVerse(intent, session, callback)`

7. In the ReadBookChapterVerse function we do a few things:

• Initialize default variables

• Set function variables from the intent (intent.slots.book then .value)

• Checks valid variables provided otherwise asks for re-prompt

• Store sessions variables

• Using Node.JS and var http = require('http');

• Executes webRequest

• Resolves webrequest data to then return speech result or re-prompt

8. Text is then sent to the Alexa Skill to be read on Alexa Device and also create a card tile for iOS/Android Alexa app.

CODE

Here is the highlighted code blocks that made this all possible and allowed me to recieve the data from Alexa -> developer.amazon.com -> aws.amazon.com/lambda -> rest api -> aws.amazon.com/lambda -> developer.amazon.com -> Alexa/phone app

Intent Schema

{
 "intents": [
   {
     "intent": "RandomScriptureMasteryIntent"
   },
   {
     "slots": [
       {
         "name": "book",
         "type": "BOMBOOKS"
       },
       {
         "name": "chapter",
         "type": "AMAZON.NUMBER"
       },
       {
         "name": "startVerse",
         "type": "AMAZON.NUMBER"
       },
       {
         "name": "endVerse",
         "type": "AMAZON.NUMBER"
       }
     ],
     "intent": "ReadBookChapterVerseIntent"
   },
   {
     "slots": [
       {
         "name": "startVerse",
         "type": "AMAZON.NUMBER"
       },
       {
         "name": "endVerse",
         "type": "AMAZON.NUMBER"
       }
     ],
     "intent": "ReadNextVerseIntent"
   },
   {
     "intent": "AMAZON.HelpIntent"
   },
   {
     "intent": "AMAZON.StopIntent"
   },
   {
     "intent": "AMAZON.CancelIntent"
   }
 ]
}

Custom Slot

BOMBOOKS

1 Nephi
1st Nephi
2 Nephi
2nd Nephi
Jacob
Enos
Jarom
Omni
Words of Mormon
Mosiah
Alma
Helaman
3 Nephi
3rd Nephi
4 Nephi
4th Nephi
Mormon
Ether
Moroni
Exodus
Leviticus
Numbers
Deuteronomy
Joshua
Judges
Ruth
1 Samuel
1st Samuel
2 Samuel
2nd Samuel
1 Kings
1st Kings
2 Kings
2nd Kings
1 Chronicles
1st Chronicles
2 Chronicles
2nd Chronicles
Ezra
Nehemiah
Esther
Job
Psalms
Proverbs
Ecclesiastes
Song of Solomon
Isaiah
Jeremiah
Lamentations
Ezekiel
Daniel
Hosea
Joel
Amos
Obadiah
Jonah
Micah
Nahum
Habakkuk
Zephaniah
Haggai
Zechariah
Malachi
Matthew
Mark
Luke
John
Acts
Romans
1 Corinthians
1st Corinthians
2 Corinthians
2nd Corinthians
Galatians
Ephesians
Philippians
Colossians
1 Thessalonians
1st Thessalonians
2 Thessalonians
2nd Thessalonians
1 Timothy
1st Timothy
2 Timothy
2nd Timothy
Titus
Philemon
Hebrews
James
1 Peter
1st Peter
2 Peter
2nd Peter
1 John
1st John
2 John
2nd John
3 John
3rd John
Jude
Revelation
DC
Doctrine and Covenants

Sample Utterances

Lambda Function (GospelLibraryReader)

function sendWebRequest(inBook, chapter, startVerse, endVerse, cardTitle, callback)
{
   var _this = this;
   var sessionAttributes = {};
   var book = resolveBook(inBook);
   sessionAttributes = createCurrentVerseAttributes(book, chapter, endVerse);
   var url = 'http://bomapi-happycloud.rhcloud.com/v1/verses/' + book + '/' + chapter + '/' + startVerse + '/' + endVerse;
   console.log("Requesting: " + url);
   http.get(url, function(res){
               res.setEncoding('utf8');
               res.on('data', function(chunk){
                   var resultArray;
                   if(chunk)
                       resultArray = JSON.parse('' + chunk);
                   else
                       _this.console.log('Unable to resolve web request to happycloud.')
                   if(resultArray)
                       _this.console.log('array ' + resultArray + " length: " + resultArray.length);
                    var scriptureResult = '';
                    if(resultArray)
                       for (var i = 0; i < resultArray.length; i++) {
                           _this.console.log(i + ' ' + resultArray[i]);
                           scriptureResult = scriptureResult + " " + resultArray[i].book_title + " " + resultArray[i].chapter_number + ":" + resultArray[i].verse_number + " " + resultArray[i].scripture_text;
                       }
                   repromptText = "Please ask me to tell you a verse by saying, Read 1st Nephi 3 verse 7";
                   if(scriptureResult)
                   {
                       speechOutput = scriptureResult;
                       callback(sessionAttributes,
                           buildNextSpeechletResponse(cardTitle, speechOutput, repromptText, false));
                   }
                   else
                   {
                       speechOutput = 'I was unable to find ' + book + ' ' + chapter + ':' + startVerse + '. Please try another scripture';
                       callback(sessionAttributes,
                           buildSpeechletResponse(cardTitle, speechOutput, repromptText, false));
                   }
               });
       }).on('error', function (e) {
           speechOutput = 'I was unable to find ' + book + ' ' + chapter + ':' + startVerse + '. Please try another scripture';
           repromptText = 'Please ask me to tell you a verse by saying, Read 1st Nephi 3 verse 7';
           callback(sessionAttributes,
               buildSpeechletResponse(cardTitle, speechOutput, repromptText, false));
       });
}

Configure Test Event

Execute

For my specific case I was trying to support reading text from this rest api described here: https://tech.lds.org/forum/viewtopic.php?t=23076 This Rest API was setup and ready for my consumption. However there needed to be a few tweaks to it but overall everything went without any issues. I hope you have a similar result in using an existing Rest API.
