Makers (Cubecon) #3 Gyro Sensor, Bluetooth & IR Transmit

A Bongilcheon High School Makers club's team project.

BeginnerWork in progress1 hour1,217
Makers (Cubecon) #3 Gyro Sensor, Bluetooth & IR Transmit

Things used in this project

Hardware components

Arduino Nano R3
Arduino Nano R3
×3
Breadboard (generic)
Breadboard (generic)
×3
Arduino MPU-6050
×1
HC-06 Bluetooth Module
×2
Arduino RGB LED
×3
Arduino Infrared transmitter
×1
Arduino Infrared receiver
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

Gyro Sensor_Bluetooth_RGB LED

Infrared Transmit_Bluetooth

Infrared Receive_RGB LED

Code

Gyro Sensor_Bluetooth_RGB LED

Arduino
#include<Wire.h>
#include<SoftwareSerial.h>

SoftwareSerial btSerial(7, 8);

const int MPU_addr = 0x68;
int16_t GyX, GyY, GyZ;
int red = 6;
int green = 5;
int blue = 4;

void setup() {
  Wire.begin();
  Wire.beginTransmission(MPU_addr);
  Wire.write(0x6B);
  Wire.write(0);
  Wire.endTransmission(true);
  Serial.begin(9600);
  btSerial.begin(9600);
  pinMode(red, OUTPUT);
  pinMode(green, OUTPUT);
  pinMode(blue, OUTPUT);
}

void loop() {
  gyro();
  led();
}

void gyro() {
  Wire.beginTransmission(MPU_addr);
  Wire.write(0x3B);
  Wire.endTransmission(false);
  Wire.requestFrom(MPU_addr, 14, true);
  GyX = Wire.read() << 8|Wire.read();
  GyY = Wire.read() << 8|Wire.read();
  GyZ = Wire.read() << 8|Wire.read();
  GyX = GyX / 100;
  GyY = GyY / 100;
  GyZ = GyZ / 100;
  Serial.print(F("gyro x,y,z : "));
  Serial.print("| GyX = ");
  Serial.print(GyX);
  Serial.print("| GyY = ");
  Serial.print(GyY);
  Serial.print("| GyZ = ");
  Serial.print(GyZ);
  Serial.println();
  delay(300);
}

void led() {
    if (GyX >= -20 && GyX <= -10) {
    if (GyY >= -10 && GyY <= 0) {
    if (GyZ >= 145 && GyZ <= 155) {
      btSerial.write('A');
      digitalWrite(red, HIGH);
      digitalWrite(green, HIGH);
      digitalWrite(blue, HIGH);
  }
  }
  }
    else if (GyX >= 0 && GyX <= 10) {
    if (GyY >= -175 && GyY <= -165) {
    if (GyZ >= -20 && GyZ <= -10) {
      btSerial.write('B');
      digitalWrite(red, HIGH);
      digitalWrite(green, LOW);
      digitalWrite(blue, LOW);
  }
  }
  }
    else if (GyX >= 165 && GyX <= 175) {
    if (GyY >= -10 && GyY <= 0) {
    if (GyZ >= 10 && GyZ <= 20) {
      btSerial.write('C');
      digitalWrite(red, LOW);
      digitalWrite(green, HIGH);
      digitalWrite(blue, LOW);
  }
  }
  }
    else if (GyX >= -155 && GyX <= -145) {
    if (GyY >= -5 && GyY <= 5) {
    if (GyZ >= -40 && GyZ <= -30) {
      btSerial.write('D');
      digitalWrite(red, LOW);
      digitalWrite(green, LOW);
      digitalWrite(blue, HIGH);
  }
  }
  }
  else {
    btSerial.write('X');
    digitalWrite(red, LOW);
    digitalWrite(green, LOW);
    digitalWrite(blue, LOW);
  }
}

IR Transmit_Bluetooth_RGB LED

Arduino
For convenience purposes, this project uses infrared values except for the Hex code.
However, I recommend you use normally the infrared value of the hex code.
#include <SoftwareSerial.h>
#include <boarddefs.h>
#include <IRremote.h>
#include <IRremoteInt.h>
#include <ir_Lego_PF_BitStreamEncoder.h>

SoftwareSerial btSerial(7, 8);
IRsend irsend;

int red = 6;
int green = 5;
int blue = 4;

void setup() {
  Serial.begin(9600);
  btSerial.begin(9600);
  pinMode(red, OUTPUT);
  pinMode(green, OUTPUT);
  pinMode(blue, OUTPUT);
}
void loop() {
  byte data;
  data = btSerial.read();
  if(data == 'A') {
    irsend.sendNEC(106206, 16);
    digitalWrite(red, HIGH);
    digitalWrite(green, HIGH);
    digitalWrite(blue, HIGH);
  }
  else if(data == 'B') {
    irsend.sendNEC(12495, 16);
    digitalWrite(red, HIGH);
    digitalWrite(green, LOW);
    digitalWrite(blue, LOW);
  }
  else if(data == 'C') {
    irsend.sendNEC(6375, 16);
    digitalWrite(red, LOW);
    digitalWrite(green, HIGH);
    digitalWrite(blue, LOW);
  }
  else if(data == 'D') {
    irsend.sendNEC(31365, 16);
    digitalWrite(red, LOW);
    digitalWrite(green, LOW);
    digitalWrite(blue, HIGH);
  }
  else if(data == 'X') {
    irsend.sendNEC(4335, 16);
    digitalWrite(red, LOW);
    digitalWrite(green, LOW);
    digitalWrite(blue, LOW);
  }
}

IR Receive_RGB LED

Arduino
#include <IRremote.h>

int RECV_PIN = 6;
int red = 10;
int green = 9;
int blue = 8;
int ared = 12495;
int agreen = 6375;
int ablue = 31365;
int awhite = 106206;
int apurple = 12345;
int a;

IRrecv irrecv(RECV_PIN);
decode_results results;

void setup() {
  Serial.begin(9600);
  irrecv.enableIRIn();
  pinMode(red, OUTPUT);
  pinMode(green, OUTPUT);
  pinMode(blue, OUTPUT);
}

void loop() {
  if (irrecv.decode(&results)) {
    Serial.println(results.value, HEX);
    irrecv.resume();
    a = results.value;
    Serial.println(a);
  }
  led();
}

void led() {
  if (a == awhite) {
    digitalWrite(red, HIGH);
    digitalWrite(green, HIGH);
    digitalWrite(blue, HIGH);
  }
  else if (a == ared) {
    digitalWrite(red, HIGH);
    digitalWrite(green, LOW);
    digitalWrite(blue, LOW);
  }
  else if (a == agreen) {
    digitalWrite(red, LOW);
    digitalWrite(green, HIGH);
    digitalWrite(blue, LOW);
  }
  else if (a == ablue) {
    digitalWrite(red, LOW);
    digitalWrite(green, LOW);
    digitalWrite(blue, HIGH);
  }
  else if (a == apurple) {
    digitalWrite(red, HIGH);
    digitalWrite(green, LOW);
    digitalWrite(blue, HIGH);
  }
  else {
    digitalWrite(red, LOW);
    digitalWrite(green, LOW);
    digitalWrite(blue, LOW);
  }
  delay(500);
}
