Automation basics using arduino and DTMF decoder

This projects explains the basic set up of automation using DTMF technology.It can be applicable in any automation field.

IntermediateFull instructions provided8,886

Automation basics using arduino and DTMF decoder

Things used in this project

Hardware components

Arduino UNO

MICO DTMF Basic Shield for Arduino

Story

The project uses the DTMF technology. The tone generated from cell phone is converted into binary numbers.This particular number is used for driving LEDs or relays.

Code

Arduino code

int x,y,z,t;

int a=3;

int b=4;

int c=5;

int d=6;

int e=7;

int f=8;

int g=9;

int h=10;

void setup() {



pinMode(a,INPUT);

pinMode(b,INPUT);

pinMode(c,INPUT);

pinMode(d,INPUT);

pinMode(e, OUTPUT);

pinMode(f,OUTPUT);

pinMode(g,OUTPUT);

pinMode(h,OUTPUT);

Serial.begin (9600);

}

void loop() {



x=digitalRead(a);

y=digitalRead(b);

z=digitalRead(c);

t=digitalRead(d);

Serial.print(x);

Serial.print(y);

Serial.print(z);

Serial.println(t);

delay(1000);

if (x==1 && y==0 && z==1 && t==1)

{digitalWrite(e,HIGH);

digitalWrite(f,LOW);

digitalWrite(g,HIGH);

digitalWrite(h,LOW);}

if (x==1 && y==1 && z==1 && t==0)

{digitalWrite(e,LOW);

digitalWrite(f,HIGH);

digitalWrite(g,LOW);

digitalWrite(h,HIGH);}

if (x==1 && y==1 && z==0 && t==1)

{digitalWrite(e,LOW);

digitalWrite(f,LOW);

digitalWrite(g,HIGH);

digitalWrite(h,LOW);}

if (x==1 && y==0 && z==0 && t==1)

{digitalWrite(e,HIGH);

digitalWrite(f,LOW);

digitalWrite(g,LOW);

digitalWrite(h,LOW);}

if (x==0 && y==0 && z==1 && t==1)

{digitalWrite(e,LOW);

digitalWrite(f,LOW);

digitalWrite(g,LOW);

digitalWrite(h,LOW);}}
