Obstacle Avoiding Car

An Arduino controlled car that avoids obstacles (ie. walls or objects in front of it).

BeginnerShowcase (no instructions)2 hours134,698
Obstacle Avoiding Car

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
SparkFun mini breadboard
×1
Dual H-Bridge motor drivers L298
SparkFun Dual H-Bridge motor drivers L298
×1
Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1
Servos (Tower Pro MG996R)
×1
DC motor (generic)
×1
4 AA battery holder
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Software apps and online services

Arduino Web Editor
Arduino Web Editor

Hand tools and fabrication machines

Hot glue gun (generic)
Hot glue gun (generic)
super glue
tiny screwdriver

Schematics

Schematics

Usually people use two power sources, one for the Arduino and another one for the L298N Motor Driver. That's not necessary as the L298n has a 5v regulator that can power the Arduino, so i took advantage of that.

Code

Arduino Obstacle avoidance Car code

Arduino
Use it to Control the components on the car.
You need the New Ping Library for the ultrasonic sensor.
The maximum distance between the car and an object is set in the code and the reaction of the car too. The reaction of the car to an obstacle is : go back, look right, look left and go where it is clear. If both sides are clear, it will go forward.
#include <Servo.h>          //standard library for the servo
#include <NewPing.h>        //for the Ultrasonic sensor function library.

//L298N motor control pins
const int LeftMotorForward = 6;
const int LeftMotorBackward = 7;
const int RightMotorForward = 5;
const int RightMotorBackward = 4;

//sensor pins
#define trig_pin A1 //analog input 1
#define echo_pin A2 //analog input 2

#define maximum_distance 200
boolean goesForward = false;
int distance = 100;

NewPing sonar(trig_pin, echo_pin, maximum_distance); //sensor function
Servo servo_motor;

void setup(){

  pinMode(RightMotorForward, OUTPUT);
  pinMode(LeftMotorForward, OUTPUT);
  pinMode(LeftMotorBackward, OUTPUT);
  pinMode(RightMotorBackward, OUTPUT);

  servo_motor.attach(9); //our servo pin

  servo_motor.write(115);
  delay(2000);
  distance = readPing();
  delay(100);
  distance = readPing();
  delay(100);
  distance = readPing();
  delay(100);
  distance = readPing();
  delay(100);
}

void loop(){

  int distanceRight = 0;
  int distanceLeft = 0;
  delay(50);

  if (distance <= 20){
    moveStop();
    delay(300);
    moveBackward();
    delay(400);
    moveStop();
    delay(300);
    distanceRight = lookRight();
    delay(300);
    distanceLeft = lookLeft();
    delay(300);

    if (distance >= distanceLeft){
      turnRight();
      moveStop();
    }
    else{
      turnLeft();
      moveStop();
    }
  }
  else{
    moveForward();
  }
    distance = readPing();
}

int lookRight(){
  servo_motor.write(50);
  delay(500);
  int distance = readPing();
  delay(100);
  servo_motor.write(115);
  return distance;
}

int lookLeft(){
  servo_motor.write(170);
  delay(500);
  int distance = readPing();
  delay(100);
  servo_motor.write(115);
  return distance;
  delay(100);
}

int readPing(){
  delay(70);
  int cm = sonar.ping_cm();
  if (cm==0){
    cm=250;
  }
  return cm;
}

void moveStop(){

  digitalWrite(RightMotorForward, LOW);
  digitalWrite(LeftMotorForward, LOW);
  digitalWrite(RightMotorBackward, LOW);
  digitalWrite(LeftMotorBackward, LOW);
}

void moveForward(){

  if(!goesForward){

    goesForward=true;

    digitalWrite(LeftMotorForward, HIGH);
    digitalWrite(RightMotorForward, HIGH);

    digitalWrite(LeftMotorBackward, LOW);
    digitalWrite(RightMotorBackward, LOW);
  }
}

void moveBackward(){

  goesForward=false;

  digitalWrite(LeftMotorBackward, HIGH);
  digitalWrite(RightMotorBackward, HIGH);

  digitalWrite(LeftMotorForward, LOW);
  digitalWrite(RightMotorForward, LOW);

}

void turnRight(){

  digitalWrite(LeftMotorForward, HIGH);
  digitalWrite(RightMotorBackward, HIGH);

  digitalWrite(LeftMotorBackward, LOW);
  digitalWrite(RightMotorForward, LOW);

  delay(500);

  digitalWrite(LeftMotorForward, HIGH);
  digitalWrite(RightMotorForward, HIGH);

  digitalWrite(LeftMotorBackward, LOW);
  digitalWrite(RightMotorBackward, LOW);



}

void turnLeft(){

  digitalWrite(LeftMotorBackward, HIGH);
  digitalWrite(RightMotorForward, HIGH);

  digitalWrite(LeftMotorForward, LOW);
  digitalWrite(RightMotorBackward, LOW);

  delay(500);

  digitalWrite(LeftMotorForward, HIGH);
  digitalWrite(RightMotorForward, HIGH);

  digitalWrite(LeftMotorBackward, LOW);
  digitalWrite(RightMotorBackward, LOW);
}
