Bike Turn Signal - Part 1

Using 8x8 WS2812B RGB LED Matrix, Arduino Nano & PS2 Joystick Module

BeginnerWork in progress2,147

Things used in this project

Hardware components

Arduino Nano R3

Analog joystick (Generic)

PS2 Joystick Module

RGB LED Pixel Matrix, NeoPixel NeoMatrix

8x8 WS2812B RGB LED Matrix

Jumper wires (generic)

Software apps and online services

Arduino IDE

Hand tools and fabrication machines

Soldering iron (generic)

Story

This video is going to be the first in a series of multi-part videos.

Part 1 would mostly consist of equipment and initial code testing.

I'm planning on improving/adding features or functions to this project and the videos for those would be uploaded in the following weeks.

As of now, I'm still waiting for the replacement parts from China and I think it would take a long time before I receive it, because of the Corona Virus/COVID-19 stuff.

I've been planning on making this since 2018 and I have actually recorded the videos for it already, but since I have just upgraded my camera last 2019, I thought that it would be weird to upload a video that has lower quality.

Encountered a problem related to the library as well, but I have managed to fix it.

On this project, I would use an ArduinoNANO board, an 8x8 WS2812B RGB LED Matrix and a PS2JoystickModule.

******************************************************************************

Facebook

Twitter

Instagram

******************************************************************************

In action

One of the three malfunctioning matrices that was delivered to me.

Watch the full video here.

https://youtube.com/@HeathenHacks

Code

Initial_Test_Code.ino

#include <Arduino.h>
#include "FastLED.h"
#define Vx A0 // Define / Equate "Vx" with A0, the pin where Vx is connected
#define Vy A1 // Define / Equate "Vy" with A1, the pin where Vy is connected
#define Button A2 // Define / Equate Button with A2, the pin where the button is connected
#define NUM_LEDS 64
#define DATA_PIN 2

CRGB leds[NUM_LEDS];

void setup() {
  pinMode(Vx, INPUT); // Configure Vx (A0) as an Input
  pinMode(Vy, INPUT); // Configure Vy (A1) as an Input
  pinMode(Button, INPUT_PULLUP); // Configure Button (A2) as an Input, internally "pulled-up" to 5V
  // Note, we're configuring an Analog input as digital input
  // which is perfectly fine.  I did this to make the wiring easier
  // and keep all of the wires on the same side of the board
  FastLED.addLeds<WS2812B, DATA_PIN, GRB>(leds, NUM_LEDS);
  FastLED.setBrightness(64);
  Serial.begin(9600); // Initialize Serial Port at 9600 baud to display the results

}

void loop()
{
  int x, y, btn;

  x = analogRead(Vx); // Read the analog value of Vx (Analog Values are from 0-1023 which equate to 0V to 5V)
  y = analogRead(Vy); // Read the analog value of Vy
  btn = digitalRead(Button); // Read the button.  When the button is open (unpushed),
  // the input will read High (+5V)
  // When the button is closed (pressed), the input pin
  // is connected to ground and will read Low (0V)

  /*Serial.print(x);  // Print the X value to the serial port
    Serial.print("\t"); // Print a Tab character
    Serial.print(y);  // Print the Y value
    Serial.print("\t"); // Print a Tab
    Serial.println(btn); // Print the value of the Btn (0=Pushed, 1 = Not Pushed)
    delay(250); // Delay 250ms so the results don't print too quickly*/

  if  (x <= 80) {

    FastLED.clear();
    leds[3] = CRGB(255, 18, 0);
    leds[4] = CRGB(255, 18, 0);
    leds[11] = CRGB(255, 18, 0);
    leds[12] = CRGB(255, 18, 0);
    leds[19] = CRGB(255, 18, 0);
    leds[20] = CRGB(255, 18, 0);
    leds[24] = CRGB(255, 18, 0);
    leds[27] = CRGB(255, 18, 0);
    leds[28] = CRGB(255, 18, 0);
    leds[31] = CRGB(255, 18, 0);
    leds[32] = CRGB(255, 18, 0);
    leds[33] = CRGB(255, 18, 0);
    leds[35] = CRGB(255, 18, 0);
    leds[36] = CRGB(255, 18, 0);
    leds[38] = CRGB(255, 18, 0);
    leds[39] = CRGB(255, 18, 0);
    leds[41] = CRGB(255, 18, 0);
    leds[42] = CRGB(255, 18, 0);
    leds[43] = CRGB(255, 18, 0);
    leds[44] = CRGB(255, 18, 0);
    leds[45] = CRGB(255, 18, 0);
    leds[46] = CRGB(255, 18, 0);
    leds[50] = CRGB(255, 18, 0);
    leds[51] = CRGB(255, 18, 0);
    leds[52] = CRGB(255, 18, 0);
    leds[53] = CRGB(255, 18, 0);
    leds[59] = CRGB(255, 18, 0);
    leds[60] = CRGB(255, 18, 0);
    FastLED.show();
  }

  if  (x >= 900) {

    FastLED.clear();
    leds[3] = CRGB(255, 18, 0);
    leds[4] = CRGB(255, 18, 0);
    leds[10] = CRGB(255, 18, 0);
    leds[11] = CRGB(255, 18, 0);
    leds[12] = CRGB(255, 18, 0);
    leds[13] = CRGB(255, 18, 0);
    leds[17] = CRGB(255, 18, 0);
    leds[18] = CRGB(255, 18, 0);
    leds[19] = CRGB(255, 18, 0);
    leds[20] = CRGB(255, 18, 0);
    leds[21] = CRGB(255, 18, 0);
    leds[22] = CRGB(255, 18, 0);
    leds[24] = CRGB(255, 18, 0);
    leds[25] = CRGB(255, 18, 0);
    leds[27] = CRGB(255, 18, 0);
    leds[28] = CRGB(255, 18, 0);
    leds[30] = CRGB(255, 18, 0);
    leds[31] = CRGB(255, 18, 0);
    leds[32] = CRGB(255, 18, 0);
    leds[35] = CRGB(255, 18, 0);
    leds[36] = CRGB(255, 18, 0);
    leds[39] = CRGB(255, 18, 0);
    leds[43] = CRGB(255, 18, 0);
    leds[44] = CRGB(255, 18, 0);
    leds[51] = CRGB(255, 18, 0);
    leds[52] = CRGB(255, 18, 0);
    leds[59] = CRGB(255, 18, 0);
    leds[60] = CRGB(255, 18, 0);
    FastLED.show();
  }

  if  (y <= 100) {

    FastLED.clear();
    fill_solid (leds, NUM_LEDS, CRGB(0, 255, 0));
    FastLED.show();
  }

  if (y >= 900) {

    FastLED.clear();
    fill_solid (leds, NUM_LEDS, CRGB(255, 0, 0));
    FastLED.show();
  }

  if (btn == 0) {

    FastLED.clear();
    FastLED.show();
  }
}
