Drawing Cartoons with Inkscape
Read moreVIDEO
You will need a newer version of Inkscape that can be found here https://inkscape.org/
You will also need the Axidraw Utility that can be found here: https://wiki.evilmadscientist.com/Axidraw_Software_Installation
Step 1: Prepare DocumentWe will create a new document and then use document properties to set the page size. In this case we want a 6" x 6" page.
Step 2: Set and Trace imageWe will paste the image and resize to our page size. If you hold ctrl + shift while resizing, it will keep the aspect ratio and resize from the center.
Once placed we will trace the image to create a vector with the Trace Bitmap tool.
trace bitmap tool
Once we have traced our picture we will change our view to Outline so we can better see what we're doing.
set to outline view
Then we will delete the bitmap image because we do not need it anymore.
outlines view
Be sure you have added the Axidraw Tools to your Inkscape.
Then choose the Hatch fill... tool from Axidraw Utilities
hatch fill
Once the dialog is opened choose your options. The most important options will be:
- Hatch Spacing: this is the spacing between the lines
- Hatch angle: this is the angle from which the lines will be drawn
- Connect Nearby Ends: This will connect the ends making
set hatch options
Ungroup the hatch fill from the outline. You can either click ctrl + shift + g or you can select ungroup from the Object menu. You can now see that there are two seperate objects on the canvas.
Ungroup. *note that there are two objects here
Next we want to Combine the two paths into one. You can either hit ctrl + k or you can select Combine from the Path menu.
combine. *note there are 2 objects selected
Now that all the paths are one object we can take away any curves and convert them to lines. We will use the Approximate Curves by Straight Lines... tool in the Extensions => Modify Path menu. 0.1 is a fine value. You can make the number bigger if you want the lines to be larger.
approximate curves to straight lines
We can now export the gcode from inkscape with the Path to Gcode... tool.
path to gcode
Set filename and directory for the exported file by setting these options:
- File: This will be the filename. You can have the extension be anything you want, but should keep it as 'gcode' as good practice.
- Directory: This is the folder where the file will be saved. You can choose any place you like. If you don't want to choose something like 'C:' would be fine as it will just go in the root directory.
- Add numeric suffix to filename: It is good practice just to leave this checked as it will keep you from overwriting a file if you forget to change something (ask me how I know)
path to gcode first tab
Set Cutting Order and Path Sorting.
- Cutting Order: Subpath by Subpath is fine here, it will ignore if a path is in some other object and will go to wherever is closest.
- Sort paths to reduce rapid distance: this will make the code choose the closest path to whatever is closest. (default is to go by layer order)
path to gcode second tab
Please note that you must have the tab on Path to Gcode for this operation to function correctly
Press Apply and the file will be exported.
A view of the toolpath will now be visible
exported gcode view
You can find the inkscape2scara canvas here: https://floe.evezor.com/ide/666d3aa8a81388b6canv
The program can be run here: https://floe.evezor.com/pyscript/666d3aa8a81388b6canv?core=mpy
In this program we will be taking the Gcode file from inkscape and converting it to a list of orders that Tobor will run.
The program In the program itself you can see that there are a series of GuiCodeEditors and GuiCodeViewers separated by some logic blocks.
The editors and viewers are places we can put and see the code itself and the viewers will actually render their code in the 3Dviewer
Functionally we put the raw gcode from Inkscape in the ink_sender parameter.
From there the Inkscape parameter will convert the gcode to orders and will also change the tool_on and tool_off events to some other orders of our choosing.
After that we have a viewer where we can see the original code after trasformation and we move the code to where we want with a CncTranslator parameter. That parameter also has 3 more connected parameters of type GuiFloat that will allow the input of new values on the fly.
Then there is another Gui3dViewer, called translated; that will show what the robot will actually draw. After that the code is sent to a ScaraKinematics parameter which will do the inverse kinematics transformations that tobor will actually run.
a_output is the final parameter of type Gui3dViewer where we can save and view the actual code that tobor will run.
inscape2scara canvas
running program view
The program can be run here: https://floe.evezor.com/pyscript/666d3aa8a81388b6canv?core=mpy
When running the canvas you can see at the top we have a 3D viewer that will display code in 3D.
We also have a series of Parameters that are imports and viewers for code in various stages of the export.
- a-output: this is where the final code that we will send to Tobor will be created
- ink_sender: this is where we will put the original gcode file from Inkscape
- original: this is what the code looks like after it is imported from the inkscape gcode file, but is now a series of orders
- translated: this is what the code will actually look like when and where Tobor will draw it.
- rotate, x_offset, y_offset: these are the numbers we can put in to move and rotate where the actual drawing will take place.
You may either drop the file into the code editor or you may browse for the file you wish
original gcode view
Now you can see that there is gcode in the viewer. We will now press Submit on the ink_sender parameter to process the file.
We can now see that all the parameters have been populated with code.
after submit all parameters are populated with code
And we can see that the 3dViewer has been populated
untranslated code view
But the file as is will be drawn right under the robot (which we cannot do). So we will change the values to move the drawing.
The drawing is roughly 150mm x 150mm so we will change the value of x_offset to -75 to center and y_offset to -300 to move it way out front.
all codes view
We have also changed the colors of some of the views to better differentiate the different views. Original is still green, the translated view is pink, and the transformed version that tobor will run is in yellow.
transformed file view
We are now ready to export the code in a_output and send to Tobor.
Also note how you can still make out the drawing even though it's the code that is the angle of the joints! It just skews all straight lines to curves.
Step 7: DrawYou are now ready to have Tobor just run the file.
completed drawing
%
(Header)
(Generated by gcodetools from Inkscape.)
(Using default header. To add your own header create file "header" in the output dir.)
M3
(Header end.)
G21 (All units in mm)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X8.821790 Y121.901800
G01 Z-0.125000 F100.0(Penetrate)
G01 X10.360000 Y123.439900 Z-0.125000 F400.000000
G01 X11.170300 Y123.876100 Z-0.125000
G01 X11.464300 Y123.912800 Z-0.125000
G01 X11.419300 Y123.750900 Z-0.125000
G01 X8.611990 Y120.943600 Z-0.125000
G01 X8.293910 Y120.251300 Z-0.125000
G01 X8.338320 Y120.038500 Z-0.125000
G01 X8.537090 Y120.120300 Z-0.125000
G01 X9.924170 Y121.507400 Z-0.125000
G01 X10.052500 Y121.518800 Z-0.125000
G01 X9.941860 Y121.150900 Z-0.125000
G01 X9.398280 Y120.233200 Z-0.125000
G01 X8.612580 Y119.447500 Z-0.125000
G01 X8.426400 Y119.144400 Z-0.125000
G01 X8.409680 Y118.870400 Z-0.125000
G01 X8.533280 Y118.736800 Z-0.125000
G01 X8.768040 Y118.854600 Z-0.125000
G01 X9.382260 Y119.468800 Z-0.125000
G01 X9.606530 Y119.576200 Z-0.125000
G01 X9.707050 Y119.419400 Z-0.125000
G01 X9.667250 Y119.122400 Z-0.125000
G01 X9.470570 Y118.808800 Z-0.125000
G01 X8.970260 Y118.308500 Z-0.125000
G01 X8.795940 Y118.017200 Z-0.125000
G01 X8.805310 Y117.769300 Z-0.125000
G01 X8.954990 Y117.661800 Z-0.125000
G01 X9.201620 Y117.791500 Z-0.125000
G01 X9.622470 Y118.212300 Z-0.125000
G01 X9.862280 Y118.335200 Z-0.125000
G01 X9.996970 Y118.212600 Z-0.125000
G01 X9.991350 Y117.949800 Z-0.125000
G01 X9.810210 Y117.651700 Z-0.125000
G01 X9.454720 Y117.296200 Z-0.125000
G01 X9.285230 Y117.009800 Z-0.125000
G01 X9.305230 Y116.772500 Z-0.125000
G01 X9.465540 Y116.675600 Z-0.125000
G01 X9.717000 Y116.810100 Z-0.125000
G01 X10.024000 Y117.117100 Z-0.125000
G01 X10.270800 Y117.247000 Z-0.125000
G01 X10.421000 Y117.139900 Z-0.125000
G01 X10.430800 Y116.892500 Z-0.125000
G01 X10.256700 Y116.601500 Z-0.125000
G01 X9.991270 Y116.336000 Z-0.125000
G01 X9.824640 Y116.052500 Z-0.125000
G01 X9.850920 Y115.821500 Z-0.125000
G01 X10.017500 Y115.730900 Z-0.125000
G01 X10.271800 Y115.868300 Z-0.125000
G01 X10.504700 Y116.101100 Z-0.125000
G01 X10.755700 Y116.235200 Z-0.125000
G01 X10.915000 Y116.137300 Z-0.125000
G01 X10.934000 Y115.899000 Z-0.125000
G01 X10.764000 Y115.612100 Z-0.125000
G01 X10.556400 Y115.404500 Z-0.125000
G01 X10.391400 Y115.122500 Z-0.125000
G01 X10.421100 Y114.895000 Z-0.125000
G01 X10.591200 Y114.807900 Z-0.125000
G01 X10.847100 Y114.946800 Z-0.125000
G01 X11.032900 Y115.132700 Z-0.125000
G01 X11.286700 Y115.269500 Z-0.125000
G01 X11.452100 Y115.177700 Z-0.125000
G01 X11.477200 Y114.945500 Z-0.125000
G01 X11.310100 Y114.661400 Z-0.125000
G01 X11.139000 Y114.490400 Z-0.125000
G01 X10.974800 Y114.209200 Z-0.125000
G01 X11.006400 Y113.983600 Z-0.125000
G01 X11.178400 Y113.898300 Z-0.125000
G01 X11.435100 Y114.038100 Z-0.125000
G01 X11.597300 Y114.200300 Z-0.125000
G01 X11.852700 Y114.338800 Z-0.125000
G01 X12.021800 Y114.250600 Z-0.125000
G01 X12.050600 Y114.022200 Z-0.125000
G01 X11.885100 Y113.739700 Z-0.125000
G01 X11.732000 Y113.586700 Z-0.125000
G01 X11.568300 Y113.306000 Z-0.125000
G01 X11.600900 Y113.081300 Z-0.125000
G01 X11.773800 Y112.997000 Z-0.125000
G01 X12.030900 Y113.137200 Z-0.125000
G01 X12.179900 Y113.286200 Z-0.125000
G01 X12.436600 Y113.426000 Z-0.125000
G01 X12.608500 Y113.340600 Z-0.125000
G01 X12.640100 Y113.115000 Z-0.125000
G01 X12.475900 Y112.833800 Z-0.125000
G01 X12.331200 Y112.689200 Z-0.125000
G01 X12.167700 Y112.408700 Z-0.125000
G01 X12.200800 Y112.184600 Z-0.125000
G01 X12.374200 Y112.100700 Z-0.125000
G01 X12.631600 Y112.241200 Z-0.125000
G01 X12.776100 Y112.385700 Z-0.125000
G01 X13.033800 Y112.526500 Z-0.125000
G01 X13.208000 Y112.443400 Z-0.125000
G01 X13.241800 Y112.220000 Z-0.125000
G01 X13.078600 Y111.939800 Z-0.125000
G01 X12.933100 Y111.794400 Z-0.125000
G01 X12.769800 Y111.514100 Z-0.125000
G01 X12.803300 Y111.290300 Z-0.125000
G01 X12.977100 Y111.206900 Z-0.125000
G01 X13.234700 Y111.347500 Z-0.125000
G01 X13.384600 Y111.497500 Z-0.125000
G01 X13.643500 Y111.639500 Z-0.125000
G01 X13.820300 Y111.558900 Z-0.125000
G01 X13.856700 Y111.338100 Z-0.125000
G01 X13.694600 Y111.059200 Z-0.125000
G01 X13.536200 Y110.900700 Z-0.125000
G01 X13.372800 Y110.620400 Z-0.125000
G01 X13.406300 Y110.396700 Z-0.125000
G01 X13.580100 Y110.313200 Z-0.125000
G01 X13.837700 Y110.453900 Z-0.125000
G01 X14.006900 Y110.623100 Z-0.125000
G01 X14.267200 Y110.766500 Z-0.125000
G01 X14.447000 Y110.689000 Z-0.125000
G01 X14.486500 Y110.471300 Z-0.125000
G01 X14.325900 Y110.193700 Z-0.125000
G01 X14.139200 Y110.007000 Z-0.125000
G01 X13.975900 Y109.726700 Z-0.125000
G01 X14.009300 Y109.503000 Z-0.125000
G01 X14.183200 Y109.419500 Z-0.125000
G01 X14.440700 Y109.560200 Z-0.125000
G01 X14.648000 Y109.767500 Z-0.125000
G01 X14.909600 Y109.912100 Z-0.125000
G01 X15.092000 Y109.837300 Z-0.125000
G01 X15.134200 Y109.622200 Z-0.125000
G01 X14.974800 Y109.345900 Z-0.125000
G01 X14.742300 Y109.113400 Z-0.125000
G01 X14.578900 Y108.833100 Z-0.125000
G01 X14.612400 Y108.609300 Z-0.125000
G01 X14.786200 Y108.525900 Z-0.125000
G01 X15.043800 Y108.666500 Z-0.125000
G01 X15.309300 Y108.932100 Z-0.125000
G01 X15.573000 Y109.078800 Z-0.125000
G01 X15.760100 Y109.008700 Z-0.125000
G01 X15.807000 Y108.798300 Z-0.125000
G01 X15.649700 Y108.524100 Z-0.125000
G01 X15.345300 Y108.219700 Z-0.125000
G01 X15.181900 Y107.939400 Z-0.125000
G01 X15.215400 Y107.715700 Z-0.125000
G01 X15.389200 Y107.632200 Z-0.125000
G01 X15.646800 Y107.772900 Z-0.125000
G01 X15.997400 Y108.123400 Z-0.125000
G01 X16.263600 Y108.272800 Z-0.125000
G01 X16.456500 Y108.208400 Z-0.125000
G01 X16.509100 Y108.003700 Z-0.125000
G01 X16.354400 Y107.732100 Z-0.125000
G01 X15.802000 Y107.179700 Z-0.125000
G01 X15.419400 Y106.422900 Z-0.125000
G01 X15.419500 Y106.165800 Z-0.125000
G01 X15.598100 Y106.227400 Z-0.125000
G01 X16.724800 Y107.354200 Z-0.125000
G01 X16.995700 Y107.508100 Z-0.125000
G01 X17.198600 Y107.453800 Z-0.125000
G01 X17.261300 Y107.259200 Z-0.125000
G01 X17.111200 Y106.992200 Z-0.125000
G01 X15.394200 Y105.275200 Z-0.125000
G01 X15.011700 Y104.518500 Z-0.125000
G01 X15.011800 Y104.261300 Z-0.125000
G01 X15.190400 Y104.323000 Z-0.125000
G01 X17.521500 Y106.654200 Z-0.125000
G01 X17.802200 Y106.817900 Z-0.125000
G01 X18.026700 Y106.785100 Z-0.125000
G01 X18.110900 Y106.612100 Z-0.125000
G01 X17.970600 Y106.354800 Z-0.125000
G01 X17.516000 Y105.900300 Z-0.125000
G01 X17.454700 Y105.722000 Z-0.125000
G01 X17.712700 Y105.722800 Z-0.125000
G01 X18.470700 Y106.106600 Z-0.125000
G01 X18.509200 Y106.145100 Z-0.125000
G01 X19.381000 Y106.642700 Z-0.125000
G01 X19.717200 Y106.721700 Z-0.125000
G01 X19.691500 Y106.579000 Z-0.125000
G01 X19.247400 Y106.135000 Z-0.125000
G01 X19.175000 Y105.945600 Z-0.125000
G01 X19.408400 Y105.921800 Z-0.125000
G01 X20.130700 Y106.269900 Z-0.125000
G01 X22.574500 Y108.713700 Z-0.125000
G01 X22.776300 Y109.032400 Z-0.125000
G01 X22.827400 Y109.340800 Z-0.125000
G01 X22.738200 Y109.508800 Z-0.125000
G01 X22.519100 Y109.406600 Z-0.125000
G01 X21.490700 Y108.378200 Z-0.125000
G01 X21.297500 Y107.951100 Z-0.125000
G01 X21.265300 Y107.404500 Z-0.125000
G01 X21.373400 Y106.998100 Z-0.125000
G01 X21.601100 Y106.991900 Z-0.125000
G01 X22.601900 Y107.992800 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X20.728700 Y107.544500
G01 Z-0.125000 F100.0(Penetrate)
G01 X21.433300 Y108.519200 Z-0.125000 F400.000000
G01 X21.726400 Y109.461800 Z-0.125000
G01 X21.489000 Y110.407500 Z-0.125000
G01 X20.850200 Y111.976800 Z-0.125000
G01 X18.810300 Y116.145300 Z-0.125000
G01 X16.489300 Y120.285600 Z-0.125000
G01 X15.499300 Y121.819400 Z-0.125000
G01 X14.770100 Y122.715500 Z-0.125000
G01 X13.971900 Y123.367800 Z-0.125000
G01 X13.336300 Y123.620900 Z-0.125000
G01 X12.646000 Y123.495700 Z-0.125000
G01 X11.683500 Y123.013100 Z-0.125000
G01 X10.802000 Y122.396800 Z-0.125000
G01 X10.190200 Y121.672200 Z-0.125000
G01 X9.849100 Y120.823200 Z-0.125000
G01 X9.779650 Y119.833800 Z-0.125000
G01 X9.982880 Y118.687900 Z-0.125000
G01 X10.459800 Y117.369500 Z-0.125000
G01 X12.238700 Y114.150800 Z-0.125000
G01 X14.401900 Y110.971200 Z-0.125000
G01 X16.298000 Y108.578600 Z-0.125000
G01 X17.840500 Y107.071100 Z-0.125000
G01 X18.452100 Y106.679900 Z-0.125000
G01 X18.942800 Y106.546800 Z-0.125000
G01 X19.792600 Y106.839800 Z-0.125000
G01 X20.728700 Y107.544500 Z-0.125000
G01 X20.728700 Y107.544500 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X16.379600 Y104.763800
G01 Z-0.125000 F100.0(Penetrate)
G01 X14.986500 Y103.370800 Z-0.125000 F400.000000
G01 X14.604000 Y102.614100 Z-0.125000
G01 X14.604000 Y102.356900 Z-0.125000
G01 X14.782700 Y102.418600 Z-0.125000
G01 X15.654100 Y103.290000 Z-0.125000
G01 X15.824600 Y103.343600 Z-0.125000
G01 X15.806800 Y103.068600 Z-0.125000
G01 X15.398300 Y102.285900 Z-0.125000
G01 X14.579500 Y101.467100 Z-0.125000
G01 X14.174300 Y100.687700 Z-0.125000
G01 X14.158800 Y100.414900 Z-0.125000
G01 X14.330300 Y100.469500 Z-0.125000
G01 X15.174600 Y101.313800 Z-0.125000
G01 X15.353600 Y101.375900 Z-0.125000
G01 X15.354600 Y101.119600 Z-0.125000
G01 X14.973200 Y100.364100 Z-0.125000
G01 X14.201800 Y99.592600 Z-0.125000
G01 X13.835000 Y98.851700 Z-0.125000
G01 X13.845900 Y98.605300 Z-0.125000
G01 X14.029500 Y98.672000 Z-0.125000
G01 X14.787900 Y99.430400 Z-0.125000
G01 X14.971300 Y99.496900 Z-0.125000
G01 X14.981900 Y99.250200 Z-0.125000
G01 X14.614500 Y98.508700 Z-0.125000
G01 X13.865900 Y97.760000 Z-0.125000
G01 X13.509200 Y97.029200 Z-0.125000
G01 X13.527100 Y96.789800 Z-0.125000
G01 X13.713800 Y96.859600 Z-0.125000
G01 X14.458500 Y97.604200 Z-0.125000
G01 X14.645700 Y97.674500 Z-0.125000
G01 X14.664700 Y97.436300 Z-0.125000
G01 X14.309600 Y96.707000 Z-0.125000
G01 X13.569900 Y95.967300 Z-0.125000
G01 X13.220100 Y95.243400 Z-0.125000
G01 X13.242800 Y95.008800 Z-0.125000
G01 X13.431600 Y95.080700 Z-0.125000
G01 X14.167900 Y95.817000 Z-0.125000
G01 X14.358100 Y95.890300 Z-0.125000
G01 X14.383600 Y95.658500 Z-0.125000
G01 X14.038000 Y94.938700 Z-0.125000
G01 X13.302700 Y94.203400 Z-0.125000
G01 X12.960500 Y93.487000 Z-0.125000
G01 X12.988300 Y93.257600 Z-0.125000
G01 X13.179600 Y93.332000 Z-0.125000
G01 X13.911900 Y94.064300 Z-0.125000
G01 X14.104100 Y94.139500 Z-0.125000
G01 X14.134000 Y93.912200 Z-0.125000
G01 X13.794800 Y93.198800 Z-0.125000
G01 X13.060200 Y92.464200 Z-0.125000
G01 X12.724800 Y91.754700 Z-0.125000
G01 X12.757400 Y91.530000 Z-0.125000
G01 X12.950800 Y91.606400 Z-0.125000
G01 X13.682700 Y92.338400 Z-0.125000
G01 X13.876600 Y92.415300 Z-0.125000
G01 X13.910200 Y92.191700 Z-0.125000
G01 X13.576300 Y91.483700 Z-0.125000
G01 X12.843200 Y90.750500 Z-0.125000
G01 X12.512200 Y90.045300 Z-0.125000
G01 X12.547700 Y89.823600 Z-0.125000
G01 X12.742500 Y89.901400 Z-0.125000
G01 X13.476500 Y90.635500 Z-0.125000
G01 X13.671900 Y90.714000 Z-0.125000
G01 X13.709000 Y90.493800 Z-0.125000
G01 X13.380200 Y89.790800 Z-0.125000
G01 X12.645200 Y89.055800 Z-0.125000
G01 X12.318200 Y88.354600 Z-0.125000
G01 X12.356500 Y88.135700 Z-0.125000
G01 X12.552500 Y88.214700 Z-0.125000
G01 X13.291400 Y88.953600 Z-0.125000
G01 X13.488300 Y89.033600 Z-0.125000
G01 X13.528700 Y88.816800 Z-0.125000
G01 X13.204700 Y88.118600 Z-0.125000
G01 X12.464000 Y87.377900 Z-0.125000
G01 X12.140800 Y86.680500 Z-0.125000
G01 X12.181600 Y86.464100 Z-0.125000
G01 X12.378800 Y86.544300 Z-0.125000
G01 X13.126100 Y87.291700 Z-0.125000
G01 X13.324500 Y87.373100 Z-0.125000
G01 X13.368100 Y87.159500 Z-0.125000
G01 X13.048900 Y86.466100 Z-0.125000
G01 X12.298000 Y85.715100 Z-0.125000
G01 X11.978100 Y85.021100 Z-0.125000
G01 X12.021300 Y84.807100 Z-0.125000
G01 X12.219600 Y84.888400 Z-0.125000
G01 X12.980000 Y85.648800 Z-0.125000
G01 X13.179900 Y85.731800 Z-0.125000
G01 X13.226700 Y85.521300 Z-0.125000
G01 X12.912100 Y84.832500 Z-0.125000
G01 X12.145400 Y84.065900 Z-0.125000
G01 X11.828800 Y83.375100 Z-0.125000
G01 X11.874200 Y83.163200 Z-0.125000
G01 X12.073400 Y83.245500 Z-0.125000
G01 X12.852800 Y84.024900 Z-0.125000
G01 X13.054100 Y84.109300 Z-0.125000
G01 X13.104100 Y83.902000 Z-0.125000
G01 X12.794200 Y83.217900 Z-0.125000
G01 X12.005000 Y82.428700 Z-0.125000
G01 X11.691300 Y81.740900 Z-0.125000
G01 X11.738800 Y81.531100 Z-0.125000
G01 X11.938900 Y81.614300 Z-0.125000
G01 X12.744500 Y82.419900 Z-0.125000
G01 X12.947300 Y82.505700 Z-0.125000
G01 X13.000600 Y82.301800 Z-0.125000
G01 X12.695400 Y81.622500 Z-0.125000
G01 X11.875400 Y80.802500 Z-0.125000
G01 X11.564600 Y80.117400 Z-0.125000
G01 X11.614000 Y79.909600 Z-0.125000
G01 X11.815000 Y79.993700 Z-0.125000
G01 X12.655600 Y80.834300 Z-0.125000
G01 X12.860000 Y80.921700 Z-0.125000
G01 X12.916700 Y80.721200 Z-0.125000
G01 X12.616400 Y80.046800 Z-0.125000
G01 X11.755800 Y79.186100 Z-0.125000
G01 X11.447500 Y78.503600 Z-0.125000
G01 X11.498700 Y78.297600 Z-0.125000
G01 X11.700500 Y78.382500 Z-0.125000
G01 X12.583000 Y79.265000 Z-0.125000
G01 X12.788300 Y79.353300 Z-0.125000
G01 X12.847100 Y79.154900 Z-0.125000
G01 X12.549900 Y78.483500 Z-0.125000
G01 X11.645100 Y77.578700 Z-0.125000
G01 X11.338100 Y76.897500 Z-0.125000
G01 X11.390100 Y76.692300 Z-0.125000
G01 X11.592300 Y76.777600 Z-0.125000
G01 X12.516700 Y77.702000 Z-0.125000
G01 X12.722300 Y77.790700 Z-0.125000
G01 X12.781700 Y77.592800 Z-0.125000
G01 X12.485500 Y76.922400 Z-0.125000
G01 X11.539500 Y75.976400 Z-0.125000
G01 X11.232400 Y75.295200 Z-0.125000
G01 X11.284400 Y75.089900 Z-0.125000
G01 X11.486700 Y75.175200 Z-0.125000
G01 X12.458700 Y76.147300 Z-0.125000
G01 X12.665000 Y76.236700 Z-0.125000
G01 X12.726000 Y76.040400 Z-0.125000
G01 X12.432000 Y75.372200 Z-0.125000
G01 X11.433900 Y74.374100 Z-0.125000
G01 X11.126800 Y73.692900 Z-0.125000
G01 X11.178800 Y73.487600 Z-0.125000
G01 X11.381000 Y73.572900 Z-0.125000
G01 X12.411300 Y74.603100 Z-0.125000
G01 X12.620300 Y74.695200 Z-0.125000
G01 X12.687200 Y74.504900 Z-0.125000
G01 X12.402000 Y73.845400 Z-0.125000
G01 X11.328300 Y72.771700 Z-0.125000
G01 X11.021200 Y72.090500 Z-0.125000
G01 X11.073200 Y71.885300 Z-0.125000
G01 X11.275500 Y71.970600 Z-0.125000
G01 X12.410600 Y73.105700 Z-0.125000
G01 X12.627500 Y73.205700 Z-0.125000
G01 X12.711900 Y73.032800 Z-0.125000
G01 X12.655900 Y72.719600 Z-0.125000
G01 X12.451800 Y72.398600 Z-0.125000
G01 X10.337800 Y70.284500 Z-0.125000
G01 X10.300800 Y70.130600 Z-0.125000
G01 X10.612300 Y70.184800 Z-0.125000
G01 X11.448000 Y70.646400 Z-0.125000
G01 X12.580600 Y71.779000 Z-0.125000
G01 X12.846300 Y71.927800 Z-0.125000
G01 X13.038000 Y71.862200 Z-0.125000
G01 X13.089300 Y71.656300 Z-0.125000
G01 X12.934100 Y71.384100 Z-0.125000
G01 X12.471700 Y70.921800 Z-0.125000
G01 X12.408000 Y70.741100 Z-0.125000
G01 X12.660800 Y70.736700 Z-0.125000
G01 X13.411100 Y71.112800 Z-0.125000
G01 X13.819800 Y71.521500 Z-0.125000
G01 X14.523800 Y71.851300 Z-0.125000
G01 X14.744700 Y71.815000 Z-0.125000
G01 X14.666600 Y71.619900 Z-0.125000
G01 X14.271800 Y71.225100 Z-0.125000
G01 X14.182600 Y71.019000 Z-0.125000
G01 X14.379500 Y70.958600 Z-0.125000
G01 X15.048500 Y71.253400 Z-0.125000
G01 X15.323300 Y71.528300 Z-0.125000
G01 X15.625900 Y71.713900 Z-0.125000
G01 X15.898700 Y71.729500 Z-0.125000
G01 X16.031100 Y71.604700 Z-0.125000
G01 X15.912800 Y71.369400 Z-0.125000
G01 X15.746500 Y71.203100 Z-0.125000
G01 X15.632800 Y70.972500 Z-0.125000
G01 X15.775500 Y70.857900 Z-0.125000
G01 X16.058500 Y70.883700 Z-0.125000
G01 X16.365800 Y71.074000 Z-0.125000
G01 X16.445700 Y71.153900 Z-0.125000
G01 X16.733000 Y71.324400 Z-0.125000
G01 X16.972400 Y71.306500 Z-0.125000
G01 X17.071400 Y71.148200 Z-0.125000
G01 X16.937800 Y70.897700 Z-0.125000
G01 X16.905100 Y70.865000 Z-0.125000
G01 X16.766000 Y70.609000 Z-0.125000
G01 X16.853000 Y70.438700 Z-0.125000
G01 X17.080300 Y70.408800 Z-0.125000
G01 X17.362200 Y70.573800 Z-0.125000
G01 X17.382300 Y70.593900 Z-0.125000
G01 X17.655400 Y70.750000 Z-0.125000
G01 X17.863300 Y70.700600 Z-0.125000
G01 X17.930800 Y70.511000 Z-0.125000
G01 X17.782900 Y70.246100 Z-0.125000
G01 X17.733600 Y70.196800 Z-0.125000
G01 X17.567900 Y69.914200 Z-0.125000
G01 X17.596300 Y69.685300 Z-0.125000
G01 X17.765000 Y69.596700 Z-0.125000
G01 X18.020200 Y69.735100 Z-0.125000
G01 X18.131300 Y69.846100 Z-0.125000
G01 X18.385300 Y69.983200 Z-0.125000
G01 X18.551300 Y69.892000 Z-0.125000
G01 X18.577000 Y69.660400 Z-0.125000
G01 X18.410000 Y69.376500 Z-0.125000
G01 X18.238700 Y69.205200 Z-0.125000
G01 X18.045600 Y68.895200 Z-0.125000
G01 X18.013600 Y68.605900 Z-0.125000
G01 X18.122000 Y68.457000 Z-0.125000
G01 X18.349800 Y68.567900 Z-0.125000
G01 X18.584400 Y68.802500 Z-0.125000
G01 X18.813300 Y68.914500 Z-0.125000
G01 X18.924200 Y68.768100 Z-0.125000
G01 X18.894700 Y68.481400 Z-0.125000
G01 X18.702700 Y68.172500 Z-0.125000
G01 X17.956300 Y67.426000 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X19.025500 Y67.746900
G01 Z-0.125000 F100.0(Penetrate)
G01 X11.923300 Y60.644800 Z-0.125000 F400.000000
G01 X11.763700 Y60.368200 Z-0.125000
G01 X11.805400 Y60.152700 Z-0.125000
G01 X11.987500 Y60.077500 Z-0.125000
G01 X12.248800 Y60.221900 Z-0.125000
G01 X13.087700 Y61.060700 Z-0.125000
G01 X13.308600 Y61.164700 Z-0.125000
G01 X13.401700 Y61.000600 Z-0.125000
G01 X13.354500 Y60.696200 Z-0.125000
G01 X13.154500 Y60.379200 Z-0.125000
G01 X12.453900 Y59.678700 Z-0.125000
G01 X12.268300 Y59.376100 Z-0.125000
G01 X12.252700 Y59.103300 Z-0.125000
G01 X12.377500 Y58.970800 Z-0.125000
G01 X12.612800 Y59.089100 Z-0.125000
G01 X13.221200 Y59.697600 Z-0.125000
G01 X13.442100 Y59.801600 Z-0.125000
G01 X13.535300 Y59.637500 Z-0.125000
G01 X13.488100 Y59.333000 Z-0.125000
G01 X13.288000 Y59.016100 Z-0.125000
G01 X12.748500 Y58.476600 Z-0.125000
G01 X12.557300 Y58.168400 Z-0.125000
G01 X12.529600 Y57.883400 Z-0.125000
G01 X12.642100 Y57.738700 Z-0.125000
G01 X12.871900 Y57.851500 Z-0.125000
G01 X13.354800 Y58.334500 Z-0.125000
G01 X13.575900 Y58.438600 Z-0.125000
G01 X13.669300 Y58.274800 Z-0.125000
G01 X13.622400 Y57.970700 Z-0.125000
G01 X13.422500 Y57.653900 Z-0.125000
G01 X12.988600 Y57.219900 Z-0.125000
G01 X12.795800 Y56.910200 Z-0.125000
G01 X12.764400 Y56.621500 Z-0.125000
G01 X12.873300 Y56.473200 Z-0.125000
G01 X13.101400 Y56.584400 Z-0.125000
G01 X13.498300 Y56.981300 Z-0.125000
G01 X13.722400 Y57.088400 Z-0.125000
G01 X13.822300 Y56.931100 Z-0.125000
G01 X13.781900 Y56.633500 Z-0.125000
G01 X13.585000 Y56.319600 Z-0.125000
G01 X13.211700 Y55.946300 Z-0.125000
G01 X13.018400 Y55.636100 Z-0.125000
G01 X12.986200 Y55.346600 Z-0.125000
G01 X13.094200 Y55.197400 Z-0.125000
G01 X13.321900 Y55.308200 Z-0.125000
G01 X13.680800 Y55.667100 Z-0.125000
G01 X13.907800 Y55.777200 Z-0.125000
G01 X14.014300 Y55.626400 Z-0.125000
G01 X13.980500 Y55.335300 Z-0.125000
G01 X13.786500 Y55.024500 Z-0.125000
G01 X13.433300 Y54.671300 Z-0.125000
G01 X13.240600 Y54.361600 Z-0.125000
G01 X13.209600 Y54.073300 Z-0.125000
G01 X13.318800 Y53.925300 Z-0.125000
G01 X13.547100 Y54.036700 Z-0.125000
G01 X13.896200 Y54.385800 Z-0.125000
G01 X14.125000 Y54.497600 Z-0.125000
G01 X14.235400 Y54.350800 Z-0.125000
G01 X14.205500 Y54.063700 Z-0.125000
G01 X14.013400 Y53.754600 Z-0.125000
G01 X13.660300 Y53.401500 Z-0.125000
G01 X13.469000 Y53.093300 Z-0.125000
G01 X13.441200 Y52.808200 Z-0.125000
G01 X13.553600 Y52.663400 Z-0.125000
G01 X13.783300 Y52.776100 Z-0.125000
G01 X14.135000 Y53.127900 Z-0.125000
G01 X14.365300 Y53.241200 Z-0.125000
G01 X14.479100 Y53.097800 Z-0.125000
G01 X14.452500 Y52.814000 Z-0.125000
G01 X14.261900 Y52.506400 Z-0.125000
G01 X13.906300 Y52.151000 Z-0.125000
G01 X13.715800 Y51.843000 Z-0.125000
G01 X13.689700 Y51.560000 Z-0.125000
G01 X13.803800 Y51.417000 Z-0.125000
G01 X14.034300 Y51.530000 Z-0.125000
G01 X14.393900 Y51.890000 Z-0.125000
G01 X14.625400 Y52.005000 Z-0.125000
G01 X14.741800 Y51.864000 Z-0.125000
G01 X14.717900 Y51.583000 Z-0.125000
G01 X14.528400 Y51.276000 Z-0.125000
G01 X14.166400 Y50.914000 Z-0.125000
G01 X13.976800 Y50.608000 Z-0.125000
G01 X13.952700 Y50.326000 Z-0.125000
G01 X14.068800 Y50.185000 Z-0.125000
G01 X14.300100 Y50.300000 Z-0.125000
G01 X14.669700 Y50.669000 Z-0.125000
G01 X14.902300 Y50.785000 Z-0.125000
G01 X15.021000 Y50.646000 Z-0.125000
G01 X14.999400 Y50.367000 Z-0.125000
G01 X14.811000 Y50.062000 Z-0.125000
G01 X14.441300 Y49.692000 Z-0.125000
G01 X14.252900 Y49.387000 Z-0.125000
G01 X14.231200 Y49.108000 Z-0.125000
G01 X14.349900 Y48.970000 Z-0.125000
G01 X14.582400 Y49.085000 Z-0.125000
G01 X14.960500 Y49.463000 Z-0.125000
G01 X15.194300 Y49.580000 Z-0.125000
G01 X15.316000 Y49.445000 Z-0.125000
G01 X15.297300 Y49.169000 Z-0.125000
G01 X15.110200 Y48.865000 Z-0.125000
G01 X14.730900 Y48.485000 Z-0.125000
G01 X14.543900 Y48.181000 Z-0.125000
G01 X14.525400 Y47.906000 Z-0.125000
G01 X14.647200 Y47.770000 Z-0.125000
G01 X14.881100 Y47.887000 Z-0.125000
G01 X15.264800 Y48.271000 Z-0.125000
G01 X15.499900 Y48.389000 Z-0.125000
G01 X15.624300 Y48.256000 Z-0.125000
G01 X15.608400 Y47.983000 Z-0.125000
G01 X15.422600 Y47.680000 Z-0.125000
G01 X15.035600 Y47.293000 Z-0.125000
G01 X14.850000 Y46.991000 Z-0.125000
G01 X14.834600 Y46.718000 Z-0.125000
G01 X14.959500 Y46.586000 Z-0.125000
G01 X15.194900 Y46.704000 Z-0.125000
G01 X15.581900 Y47.091000 Z-0.125000
G01 X15.818200 Y47.211000 Z-0.125000
G01 X15.945300 Y47.080000 Z-0.125000
G01 X15.932100 Y46.810000 Z-0.125000
G01 X15.747500 Y46.508000 Z-0.125000
G01 X15.355400 Y46.116000 Z-0.125000
G01 X15.171300 Y45.815000 Z-0.125000
G01 X15.159100 Y45.546000 Z-0.125000
G01 X15.287200 Y45.417000 Z-0.125000
G01 X15.524000 Y45.537000 Z-0.125000
G01 X15.913100 Y45.926000 Z-0.125000
G01 X16.150400 Y46.046000 Z-0.125000
G01 X16.279500 Y45.918000 Z-0.125000
G01 X16.268300 Y45.649000 Z-0.125000
G01 X16.084600 Y45.349000 Z-0.125000
G01 X15.692500 Y44.957000 Z-0.125000
G01 X15.509600 Y44.657000 Z-0.125000
G01 X15.500100 Y44.390000 Z-0.125000
G01 X15.630900 Y44.264000 Z-0.125000
G01 X15.869000 Y44.385000 Z-0.125000
G01 X16.258000 Y44.774000 Z-0.125000
G01 X16.496000 Y44.895000 Z-0.125000
G01 X16.626600 Y44.768000 Z-0.125000
G01 X16.617000 Y44.501000 Z-0.125000
G01 X16.434000 Y44.202000 Z-0.125000
G01 X16.047000 Y43.815000 Z-0.125000
G01 X15.865200 Y43.516000 Z-0.125000
G01 X15.858100 Y43.251000 Z-0.125000
G01 X15.991300 Y43.127000 Z-0.125000
G01 X16.230500 Y43.250000 Z-0.125000
G01 X16.615400 Y43.635000 Z-0.125000
G01 X16.854200 Y43.756000 Z-0.125000
G01 X16.986700 Y43.632000 Z-0.125000
G01 X16.978800 Y43.367000 Z-0.125000
G01 X16.796700 Y43.068000 Z-0.125000
G01 X16.418200 Y42.689000 Z-0.125000
G01 X16.237600 Y42.391000 Z-0.125000
G01 X16.233100 Y42.130000 Z-0.125000
G01 X16.369000 Y42.008000 Z-0.125000
G01 X16.609300 Y42.132000 Z-0.125000
G01 X16.985700 Y42.508000 Z-0.125000
G01 X17.225900 Y42.631000 Z-0.125000
G01 X17.361200 Y42.510000 Z-0.125000
G01 X17.356300 Y42.247000 Z-0.125000
G01 X17.175500 Y41.950000 Z-0.125000
G01 X16.807100 Y41.581000 Z-0.125000
G01 X16.627800 Y41.285000 Z-0.125000
G01 X16.626200 Y41.026000 Z-0.125000
G01 X16.764800 Y40.908000 Z-0.125000
G01 X17.006500 Y41.032000 Z-0.125000
G01 X17.370100 Y41.396000 Z-0.125000
G01 X17.611700 Y41.521000 Z-0.125000
G01 X17.750100 Y41.402000 Z-0.125000
G01 X17.748300 Y41.143000 Z-0.125000
G01 X17.568900 Y40.846000 Z-0.125000
G01 X17.214900 Y40.492000 Z-0.125000
G01 X17.037000 Y40.197000 Z-0.125000
G01 X17.038400 Y39.942000 Z-0.125000
G01 X17.180200 Y39.826000 Z-0.125000
G01 X17.423300 Y39.952000 Z-0.125000
G01 X17.770100 Y40.299000 Z-0.125000
G01 X18.013200 Y40.425000 Z-0.125000
G01 X18.155100 Y40.310000 Z-0.125000
G01 X18.156700 Y40.054000 Z-0.125000
G01 X17.978800 Y39.760000 Z-0.125000
G01 X17.642900 Y39.424000 Z-0.125000
G01 X17.466700 Y39.130000 Z-0.125000
G01 X17.472000 Y38.879000 Z-0.125000
G01 X17.617700 Y38.767000 Z-0.125000
G01 X17.862400 Y38.895000 Z-0.125000
G01 X18.187500 Y39.220000 Z-0.125000
G01 X18.431900 Y39.347000 Z-0.125000
G01 X18.576800 Y39.235000 Z-0.125000
G01 X18.581300 Y38.982000 Z-0.125000
G01 X18.404800 Y38.689000 Z-0.125000
G01 X18.090000 Y38.374000 Z-0.125000
G01 X17.916100 Y38.083000 Z-0.125000
G01 X17.926300 Y37.836000 Z-0.125000
G01 X18.076800 Y37.729000 Z-0.125000
G01 X18.323900 Y37.859000 Z-0.125000
G01 X18.627800 Y38.163000 Z-0.125000
G01 X18.874100 Y38.293000 Z-0.125000
G01 X19.023000 Y38.184000 Z-0.125000
G01 X19.031700 Y37.936000 Z-0.125000
G01 X18.857000 Y37.644000 Z-0.125000
G01 X18.564000 Y37.351000 Z-0.125000
G01 X18.392100 Y37.062000 Z-0.125000
G01 X18.406700 Y36.820000 Z-0.125000
G01 X18.561700 Y36.718000 Z-0.125000
G01 X18.810800 Y36.850000 Z-0.125000
G01 X19.093500 Y37.132000 Z-0.125000
G01 X19.342000 Y37.264000 Z-0.125000
G01 X19.496000 Y37.161000 Z-0.125000
G01 X19.509700 Y36.917000 Z-0.125000
G01 X19.337300 Y36.628000 Z-0.125000
G01 X19.064300 Y36.355000 Z-0.125000
G01 X18.894800 Y36.068000 Z-0.125000
G01 X18.914600 Y35.831000 Z-0.125000
G01 X19.074800 Y35.734000 Z-0.125000
G01 X19.326200 Y35.868000 Z-0.125000
G01 X19.581500 Y36.124000 Z-0.125000
G01 X19.830500 Y36.256000 Z-0.125000
G01 X19.985500 Y36.154000 Z-0.125000
G01 X20.000200 Y35.911000 Z-0.125000
G01 X19.828300 Y35.622000 Z-0.125000
G01 X19.596200 Y35.390000 Z-0.125000
G01 X19.429200 Y35.106000 Z-0.125000
G01 X19.454600 Y34.874000 Z-0.125000
G01 X19.620300 Y34.783000 Z-0.125000
G01 X19.874200 Y34.920000 Z-0.125000
G01 X20.081400 Y35.127000 Z-0.125000
G01 X20.332600 Y35.261000 Z-0.125000
G01 X20.492300 Y35.164000 Z-0.125000
G01 X20.511700 Y34.926000 Z-0.125000
G01 X20.342000 Y34.639000 Z-0.125000
G01 X20.155500 Y34.453000 Z-0.125000
G01 X19.988900 Y34.169000 Z-0.125000
G01 X20.015500 Y33.938000 Z-0.125000
G01 X20.182300 Y33.848000 Z-0.125000
G01 X20.436700 Y33.986000 Z-0.125000
G01 X20.614000 Y34.163000 Z-0.125000
G01 X20.869600 Y34.302000 Z-0.125000
G01 X21.039200 Y34.214000 Z-0.125000
G01 X21.068400 Y33.986000 Z-0.125000
G01 X20.903100 Y33.704000 Z-0.125000
G01 X20.718000 Y33.518000 Z-0.125000
G01 X20.551500 Y33.235000 Z-0.125000
G01 X20.578000 Y33.004000 Z-0.125000
G01 X20.744800 Y32.914000 Z-0.125000
G01 X20.999300 Y33.051000 Z-0.125000
G01 X21.226000 Y33.278000 Z-0.125000
G01 X21.497000 Y33.432000 Z-0.125000
G01 X21.700400 Y33.378000 Z-0.125000
G01 X21.763500 Y33.184000 Z-0.125000
G01 X21.613600 Y32.917000 Z-0.125000
G01 X21.280500 Y32.584000 Z-0.125000
G01 X21.114000 Y32.301000 Z-0.125000
G01 X21.140500 Y32.070000 Z-0.125000
G01 X21.307400 Y31.980000 Z-0.125000
G01 X21.561800 Y32.117000 Z-0.125000
G01 X22.162400 Y32.718000 Z-0.125000
G01 X23.004200 Y33.185000 Z-0.125000
G01 X23.319900 Y33.244000 Z-0.125000
G01 X23.284800 Y33.092000 Z-0.125000
G01 X21.843100 Y31.650000 Z-0.125000
G01 X21.643900 Y31.334000 Z-0.125000
G01 X21.598600 Y31.031000 Z-0.125000
G01 X21.693600 Y30.869000 Z-0.125000
G01 X21.915300 Y30.974000 Z-0.125000
G01 X24.342800 Y33.401000 Z-0.125000
G01 X25.070500 Y33.755000 Z-0.125000
G01 X25.307800 Y33.735000 Z-0.125000
G01 X25.237000 Y33.547000 Z-0.125000
G01 X24.827800 Y33.138000 Z-0.125000
G01 X24.761000 Y32.954000 Z-0.125000
G01 X25.007100 Y32.943000 Z-0.125000
G01 X25.747700 Y33.310000 Z-0.125000
G01 X25.987700 Y33.550000 Z-0.125000
G01 X26.299200 Y33.744000 Z-0.125000
G01 X26.591600 Y33.779000 Z-0.125000
G01 X26.743600 Y33.674000 Z-0.125000
G01 X26.634100 Y33.448000 Z-0.125000
G01 X26.459500 Y33.273000 Z-0.125000
G01 X26.350000 Y33.047000 Z-0.125000
G01 X26.501900 Y32.941000 Z-0.125000
G01 X26.794200 Y32.976000 Z-0.125000
G01 X27.105700 Y33.171000 Z-0.125000
G01 X27.178300 Y33.244000 Z-0.125000
G01 X27.460600 Y33.409000 Z-0.125000
G01 X27.688900 Y33.380000 Z-0.125000
G01 X27.776900 Y33.211000 Z-0.125000
G01 X27.638300 Y32.955000 Z-0.125000
G01 X27.618300 Y32.935000 Z-0.125000
G01 X27.482500 Y32.683000 Z-0.125000
G01 X27.557900 Y32.501000 Z-0.125000
G01 X27.766900 Y32.452000 Z-0.125000
G01 X28.031900 Y32.601000 Z-0.125000
G01 X28.031900 Y32.601000 Z-0.125000
G01 X28.280400 Y32.732000 Z-0.125000
G01 X28.452800 Y32.647000 Z-0.125000
G01 X28.491700 Y32.429000 Z-0.125000
G01 X28.339300 Y32.160000 Z-0.125000
G01 X28.338000 Y32.159000 Z-0.125000
G01 X28.168800 Y31.872000 Z-0.125000
G01 X28.172300 Y31.619000 Z-0.125000
G01 X28.310100 Y31.499000 Z-0.125000
G01 X28.543700 Y31.616000 Z-0.125000
G01 X28.567000 Y31.639000 Z-0.125000
G01 X28.805300 Y31.761000 Z-0.125000
G01 X28.936700 Y31.635000 Z-0.125000
G01 X28.927800 Y31.369000 Z-0.125000
G01 X28.745100 Y31.069000 Z-0.125000
G01 X28.670300 Y30.994000 Z-0.125000
G01 X28.467200 Y30.674000 Z-0.125000
G01 X28.413200 Y30.363000 Z-0.125000
G01 X28.499600 Y30.192000 Z-0.125000
G01 X28.717500 Y30.293000 Z-0.125000
G01 X28.863100 Y30.439000 Z-0.125000
G01 X29.082900 Y30.541000 Z-0.125000
G01 X29.173600 Y30.375000 Z-0.125000
G01 X29.124000 Y30.068000 Z-0.125000
G01 X28.922900 Y29.750000 Z-0.125000
G01 X28.703500 Y29.531000 Z-0.125000
G01 X28.394500 Y28.847000 Z-0.125000
G01 X28.445100 Y28.641000 Z-0.125000
G01 X28.646700 Y28.725000 Z-0.125000
G01 X28.934600 Y29.013000 Z-0.125000
G01 X29.147200 Y29.109000 Z-0.125000
G01 X29.222000 Y28.927000 Z-0.125000
G01 X28.948100 Y28.278000 Z-0.125000
G01 X28.552500 Y27.883000 Z-0.125000
G01 X28.214300 Y27.171000 Z-0.125000
G01 X28.244900 Y26.944000 Z-0.125000
G01 X28.437400 Y27.019000 Z-0.125000
G01 X29.035300 Y27.617000 Z-0.125000
G01 X29.285900 Y27.751000 Z-0.125000
G01 X29.444300 Y27.652000 Z-0.125000
G01 X29.462300 Y27.413000 Z-0.125000
G01 X29.292000 Y27.126000 Z-0.125000
G01 X28.022800 Y25.856000 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X32.011800 Y29.670000
G01 Z-0.125000 F100.0(Penetrate)
G01 X30.351600 Y31.671000 Z-0.125000 F400.000000
G01 X28.768900 Y34.158000 Z-0.125000
G01 X27.276800 Y37.097000 Z-0.125000
G01 X25.888500 Y40.453000 Z-0.125000
G01 X24.617100 Y44.191000 Z-0.125000
G01 X23.475700 Y48.274000 Z-0.125000
G01 X22.477400 Y52.670200 Z-0.125000
G01 X21.635200 Y57.342600 Z-0.125000
G01 X21.072600 Y62.362300 Z-0.125000
G01 X20.795600 Y68.257200 Z-0.125000
G01 X20.789200 Y74.748000 Z-0.125000
G01 X21.038200 Y81.554900 Z-0.125000
G01 X21.527600 Y88.398600 Z-0.125000
G01 X22.242200 Y94.999300 Z-0.125000
G01 X23.166800 Y101.077700 Z-0.125000
G01 X24.286400 Y106.354100 Z-0.125000
G01 X25.221700 Y109.694500 Z-0.125000
G01 X26.288600 Y112.890800 Z-0.125000
G01 X27.458900 Y115.885900 Z-0.125000
G01 X28.704400 Y118.622400 Z-0.125000
G01 X29.996900 Y121.042900 Z-0.125000
G01 X31.308300 Y123.090100 Z-0.125000
G01 X32.610200 Y124.706900 Z-0.125000
G01 X33.874600 Y125.835700 Z-0.125000
G01 X35.341700 Y126.863300 Z-0.125000
G01 X33.178700 Y126.863300 Z-0.125000
G01 X31.890000 Y126.755800 Z-0.125000
G01 X30.556600 Y126.444400 Z-0.125000
G01 X29.208000 Y125.945700 Z-0.125000
G01 X27.873300 Y125.276300 Z-0.125000
G01 X26.581900 Y124.453000 Z-0.125000
G01 X25.363000 Y123.492300 Z-0.125000
G01 X24.245800 Y122.410800 Z-0.125000
G01 X23.259700 Y121.225300 Z-0.125000
G01 X21.561800 Y118.706900 Z-0.125000
G01 X21.064200 Y117.697100 Z-0.125000
G01 X20.787000 Y116.782000 Z-0.125000
G01 X20.719900 Y115.907900 Z-0.125000
G01 X20.852600 Y115.021100 Z-0.125000
G01 X21.676000 Y112.994500 Z-0.125000
G01 X22.608400 Y110.815300 Z-0.125000
G01 X22.996200 Y109.210000 Z-0.125000
G01 X22.894900 Y108.561700 Z-0.125000
G01 X22.609300 Y107.930500 Z-0.125000
G01 X21.593100 Y106.805300 Z-0.125000
G01 X20.164300 Y106.004900 Z-0.125000
G01 X19.363000 Y105.780000 Z-0.125000
G01 X18.539700 Y105.700200 Z-0.125000
G01 X17.528100 Y105.621500 Z-0.125000
G01 X16.866300 Y105.300800 Z-0.125000
G01 X16.414100 Y104.611000 Z-0.125000
G01 X16.031800 Y103.425200 Z-0.125000
G01 X15.028100 Y98.780200 Z-0.125000
G01 X14.144600 Y93.004400 Z-0.125000
G01 X13.453700 Y86.653600 Z-0.125000
G01 X13.027300 Y80.283800 Z-0.125000
G01 X12.831600 Y75.265600 Z-0.125000
G01 X12.864200 Y72.691600 Z-0.125000
G01 X12.991300 Y72.088000 Z-0.125000
G01 X13.205800 Y71.815500 Z-0.125000
G01 X13.517900 Y71.781000 Z-0.125000
G01 X13.937600 Y71.891200 Z-0.125000
G01 X14.653200 Y72.016400 Z-0.125000
G01 X15.420500 Y71.975600 Z-0.125000
G01 X16.955200 Y71.474600 Z-0.125000
G01 X18.232000 Y70.545900 Z-0.125000
G01 X18.676700 Y69.970300 Z-0.125000
G01 X18.940800 Y69.346900 Z-0.125000
G01 X19.157600 Y67.721400 Z-0.125000
G01 X19.067400 Y67.022700 Z-0.125000
G01 X18.829100 Y66.368100 Z-0.125000
G01 X17.861100 Y65.096400 Z-0.125000
G01 X16.159400 Y63.715500 Z-0.125000
G01 X13.457500 Y61.786900 Z-0.125000
G01 X13.822900 Y58.058800 Z-0.125000
G01 X14.605700 Y53.123400 Z-0.125000
G01 X15.959300 Y47.515000 Z-0.125000
G01 X17.665700 Y42.024000 Z-0.125000
G01 X19.507400 Y37.440000 Z-0.125000
G01 X20.668700 Y35.109000 Z-0.125000
G01 X21.514700 Y33.752000 Z-0.125000
G01 X22.189700 Y33.187000 Z-0.125000
G01 X22.838300 Y33.231000 Z-0.125000
G01 X24.300800 Y33.738000 Z-0.125000
G01 X25.593100 Y33.963000 Z-0.125000
G01 X26.707600 Y33.910000 Z-0.125000
G01 X27.636700 Y33.583000 Z-0.125000
G01 X28.372600 Y32.987000 Z-0.125000
G01 X28.907800 Y32.127000 Z-0.125000
G01 X29.234500 Y31.005000 Z-0.125000
G01 X29.345100 Y29.626000 Z-0.125000
G01 X29.387200 Y28.222000 Z-0.125000
G01 X29.668900 Y27.497000 Z-0.125000
G01 X30.423400 Y27.226000 Z-0.125000
G01 X31.884000 Y27.185000 Z-0.125000
G01 X34.422800 Y27.185000 Z-0.125000
G01 X32.011800 Y29.670000 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X34.150400 Y25.997000
G01 Z-0.125000 F100.0(Penetrate)
G01 X35.743200 Y27.590000 Z-0.125000 F400.000000
G01 X36.035000 Y27.765000 Z-0.125000
G01 X36.284100 Y27.756000 Z-0.125000
G01 X36.392800 Y27.608000 Z-0.125000
G01 X36.263700 Y27.362000 Z-0.125000
G01 X35.221400 Y26.320000 Z-0.125000
G01 X35.135000 Y26.116000 Z-0.125000
G01 X35.337700 Y26.062000 Z-0.125000
G01 X36.015300 Y26.365000 Z-0.125000
G01 X36.817300 Y27.167000 Z-0.125000
G01 X37.120500 Y27.353000 Z-0.125000
G01 X37.394400 Y27.370000 Z-0.125000
G01 X37.528100 Y27.247000 Z-0.125000
G01 X37.410300 Y27.012000 Z-0.125000
G01 X36.814600 Y26.416000 Z-0.125000
G01 X36.731200 Y26.216000 Z-0.125000
G01 X36.940700 Y26.168000 Z-0.125000
G01 X37.628000 Y26.481000 Z-0.125000
G01 X38.064600 Y26.918000 Z-0.125000
G01 X38.385200 Y27.121000 Z-0.125000
G01 X38.697700 Y27.177000 Z-0.125000
G01 X38.869800 Y27.092000 Z-0.125000
G01 X38.769500 Y26.874000 Z-0.125000
G01 X38.450000 Y26.555000 Z-0.125000
G01 X38.370200 Y26.358000 Z-0.125000
G01 X38.587600 Y26.318000 Z-0.125000
G01 X39.286500 Y26.643000 Z-0.125000
G01 X39.560800 Y26.917000 Z-0.125000
G01 X40.328700 Y27.311000 Z-0.125000
G01 X40.593500 Y27.319000 Z-0.125000
G01 X40.535300 Y27.143000 Z-0.125000
G01 X40.141100 Y26.749000 Z-0.125000
G01 X40.067200 Y26.558000 Z-0.125000
G01 X40.297500 Y26.531000 Z-0.125000
G01 X41.015300 Y26.875000 Z-0.125000
G01 X41.965500 Y27.825000 Z-0.125000
G00 Z5.000000
(End cutting path id: path2)
(Start cutting path id: path2)
(Change tool to Default tool)
G00 Z5.000000
G00 X41.611500 Y27.777000
G01 Z-0.125000 F100.0(Penetrate)
G01 X43.307000 Y28.714000 Z-0.125000 F400.000000
G01 X45.012100 Y30.214000 Z-0.125000
G01 X46.696200 Y32.226000 Z-0.125000
G01 X48.328800 Y34.698000 Z-0.125000
G01 X49.879300 Y37.579000 Z-0.125000
G01 X51.317200 Y40.817000 Z-0.125000
G01 X52.612100 Y44.361000 Z-0.125000
G01 X53.733200 Y48.159000 Z-0.125000
G01 X54.625300 Y51.816000 Z-0.125000
G01 X55.352900 Y55.564000 Z-0.125000
G01 X56.942700 Y67.024700 Z-0.125000
G01 X57.036500 Y68.156300 Z-0.125000
G01 X56.879200 Y68.775700 Z-0.125000
G01 X56.351900 Y69.035400 Z-0.125000
G01 X55.335800 Y69.088100 Z-0.125000
...
This file has been truncated, please download it to see its full contents.
{"data": "mm", "cmd": "set_units"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 121.609, "x": -87.839, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 121.637, "x": -87.845, "feed": 446, "cmd": "move.linear"}
{"y": 121.44, "x": -87.64100000000001, "feed": 567, "cmd": "move.linear"}
{"y": 121.187, "x": -87.425, "feed": 562, "cmd": "move.linear"}
{"y": 120.984, "x": -87.38200000000001, "feed": 447, "cmd": "move.linear"}
{"y": 120.781, "x": -87.339, "feed": 448.068, "cmd": "move.linear"}
{"y": 120.657, "x": -87.28700000000001, "feed": 497, "cmd": "move.linear"}
{"y": 120.558, "x": -87.211, "feed": 557, "cmd": "move.linear"}
{"y": 120.522, "x": -87.148, "feed": 535, "cmd": "move.linear"}
{"y": 120.584, "x": -87.136, "feed": 369, "cmd": "move.linear"}
{"y": 120.725, "x": -87.166, "feed": 448, "cmd": "move.linear"}
{"y": 120.787, "x": -87.154, "feed": 368, "cmd": "move.linear"}
{"y": 120.749, "x": -87.09, "feed": 540, "cmd": "move.linear"}
{"y": 120.648, "x": -87.014, "feed": 555, "cmd": "move.linear"}
{"y": 120.524, "x": -86.962, "feed": 496, "cmd": "move.linear"}
{"y": 120.43, "x": -86.94199999999999, "feed": 448, "cmd": "move.linear"}
{"y": 120.316, "x": -86.893, "feed": 502, "cmd": "move.linear"}
{"y": 120.239, "x": -86.822, "feed": 566, "cmd": "move.linear"}
{"y": 120.225, "x": -86.764, "feed": 458, "cmd": "move.linear"}
{"y": 120.298, "x": -86.754, "feed": 377, "cmd": "move.linear"}
{"y": 120.357, "x": -86.76600000000001, "feed": 448, "cmd": "move.linear"}
{"y": 120.428, "x": -86.756, "feed": 375, "cmd": "move.linear"}
{"y": 120.409, "x": -86.697, "feed": 478, "cmd": "move.linear"}
{"y": 120.328, "x": -86.625, "feed": 564, "cmd": "move.linear"}
{"y": 120.212, "x": -86.57599999999999, "feed": 500, "cmd": "move.linear"}
{"y": 120.18, "x": -86.569, "feed": 448, "cmd": "move.linear"}
{"y": 120.069, "x": -86.521, "feed": 503, "cmd": "move.linear"}
{"y": 120.0, "x": -86.45099999999999, "feed": 567, "cmd": "move.linear"}
{"y": 119.993, "x": -86.395, "feed": 427, "cmd": "move.linear"}
{"y": 120.069, "x": -86.386, "feed": 379, "cmd": "move.linear"}
{"y": 120.082, "x": -86.38800000000001, "feed": 444, "cmd": "move.linear"}
{"y": 120.155, "x": -86.378, "feed": 375, "cmd": "move.linear"}
{"y": 120.143, "x": -86.321, "feed": 445, "cmd": "move.linear"}
{"y": 120.071, "x": -86.251, "feed": 567, "cmd": "move.linear"}
{"y": 119.962, "x": -86.203, "feed": 503, "cmd": "move.linear"}
{"y": 119.955, "x": -86.202, "feed": 447, "cmd": "move.linear"}
{"y": 119.853, "x": -86.15600000000001, "feed": 507, "cmd": "move.linear"}
{"y": 119.79, "x": -86.08799999999999, "feed": 566, "cmd": "move.linear"}
{"y": 119.784, "x": -86.032, "feed": 423, "cmd": "move.linear"}
{"y": 119.854, "x": -86.021, "feed": 374, "cmd": "move.linear"}
{"y": 119.858, "x": -86.02200000000001, "feed": 447, "cmd": "move.linear"}
{"y": 119.924, "x": -86.01000000000001, "feed": 369, "cmd": "move.linear"}
{"y": 119.914, "x": -85.953, "feed": 438, "cmd": "move.linear"}
{"y": 119.849, "x": -85.88500000000001, "feed": 566, "cmd": "move.linear"}
{"y": 119.75, "x": -85.84099999999999, "feed": 508, "cmd": "move.linear"}
{"y": 119.745, "x": -85.84, "feed": 447, "cmd": "move.linear"}
{"y": 119.652, "x": -85.79600000000001, "feed": 512, "cmd": "move.linear"}
{"y": 119.592, "x": -85.729, "feed": 564, "cmd": "move.linear"}
{"y": 119.586, "x": -85.672, "feed": 424, "cmd": "move.linear"}
{"y": 119.65, "x": -85.66, "feed": 368, "cmd": "move.linear"}
{"y": 119.652, "x": -85.661, "feed": 446, "cmd": "move.linear"}
{"y": 119.713, "x": -85.648, "feed": 365, "cmd": "move.linear"}
{"y": 119.704, "x": -85.59099999999999, "feed": 434, "cmd": "move.linear"}
{"y": 119.644, "x": -85.524, "feed": 565, "cmd": "move.linear"}
{"y": 119.552, "x": -85.48099999999999, "feed": 511, "cmd": "move.linear"}
{"y": 119.549, "x": -85.48099999999999, "feed": 446, "cmd": "move.linear"}
{"y": 119.46, "x": -85.438, "feed": 514, "cmd": "move.linear"}
{"y": 119.403, "x": -85.372, "feed": 563, "cmd": "move.linear"}
{"y": 119.395, "x": -85.316, "feed": 425, "cmd": "move.linear"}
{"y": 119.456, "x": -85.303, "feed": 364, "cmd": "move.linear"}
{"y": 119.457, "x": -85.303, "feed": 491, "cmd": "move.linear"}
{"y": 119.516, "x": -85.29000000000001, "feed": 363, "cmd": "move.linear"}
{"y": 119.508, "x": -85.233, "feed": 430, "cmd": "move.linear"}
{"y": 119.451, "x": -85.167, "feed": 563, "cmd": "move.linear"}
{"y": 119.362, "x": -85.125, "feed": 514, "cmd": "move.linear"}
{"y": 119.361, "x": -85.125, "feed": 446, "cmd": "move.linear"}
{"y": 119.273, "x": -85.08199999999999, "feed": 515, "cmd": "move.linear"}
{"y": 119.217, "x": -85.017, "feed": 562, "cmd": "move.linear"}
{"y": 119.21, "x": -84.961, "feed": 424, "cmd": "move.linear"}
{"y": 119.269, "x": -84.947, "feed": 362, "cmd": "move.linear"}
{"y": 119.269, "x": -84.947, "feed": 500, "cmd": "move.linear"}
{"y": 119.328, "x": -84.934, "feed": 363, "cmd": "move.linear"}
{"y": 119.321, "x": -84.878, "feed": 424, "cmd": "move.linear"}
{"y": 119.264, "x": -84.812, "feed": 563, "cmd": "move.linear"}
{"y": 119.176, "x": -84.77, "feed": 514, "cmd": "move.linear"}
{"y": 119.176, "x": -84.77, "feed": 500, "cmd": "move.linear"}
{"y": 119.088, "x": -84.72799999999999, "feed": 514, "cmd": "move.linear"}
{"y": 119.032, "x": -84.663, "feed": 562, "cmd": "move.linear"}
{"y": 119.025, "x": -84.607, "feed": 422, "cmd": "move.linear"}
{"y": 119.085, "x": -84.593, "feed": 362, "cmd": "move.linear"}
{"y": 119.085, "x": -84.593, "feed": 445, "cmd": "move.linear"}
{"y": 119.145, "x": -84.58, "feed": 362, "cmd": "move.linear"}
{"y": 119.138, "x": -84.524, "feed": 421, "cmd": "move.linear"}
{"y": 119.082, "x": -84.459, "feed": 562, "cmd": "move.linear"}
{"y": 118.994, "x": -84.417, "feed": 514, "cmd": "move.linear"}
{"y": 118.994, "x": -84.417, "feed": 445, "cmd": "move.linear"}
{"y": 118.905, "x": -84.375, "feed": 514, "cmd": "move.linear"}
{"y": 118.848, "x": -84.31, "feed": 562, "cmd": "move.linear"}
{"y": 118.841, "x": -84.254, "feed": 420, "cmd": "move.linear"}
{"y": 118.901, "x": -84.241, "feed": 362, "cmd": "move.linear"}
{"y": 118.902, "x": -84.241, "feed": 444, "cmd": "move.linear"}
{"y": 118.962, "x": -84.227, "feed": 363, "cmd": "move.linear"}
{"y": 118.956, "x": -84.17100000000001, "feed": 419, "cmd": "move.linear"}
{"y": 118.899, "x": -84.10599999999999, "feed": 562, "cmd": "move.linear"}
{"y": 118.81, "x": -84.065, "feed": 513, "cmd": "move.linear"}
{"y": 118.81, "x": -84.065, "feed": 444, "cmd": "move.linear"}
{"y": 118.72, "x": -84.023, "feed": 513, "cmd": "move.linear"}
{"y": 118.664, "x": -83.958, "feed": 563, "cmd": "move.linear"}
{"y": 118.657, "x": -83.902, "feed": 420, "cmd": "move.linear"}
{"y": 118.717, "x": -83.88800000000001, "feed": 362, "cmd": "move.linear"}
{"y": 118.719, "x": -83.889, "feed": 477, "cmd": "move.linear"}
{"y": 118.78, "x": -83.875, "feed": 363, "cmd": "move.linear"}
{"y": 118.774, "x": -83.81999999999999, "feed": 416, "cmd": "move.linear"}
{"y": 118.718, "x": -83.755, "feed": 562, "cmd": "move.linear"}
{"y": 118.628, "x": -83.71299999999999, "feed": 512, "cmd": "move.linear"}
{"y": 118.626, "x": -83.71299999999999, "feed": 443, "cmd": "move.linear"}
{"y": 118.535, "x": -83.672, "feed": 511, "cmd": "move.linear"}
{"y": 118.477, "x": -83.60599999999999, "feed": 563, "cmd": "move.linear"}
{"y": 118.471, "x": -83.551, "feed": 416, "cmd": "move.linear"}
{"y": 118.533, "x": -83.538, "feed": 363, "cmd": "move.linear"}
{"y": 118.534, "x": -83.538, "feed": 443, "cmd": "move.linear"}
{"y": 118.598, "x": -83.52500000000001, "feed": 364, "cmd": "move.linear"}
{"y": 118.593, "x": -83.46899999999999, "feed": 411, "cmd": "move.linear"}
{"y": 118.536, "x": -83.404, "feed": 563, "cmd": "move.linear"}
{"y": 118.444, "x": -83.363, "feed": 510, "cmd": "move.linear"}
{"y": 118.442, "x": -83.363, "feed": 443, "cmd": "move.linear"}
{"y": 118.348, "x": -83.321, "feed": 509, "cmd": "move.linear"}
{"y": 118.29, "x": -83.256, "feed": 564, "cmd": "move.linear"}
{"y": 118.284, "x": -83.2, "feed": 413, "cmd": "move.linear"}
{"y": 118.348, "x": -83.187, "feed": 364, "cmd": "move.linear"}
{"y": 118.35, "x": -83.188, "feed": 442, "cmd": "move.linear"}
{"y": 118.417, "x": -83.175, "feed": 366, "cmd": "move.linear"}
{"y": 118.413, "x": -83.119, "feed": 404, "cmd": "move.linear"}
{"y": 118.356, "x": -83.05500000000001, "feed": 563, "cmd": "move.linear"}
{"y": 118.261, "x": -83.01300000000001, "feed": 508, "cmd": "move.linear"}
{"y": 118.258, "x": -83.01300000000001, "feed": 442, "cmd": "move.linear"}
{"y": 118.161, "x": -82.971, "feed": 507, "cmd": "move.linear"}
{"y": 118.1, "x": -82.90600000000001, "feed": 565, "cmd": "move.linear"}
{"y": 118.095, "x": -82.84999999999999, "feed": 409, "cmd": "move.linear"}
{"y": 118.163, "x": -82.83799999999999, "feed": 367, "cmd": "move.linear"}
{"y": 118.167, "x": -82.83799999999999, "feed": 427, "cmd": "move.linear"}
{"y": 118.239, "x": -82.82599999999999, "feed": 370, "cmd": "move.linear"}
{"y": 118.238, "x": -82.771, "feed": 394, "cmd": "move.linear"}
{"y": 118.18, "x": -82.70699999999999, "feed": 563, "cmd": "move.linear"}
{"y": 118.081, "x": -82.66500000000001, "feed": 505, "cmd": "move.linear"}
{"y": 118.047, "x": -82.65900000000001, "feed": 442, "cmd": "move.linear"}
{"y": 117.769, "x": -82.532, "feed": 514, "cmd": "move.linear"}
{"y": 117.694, "x": -82.464, "feed": 567, "cmd": "move.linear"}
{"y": 117.739, "x": -82.44799999999999, "feed": 344, "cmd": "move.linear"}
{"y": 117.996, "x": -82.492, "feed": 442, "cmd": "move.linear"}
{"y": 118.081, "x": -82.482, "feed": 377, "cmd": "move.linear"}
{"y": 118.095, "x": -82.43000000000001, "feed": 349, "cmd": "move.linear"}
{"y": 118.047, "x": -82.367, "feed": 552, "cmd": "move.linear"}
{"y": 117.947, "x": -82.32599999999999, "feed": 504, "cmd": "move.linear"}
{"y": 117.688, "x": -82.28100000000001, "feed": 441, "cmd": "move.linear"}
{"y": 117.43, "x": -82.236, "feed": 442.902, "cmd": "move.linear"}
{"y": 117.151, "x": -82.108, "feed": 515, "cmd": "move.linear"}
{"y": 117.076, "x": -82.041, "feed": 567, "cmd": "move.linear"}
{"y": 117.121, "x": -82.02500000000001, "feed": 343, "cmd": "move.linear"}
{"y": 117.239, "x": -82.04600000000001, "feed": 443, "cmd": "move.linear"}
{"y": 117.275, "x": -82.02800000000001, "feed": 332, "cmd": "move.linear"}
{"y": 117.182, "x": -81.958, "feed": 561, "cmd": "move.linear"}
{"y": 116.877, "x": -81.82599999999999, "feed": 510, "cmd": "move.linear"}
{"y": 116.811, "x": -81.81399999999999, "feed": 444, "cmd": "move.linear"}
{"y": 116.531, "x": -81.68600000000001, "feed": 517, "cmd": "move.linear"}
{"y": 116.455, "x": -81.619, "feed": 568, "cmd": "move.linear"}
{"y": 116.5, "x": -81.60299999999999, "feed": 343, "cmd": "move.linear"}
{"y": 116.573, "x": -81.616, "feed": 445, "cmd": "move.linear"}
{"y": 116.615, "x": -81.599, "feed": 339, "cmd": "move.linear"}
{"y": 116.533, "x": -81.53100000000001, "feed": 567, "cmd": "move.linear"}
{"y": 116.244, "x": -81.402, "feed": 515, "cmd": "move.linear"}
{"y": 116.189, "x": -81.392, "feed": 446, "cmd": "move.linear"}
{"y": 115.909, "x": -81.265, "feed": 518, "cmd": "move.linear"}
{"y": 115.833, "x": -81.19799999999999, "feed": 569, "cmd": "move.linear"}
{"y": 115.877, "x": -81.182, "feed": 343, "cmd": "move.linear"}
{"y": 115.936, "x": -81.193, "feed": 446, "cmd": "move.linear"}
{"y": 115.981, "x": -81.17700000000001, "feed": 343, "cmd": "move.linear"}
{"y": 115.907, "x": -81.11, "feed": 569, "cmd": "move.linear"}
{"y": 115.629, "x": -80.983, "feed": 519, "cmd": "move.linear"}
{"y": 115.567, "x": -80.97199999999999, "feed": 447, "cmd": "move.linear"}
{"y": 115.287, "x": -80.84399999999999, "feed": 520, "cmd": "move.linear"}
{"y": 115.211, "x": -80.77800000000001, "feed": 569, "cmd": "move.linear"}
{"y": 115.257, "x": -80.76300000000001, "feed": 343, "cmd": "move.linear"}
{"y": 115.323, "x": -80.77500000000001, "feed": 447, "cmd": "move.linear"}
{"y": 115.369, "x": -80.759, "feed": 344, "cmd": "move.linear"}
{"y": 115.297, "x": -80.694, "feed": 569, "cmd": "move.linear"}
{"y": 115.021, "x": -80.56699999999999, "feed": 521, "cmd": "move.linear"}
{"y": 114.952, "x": -80.554, "feed": 449, "cmd": "move.linear"}
{"y": 114.674, "x": -80.42700000000001, "feed": 522, "cmd": "move.linear"}
{"y": 114.601, "x": -80.361, "feed": 570, "cmd": "move.linear"}
{"y": 114.647, "x": -80.346, "feed": 344, "cmd": "move.linear"}
{"y": 114.719, "x": -80.36, "feed": 449, "cmd": "move.linear"}
{"y": 114.767, "x": -80.345, "feed": 345, "cmd": "move.linear"}
{"y": 114.695, "x": -80.279, "feed": 570, "cmd": "move.linear"}
{"y": 114.42, "x": -80.15300000000001, "feed": 524, "cmd": "move.linear"}
{"y": 114.346, "x": -80.139, "feed": 449, "cmd": "move.linear"}
{"y": 114.07, "x": -80.012, "feed": 525, "cmd": "move.linear"}
{"y": 113.999, "x": -79.947, "feed": 570, "cmd": "move.linear"}
{"y": 114.046, "x": -79.93300000000001, "feed": 345, "cmd": "move.linear"}
{"y": 114.124, "x": -79.947, "feed": 450, "cmd": "move.linear"}
{"y": 114.176, "x": -79.93300000000001, "feed": 350, "cmd": "move.linear"}
{"y": 114.114, "x": -79.87, "feed": 565, "cmd": "move.linear"}
{"y": 113.852, "x": -79.746, "feed": 528, "cmd": "move.linear"}
{"y": 113.748, "x": -79.727, "feed": 451, "cmd": "move.linear"}
{"y": 113.475, "x": -79.59999999999999, "feed": 527, "cmd": "move.linear"}
{"y": 113.405, "x": -79.536, "feed": 570, "cmd": "move.linear"}
{"y": 113.453, "x": -79.52200000000001, "feed": 346, "cmd": "move.linear"}
{"y": 113.536, "x": -79.53700000000001, "feed": 451, "cmd": "move.linear"}
{"y": 113.585, "x": -79.523, "feed": 347, "cmd": "move.linear"}
{"y": 113.517, "x": -79.459, "feed": 570, "cmd": "move.linear"}
{"y": 113.246, "x": -79.333, "feed": 528, "cmd": "move.linear"}
{"y": 113.159, "x": -79.31699999999999, "feed": 451, "cmd": "move.linear"}
{"y": 112.887, "x": -79.191, "feed": 529, "cmd": "move.linear"}
{"y": 112.819, "x": -79.127, "feed": 570, "cmd": "move.linear"}
{"y": 112.868, "x": -79.113, "feed": 347, "cmd": "move.linear"}
{"y": 112.957, "x": -79.13, "feed": 453, "cmd": "move.linear"}
{"y": 113.007, "x": -79.116, "feed": 348, "cmd": "move.linear"}
{"y": 112.94, "x": -79.053, "feed": 569, "cmd": "move.linear"}
{"y": 112.671, "x": -78.928, "feed": 530, "cmd": "move.linear"}
{"y": 112.577, "x": -78.90900000000001, "feed": 453, "cmd": "move.linear"}
{"y": 112.306, "x": -78.78400000000001, "feed": 531, "cmd": "move.linear"}
{"y": 112.239, "x": -78.72, "feed": 570, "cmd": "move.linear"}
{"y": 112.289, "x": -78.70699999999999, "feed": 347, "cmd": "move.linear"}
{"y": 112.387, "x": -78.72499999999999, "feed": 454, "cmd": "move.linear"}
{"y": 112.438, "x": -78.712, "feed": 349, "cmd": "move.linear"}
{"y": 112.372, "x": -78.649, "feed": 569, "cmd": "move.linear"}
{"y": 112.104, "x": -78.524, "feed": 532, "cmd": "move.linear"}
{"y": 112.002, "x": -78.505, "feed": 454, "cmd": "move.linear"}
{"y": 111.733, "x": -78.379, "feed": 533, "cmd": "move.linear"}
{"y": 111.667, "x": -78.316, "feed": 570, "cmd": "move.linear"}
{"y": 111.718, "x": -78.303, "feed": 349, "cmd": "move.linear"}
{"y": 111.824, "x": -78.324, "feed": 455, "cmd": "move.linear"}
{"y": 111.879, "x": -78.31100000000001, "feed": 353, "cmd": "move.linear"}
{"y": 111.82, "x": -78.25, "feed": 562, "cmd": "move.linear"}
{"y": 111.563, "x": -78.127, "feed": 536, "cmd": "move.linear"}
{"y": 111.434, "x": -78.102, "feed": 456, "cmd": "move.linear"}
{"y": 111.167, "x": -77.977, "feed": 535, "cmd": "move.linear"}
{"y": 111.102, "x": -77.914, "feed": 569, "cmd": "move.linear"}
{"y": 111.153, "x": -77.902, "feed": 350, "cmd": "move.linear"}
{"y": 111.27, "x": -77.92400000000001, "feed": 456, "cmd": "move.linear"}
{"y": 111.322, "x": -77.91200000000001, "feed": 350, "cmd": "move.linear"}
{"y": 111.26, "x": -77.84999999999999, "feed": 567, "cmd": "move.linear"}
{"y": 110.995, "x": -77.726, "feed": 536, "cmd": "move.linear"}
{"y": 110.874, "x": -77.702, "feed": 457, "cmd": "move.linear"}
{"y": 110.607, "x": -77.577, "feed": 537, "cmd": "move.linear"}
{"y": 110.544, "x": -77.515, "feed": 568, "cmd": "move.linear"}
{"y": 110.596, "x": -77.503, "feed": 351, "cmd": "move.linear"}
{"y": 110.722, "x": -77.527, "feed": 458, "cmd": "move.linear"}
{"y": 110.775, "x": -77.515, "feed": 352, "cmd": "move.linear"}
{"y": 110.715, "x": -77.45399999999999, "feed": 566, "cmd": "move.linear"}
{"y": 110.452, "x": -77.33, "feed": 538, "cmd": "move.linear"}
{"y": 110.32, "x": -77.304, "feed": 458, "cmd": "move.linear"}
{"y": 110.046, "x": -77.178, "feed": 537, "cmd": "move.linear"}
{"y": 109.978, "x": -77.11499999999999, "feed": 573, "cmd": "move.linear"}
{"y": 110.028, "x": -77.10299999999999, "feed": 348, "cmd": "move.linear"}
{"y": 110.182, "x": -77.133, "feed": 459, "cmd": "move.linear"}
{"y": 110.236, "x": -77.122, "feed": 354, "cmd": "move.linear"}
{"y": 110.177, "x": -77.06, "feed": 565, "cmd": "move.linear"}
{"y": 109.916, "x": -76.937, "feed": 540, "cmd": "move.linear"}
{"y": 109.775, "x": -76.90900000000001, "feed": 459, "cmd": "move.linear"}
{"y": 109.512, "x": -76.786, "feed": 541, "cmd": "move.linear"}
{"y": 109.451, "x": -76.724, "feed": 566, "cmd": "move.linear"}
{"y": 109.505, "x": -76.71299999999999, "feed": 353, "cmd": "move.linear"}
{"y": 109.65, "x": -76.742, "feed": 460, "cmd": "move.linear"}
{"y": 109.705, "x": -76.73, "feed": 354, "cmd": "move.linear"}
{"y": 109.646, "x": -76.669, "feed": 564, "cmd": "move.linear"}
{"y": 109.386, "x": -76.547, "feed": 542, "cmd": "move.linear"}
{"y": 109.239, "x": -76.517, "feed": 461, "cmd": "move.linear"}
{"y": 108.978, "x": -76.39400000000001, "feed": 544, "cmd": "move.linear"}
{"y": 108.92, "x": -76.333, "feed": 564, "cmd": "move.linear"}
{"y": 108.974, "x": -76.322, "feed": 354, "cmd": "move.linear"}
{"y": 109.124, "x": -76.352, "feed": 461, "cmd": "move.linear"}
{"y": 109.18, "x": -76.34099999999999, "feed": 355, "cmd": "move.linear"}
{"y": 109.124, "x": -76.28100000000001, "feed": 560, "cmd": "move.linear"}
{"y": 108.866, "x": -76.15900000000001, "feed": 544, "cmd": "move.linear"}
{"y": 108.713, "x": -76.128, "feed": 462, "cmd": "move.linear"}
{"y": 108.455, "x": -76.005, "feed": 546, "cmd": "move.linear"}
{"y": 108.399, "x": -75.946, "feed": 560, "cmd": "move.linear"}
{"y": 108.455, "x": -75.935, "feed": 356, "cmd": "move.linear"}
{"y": 108.604, "x": -75.965, "feed": 462, "cmd": "move.linear"}
{"y": 108.66, "x": -75.95399999999999, "feed": 355, "cmd": "move.linear"}
{"y": 108.604, "x": -75.89400000000001, "feed": 560, "cmd": "move.linear"}
{"y": 108.346, "x": -75.77200000000001, "feed": 546, "cmd": "move.linear"}
{"y": 108.2, "x": -75.74299999999999, "feed": 463, "cmd": "move.linear"}
{"y": 107.946, "x": -75.621, "feed": 549, "cmd": "move.linear"}
{"y": 107.892, "x": -75.562, "feed": 554, "cmd": "move.linear"}
{"y": 107.95, "x": -75.551, "feed": 358, "cmd": "move.linear"}
{"y": 108.088, "x": -75.57899999999999, "feed": 463, "cmd": "move.linear"}
{"y": 108.144, "x": -75.568, "feed": 357, "cmd": "move.linear"}
{"y": 108.087, "x": -75.509, "feed": 561, "cmd": "move.linear"}
{"y": 107.829, "x": -75.387, "feed": 548, "cmd": "move.linear"}
{"y": 107.702, "x": -75.361, "feed": 464, "cmd": "move.linear"}
{"y": 107.449, "x": -75.23999999999999, "feed": 551, "cmd": "move.linear"}
{"y": 107.396, "x": -75.181, "feed": 552, "cmd": "move.linear"}
{"y": 107.455, "x": -75.17100000000001, "feed": 360, "cmd": "move.linear"}
{"y": 107.572, "x": -75.19499999999999, "feed": 465, "cmd": "move.linear"}
{"y": 107.63, "x": -75.184, "feed": 357, "cmd": "move.linear"}
{"y": 107.575, "x": -75.125, "feed": 557, "cmd": "move.linear"}
{"y": 107.319, "x": -75.004, "feed": 550, "cmd": "move.linear"}
{"y": 107.207, "x": -74.98099999999999, "feed": 465, "cmd": "move.linear"}
{"y": 106.953, "x": -74.86, "feed": 552, "cmd": "move.linear"}
{"y": 106.9, "x": -74.801, "feed": 553, "cmd": "move.linear"}
{"y": 106.959, "x": -74.791, "feed": 359, "cmd": "move.linear"}
{"y": 107.076, "x": -74.815, "feed": 466, "cmd": "move.linear"}
{"y": 107.138, "x": -74.806, "feed": 362, "cmd": "move.linear"}
{"y": 107.093, "x": -74.749, "feed": 533, "cmd": "move.linear"}
{"y": 106.983, "x": -74.679, "feed": 579, "cmd": "move.linear"}
{"y": 106.851, "x": -74.63, "feed": 521, "cmd": "move.linear"}
{"y": 106.58, "x": -74.575, "feed": 466, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 105.947, "x": -74.443, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 105.695, "x": -74.389, "feed": 471, "cmd": "move.linear"}
{"y": 105.441, "x": -74.33499999999999, "feed": 472.673, "cmd": "move.linear"}
{"y": 105.391, "x": -74.303, "feed": 585, "cmd": "move.linear"}
{"y": 105.464, "x": -74.27200000000001, "feed": 317, "cmd": "move.linear"}
{"y": 105.607, "x": -74.268, "feed": 393, "cmd": "move.linear"}
{"y": 105.749, "x": -74.264, "feed": 392.948, "cmd": "move.linear"}
{"y": 106.055, "x": -74.328, "feed": 470, "cmd": "move.linear"}
{"y": 106.36, "x": -74.39100000000001, "feed": 468, "cmd": "move.linear"}
{"y": 106.665, "x": -74.453, "feed": 467.272, "cmd": "move.linear"}
{"y": 106.743, "x": -74.447, "feed": 380, "cmd": "move.linear"}
{"y": 106.732, "x": -74.39700000000001, "feed": 378, "cmd": "move.linear"}
{"y": 106.658, "x": -74.33499999999999, "feed": 582, "cmd": "move.linear"}
{"y": 106.541, "x": -74.29000000000001, "feed": 529, "cmd": "move.linear"}
{"y": 106.277, "x": -74.236, "feed": 467, "cmd": "move.linear"}
{"y": 106.013, "x": -74.182, "feed": 468.429, "cmd": "move.linear"}
{"y": 105.951, "x": -74.14700000000001, "feed": 572, "cmd": "move.linear"}
{"y": 105.998, "x": -74.11, "feed": 291, "cmd": "move.linear"}
{"y": 106.242, "x": -74.09099999999999, "feed": 379, "cmd": "move.linear"}
{"y": 106.496, "x": -74.142, "feed": 466, "cmd": "move.linear"}
{"y": 106.597, "x": -74.14, "feed": 396, "cmd": "move.linear"}
{"y": 106.637, "x": -74.09999999999999, "feed": 288, "cmd": "move.linear"}
{"y": 106.613, "x": -74.048, "feed": 446, "cmd": "move.linear"}
{"y": 106.519, "x": -74.008, "feed": 541, "cmd": "move.linear"}
{"y": 106.429, "x": -73.98999999999999, "feed": 465, "cmd": "move.linear"}
{"y": 106.355, "x": -73.953, "feed": 558, "cmd": "move.linear"}
{"y": 106.372, "x": -73.90900000000001, "feed": 293, "cmd": "move.linear"}
{"y": 106.574, "x": -73.879, "feed": 363, "cmd": "move.linear"}
{"y": 106.592, "x": -73.883, "feed": 464, "cmd": "move.linear"}
{"y": 106.751, "x": -73.84399999999999, "feed": 344, "cmd": "move.linear"}
{"y": 106.748, "x": -73.795, "feed": 348, "cmd": "move.linear"}
{"y": 106.669, "x": -73.758, "feed": 552, "cmd": "move.linear"}
{"y": 106.669, "x": -73.758, "feed": 500, "cmd": "move.linear"}
{"y": 106.589, "x": -73.721, "feed": 550, "cmd": "move.linear"}
{"y": 106.58, "x": -73.67100000000001, "feed": 369, "cmd": "move.linear"}
{"y": 106.632, "x": -73.633, "feed": 295, "cmd": "move.linear"}
{"y": 106.732, "x": -73.631, "feed": 393, "cmd": "move.linear"}
{"y": 106.74, "x": -73.63200000000001, "feed": 453, "cmd": "move.linear"}
{"y": 106.831, "x": -73.627, "feed": 387, "cmd": "move.linear"}
{"y": 106.864, "x": -73.586, "feed": 287, "cmd": "move.linear"}
{"y": 106.838, "x": -73.533, "feed": 454, "cmd": "move.linear"}
{"y": 106.751, "x": -73.494, "feed": 543, "cmd": "move.linear"}
{"y": 106.739, "x": -73.492, "feed": 455, "cmd": "move.linear"}
{"y": 106.657, "x": -73.455, "feed": 548, "cmd": "move.linear"}
{"y": 106.627, "x": -73.401, "feed": 472, "cmd": "move.linear"}
{"y": 106.651, "x": -73.357, "feed": 289, "cmd": "move.linear"}
{"y": 106.729, "x": -73.34999999999999, "feed": 376, "cmd": "move.linear"}
{"y": 106.736, "x": -73.351, "feed": 460, "cmd": "move.linear"}
{"y": 106.801, "x": -73.34099999999999, "feed": 362, "cmd": "move.linear"}
{"y": 106.804, "x": -73.294, "feed": 326, "cmd": "move.linear"}
{"y": 106.757, "x": -73.23699999999999, "feed": 538, "cmd": "move.linear"}
{"y": 106.673, "x": -73.199, "feed": 544, "cmd": "move.linear"}
{"y": 106.669, "x": -73.199, "feed": 460, "cmd": "move.linear"}
{"y": 106.585, "x": -73.161, "feed": 546, "cmd": "move.linear"}
{"y": 106.533, "x": -73.10299999999999, "feed": 551, "cmd": "move.linear"}
{"y": 106.53, "x": -73.05500000000001, "feed": 348, "cmd": "move.linear"}
{"y": 106.589, "x": -73.044, "feed": 355, "cmd": "move.linear"}
{"y": 106.589, "x": -73.044, "feed": 500, "cmd": "move.linear"}
{"y": 106.644, "x": -73.032, "feed": 350, "cmd": "move.linear"}
{"y": 106.631, "x": -72.98099999999999, "feed": 389, "cmd": "move.linear"}
{"y": 106.571, "x": -72.922, "feed": 569, "cmd": "move.linear"}
{"y": 106.482, "x": -72.884, "feed": 541, "cmd": "move.linear"}
{"y": 106.482, "x": -72.884, "feed": 459, "cmd": "move.linear"}
{"y": 106.389, "x": -72.845, "feed": 539, "cmd": "move.linear"}
{"y": 106.319, "x": -72.78400000000001, "feed": 580, "cmd": "move.linear"}
{"y": 106.298, "x": -72.732, "feed": 430, "cmd": "move.linear"}
{"y": 106.349, "x": -72.72, "feed": 343, "cmd": "move.linear"}
{"y": 106.351, "x": -72.72, "feed": 459, "cmd": "move.linear"}
{"y": 106.402, "x": -72.70699999999999, "feed": 343, "cmd": "move.linear"}
{"y": 106.375, "x": -72.654, "feed": 457, "cmd": "move.linear"}
{"y": 106.299, "x": -72.592, "feed": 584, "cmd": "move.linear"}
{"y": 106.201, "x": -72.553, "feed": 535, "cmd": "move.linear"}
{"y": 106.194, "x": -72.551, "feed": 459, "cmd": "move.linear"}
{"y": 105.973, "x": -72.441, "feed": 561, "cmd": "move.linear"}
{"y": 105.922, "x": -72.384, "feed": 551, "cmd": "move.linear"}
{"y": 105.967, "x": -72.37, "feed": 333, "cmd": "move.linear"}
{"y": 105.994, "x": -72.375, "feed": 460, "cmd": "move.linear"}
{"y": 106.057, "x": -72.36499999999999, "feed": 358, "cmd": "move.linear"}
{"y": 106.014, "x": -72.309, "feed": 525, "cmd": "move.linear"}
{"y": 105.907, "x": -72.242, "feed": 582, "cmd": "move.linear"}
{"y": 105.776, "x": -72.196, "feed": 518, "cmd": "move.linear"}
{"y": 105.578, "x": -72.16, "feed": 461, "cmd": "move.linear"}
{"y": 105.378, "x": -72.123, "feed": 462.356, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 105.606, "x": -72.026, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 105.309, "x": -71.971, "feed": 461, "cmd": "move.linear"}
{"y": 105.011, "x": -71.916, "feed": 463, "cmd": "move.linear"}
{"y": 104.712, "x": -71.85899999999999, "feed": 464, "cmd": "move.linear"}
{"y": 104.412, "x": -71.80200000000001, "feed": 466, "cmd": "move.linear"}
{"y": 104.112, "x": -71.74299999999999, "feed": 467.73, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.582, "x": -71.97199999999999, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.292, "x": -71.91500000000001, "feed": 467, "cmd": "move.linear"}
{"y": 104.002, "x": -71.857, "feed": 469, "cmd": "move.linear"}
{"y": 103.71, "x": -71.79900000000001, "feed": 470, "cmd": "move.linear"}
{"y": 103.418, "x": -71.739, "feed": 472.11, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 103.847, "x": -71.959, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.141, "x": -71.97199999999999, "feed": 414, "cmd": "move.linear"}
{"y": 104.434, "x": -71.98399999999999, "feed": 413, "cmd": "move.linear"}
{"y": 104.726, "x": -71.99299999999999, "feed": 411.524, "cmd": "move.linear"}
{"y": 104.91, "x": -72.02500000000001, "feed": 458, "cmd": "move.linear"}
{"y": 105.093, "x": -72.056, "feed": 457.522, "cmd": "move.linear"}
{"y": 105.418, "x": -72.15300000000001, "feed": 503, "cmd": "move.linear"}
{"y": 105.707, "x": -72.288, "feed": 554, "cmd": "move.linear"}
{"y": 105.963, "x": -72.461, "feed": 586, "cmd": "move.linear"}
{"y": 106.192, "x": -72.676, "feed": 574, "cmd": "move.linear"}
{"y": 106.396, "x": -72.934, "feed": 531, "cmd": "move.linear"}
{"y": 106.525, "x": -73.16, "feed": 476, "cmd": "move.linear"}
{"y": 106.585, "x": -73.366, "feed": 397, "cmd": "move.linear"}
{"y": 106.573, "x": -73.554, "feed": 325, "cmd": "move.linear"}
{"y": 106.489, "x": -73.72499999999999, "feed": 289, "cmd": "move.linear"}
{"y": 106.36, "x": -73.82299999999999, "feed": 295, "cmd": "move.linear"}
{"y": 106.229, "x": -73.92, "feed": 295, "cmd": "move.linear"}
{"y": 106.098, "x": -74.01600000000001, "feed": 295.421, "cmd": "move.linear"}
{"y": 105.923, "x": -74.075, "feed": 329, "cmd": "move.linear"}
{"y": 105.747, "x": -74.13200000000001, "feed": 330, "cmd": "move.linear"}
{"y": 105.571, "x": -74.18899999999999, "feed": 331, "cmd": "move.linear"}
{"y": 105.394, "x": -74.245, "feed": 331.803, "cmd": "move.linear"}
{"y": 105.208, "x": -74.27500000000001, "feed": 358, "cmd": "move.linear"}
{"y": 105.021, "x": -74.306, "feed": 359, "cmd": "move.linear"}
{"y": 104.834, "x": -74.33499999999999, "feed": 360.47, "cmd": "move.linear"}
{"y": 104.572, "x": -74.342, "feed": 393, "cmd": "move.linear"}
{"y": 104.309, "x": -74.34699999999999, "feed": 394.666, "cmd": "move.linear"}
{"y": 104.067, "x": -74.318, "feed": 441, "cmd": "move.linear"}
{"y": 103.824, "x": -74.28700000000001, "feed": 443.075, "cmd": "move.linear"}
{"y": 103.603, "x": -74.22199999999999, "feed": 505, "cmd": "move.linear"}
{"y": 103.381, "x": -74.15600000000001, "feed": 506.969, "cmd": "move.linear"}
{"y": 103.184, "x": -74.05800000000001, "feed": 571, "cmd": "move.linear"}
{"y": 102.986, "x": -73.959, "feed": 572.522, "cmd": "move.linear"}
{"y": 102.813, "x": -73.828, "feed": 595, "cmd": "move.linear"}
{"y": 102.64, "x": -73.697, "feed": 595.696, "cmd": "move.linear"}
{"y": 102.493, "x": -73.53400000000001, "feed": 549, "cmd": "move.linear"}
{"y": 102.346, "x": -73.372, "feed": 549.966, "cmd": "move.linear"}
{"y": 102.226, "x": -73.179, "feed": 476, "cmd": "move.linear"}
{"y": 102.105, "x": -72.985, "feed": 476.772, "cmd": "move.linear"}
{"y": 102.011, "x": -72.73699999999999, "feed": 404, "cmd": "move.linear"}
{"y": 102.003, "x": -72.527, "feed": 324, "cmd": "move.linear"}
{"y": 102.084, "x": -72.35299999999999, "feed": 277, "cmd": "move.linear"}
{"y": 102.169, "x": -72.28400000000001, "feed": 283, "cmd": "move.linear"}
{"y": 102.253, "x": -72.214, "feed": 283.015, "cmd": "move.linear"}
{"y": 102.384, "x": -72.161, "feed": 314, "cmd": "move.linear"}
{"y": 102.514, "x": -72.107, "feed": 313.615, "cmd": "move.linear"}
{"y": 102.69, "x": -72.06999999999999, "feed": 345, "cmd": "move.linear"}
{"y": 102.866, "x": -72.03100000000001, "feed": 344.977, "cmd": "move.linear"}
{"y": 103.112, "x": -72.015, "feed": 381, "cmd": "move.linear"}
{"y": 103.358, "x": -71.998, "feed": 380, "cmd": "move.linear"}
{"y": 103.603, "x": -71.979, "feed": 379, "cmd": "move.linear"}
{"y": 103.847, "x": -71.959, "feed": 377.91, "cmd": "move.linear"}
{"y": 103.847, "x": -71.959, "feed": 500, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.358, "x": -74.364, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.687, "x": -74.43899999999999, "feed": 479, "cmd": "move.linear"}
{"y": 105.015, "x": -74.51300000000001, "feed": 477.521, "cmd": "move.linear"}
{"y": 105.183, "x": -74.51600000000001, "feed": 407, "cmd": "move.linear"}
{"y": 105.351, "x": -74.51900000000001, "feed": 406.496, "cmd": "move.linear"}
{"y": 105.457, "x": -74.496, "feed": 347, "cmd": "move.linear"}
{"y": 105.463, "x": -74.482, "feed": 292, "cmd": "move.linear"}
{"y": 105.423, "x": -74.467, "feed": 524, "cmd": "move.linear"}
{"y": 105.152, "x": -74.408, "feed": 474, "cmd": "move.linear"}
{"y": 104.88, "x": -74.348, "feed": 476.124, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 104.114, "x": -74.575, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 103.944, "x": -74.535, "feed": 483, "cmd": "move.linear"}
{"y": 103.773, "x": -74.495, "feed": 483.983, "cmd": "move.linear"}
{"y": 103.415, "x": -74.343, "feed": 550, "cmd": "move.linear"}
{"y": 103.293, "x": -74.268, "feed": 590, "cmd": "move.linear"}
{"y": 103.324, "x": -74.255, "feed": 311, "cmd": "move.linear"}
{"y": 103.599, "x": -74.321, "feed": 485, "cmd": "move.linear"}
{"y": 103.873, "x": -74.38500000000001, "feed": 483, "cmd": "move.linear"}
{"y": 104.147, "x": -74.449, "feed": 482, "cmd": "move.linear"}
{"y": 104.42, "x": -74.512, "feed": 481, "cmd": "move.linear"}
{"y": 104.692, "x": -74.575, "feed": 479.777, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 103.142, "x": -74.07899999999999, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 102.966, "x": -74.03700000000001, "feed": 486, "cmd": "move.linear"}
{"y": 102.753, "x": -73.92, "feed": 583, "cmd": "move.linear"}
{"y": 102.689, "x": -73.86, "feed": 574, "cmd": "move.linear"}
{"y": 102.717, "x": -73.846, "feed": 303, "cmd": "move.linear"}
{"y": 102.722, "x": -73.84699999999999, "feed": 499, "cmd": "move.linear"}
{"y": 102.75, "x": -73.833, "feed": 304, "cmd": "move.linear"}
{"y": 102.696, "x": -73.77500000000001, "feed": 554, "cmd": "move.linear"}
{"y": 102.504, "x": -73.663, "feed": 589, "cmd": "move.linear"}
{"y": 102.504, "x": -73.663, "feed": 500, "cmd": "move.linear"}
{"y": 102.332, "x": -73.556, "feed": 594, "cmd": "move.linear"}
{"y": 102.293, "x": -73.502, "feed": 506, "cmd": "move.linear"}
{"y": 102.328, "x": -73.48999999999999, "feed": 322, "cmd": "move.linear"}
{"y": 102.334, "x": -73.491, "feed": 499, "cmd": "move.linear"}
{"y": 102.38, "x": -73.482, "feed": 348, "cmd": "move.linear"}
{"y": 102.358, "x": -73.431, "feed": 424, "cmd": "move.linear"}
{"y": 102.291, "x": -73.37, "feed": 580, "cmd": "move.linear"}
{"y": 102.203, "x": -73.32899999999999, "feed": 569, "cmd": "move.linear"}
{"y": 102.194, "x": -73.327, "feed": 488, "cmd": "move.linear"}
{"y": 102.101, "x": -73.28400000000001, "feed": 566, "cmd": "move.linear"}
{"y": 102.035, "x": -73.223, "feed": 579, "cmd": "move.linear"}
{"y": 102.018, "x": -73.17400000000001, "feed": 396, "cmd": "move.linear"}
{"y": 102.072, "x": -73.167, "feed": 363, "cmd": "move.linear"}
{"y": 102.08, "x": -73.169, "feed": 488, "cmd": "move.linear"}
{"y": 102.145, "x": -73.164, "feed": 378, "cmd": "move.linear"}
{"y": 102.141, "x": -73.11799999999999, "feed": 334, "cmd": "move.linear"}
{"y": 102.084, "x": -73.059, "feed": 562, "cmd": "move.linear"}
{"y": 101.991, "x": -73.01600000000001, "feed": 566, "cmd": "move.linear"}
{"y": 101.984, "x": -73.015, "feed": 488, "cmd": "move.linear"}
{"y": 101.894, "x": -72.973, "feed": 568, "cmd": "move.linear"}
{"y": 101.844, "x": -72.916, "feed": 542, "cmd": "move.linear"}
{"y": 101.847, "x": -72.872, "feed": 307, "cmd": "move.linear"}
{"y": 101.916, "x": -72.86799999999999, "feed": 383, "cmd": "move.linear"}
{"y": 101.924, "x": -72.87, "feed": 478, "cmd": "move.linear"}
{"y": 101.99, "x": -72.86499999999999, "feed": 379, "cmd": "move.linear"}
{"y": 101.997, "x": -72.822, "feed": 296, "cmd": "move.linear"}
{"y": 101.955, "x": -72.76600000000001, "feed": 516, "cmd": "move.linear"}
{"y": 101.873, "x": -72.727, "feed": 573, "cmd": "move.linear"}
{"y": 101.866, "x": -72.72499999999999, "feed": 487, "cmd": "move.linear"}
{"y": 101.796, "x": -72.688, "feed": 583, "cmd": "move.linear"}
{"y": 101.77, "x": -72.637, "feed": 441, "cmd": "move.linear"}
{"y": 101.789, "x": -72.59699999999999, "feed": 276, "cmd": "move.linear"}
{"y": 101.856, "x": -72.592, "feed": 379, "cmd": "move.linear"}
{"y": 101.856, "x": -72.592, "feed": 500, "cmd": "move.linear"}
{"y": 101.953, "x": -72.54900000000001, "feed": 309, "cmd": "move.linear"}
{"y": 101.934, "x": -72.5, "feed": 403, "cmd": "move.linear"}
{"y": 101.868, "x": -72.464, "feed": 585, "cmd": "move.linear"}
{"y": 101.868, "x": -72.464, "feed": 500, "cmd": "move.linear"}
{"y": 101.805, "x": -72.429, "feed": 589, "cmd": "move.linear"}
{"y": 101.794, "x": -72.381, "feed": 362, "cmd": "move.linear"}
{"y": 101.903, "x": -72.34, "feed": 317, "cmd": "move.linear"}
{"y": 101.909, "x": -72.342, "feed": 496, "cmd": "move.linear"}
{"y": 102.053, "x": -72.309, "feed": 342, "cmd": "move.linear"}
{"y": 102.061, "x": -72.26600000000001, "feed": 295, "cmd": "move.linear"}
{"y": 102.003, "x": -72.232, "feed": 591, "cmd": "move.linear"}
{"y": 101.983, "x": -72.22799999999999, "feed": 487, "cmd": "move.linear"}
{"y": 101.907, "x": -72.18899999999999, "feed": 576, "cmd": "move.linear"}
{"y": 101.902, "x": -72.143, "feed": 336, "cmd": "move.linear"}
{"y": 102.053, "x": -72.11199999999999, "feed": 346, "cmd": "move.linear"}
{"y": 102.117, "x": -72.126, "feed": 483, "cmd": "move.linear"}
{"y": 102.359, "x": -72.114, "feed": 386, "cmd": "move.linear"}
{"y": 102.4, "x": -72.078, "feed": 281, "cmd": "move.linear"}
{"y": 102.334, "x": -72.042, "feed": 582, "cmd": "move.linear"}
{"y": 102.186, "x": -72.01000000000001, "feed": 481, "cmd": "move.linear"}
{"y": 102.11, "x": -71.97199999999999, "feed": 575, "cmd": "move.linear"}
{"y": 102.128, "x": -71.931, "feed": 279, "cmd": "move.linear"}
{"y": 102.335, "x": -71.91, "feed": 372, "cmd": "move.linear"}
{"y": 102.51, "x": -71.949, "feed": 480, "cmd": "move.linear"}
{"y": 102.685, "x": -71.98699999999999, "feed": 479.252, "cmd": "move.linear"}
{"y": 102.837, "x": -71.986, "feed": 400, "cmd": "move.linear"}
{"y": 102.988, "x": -71.985, "feed": 399.32, "cmd": "move.linear"}
{"y": 103.073, "x": -71.95699999999999, "feed": 325, "cmd": "move.linear"}
{"y": 103.027, "x": -71.92700000000001, "feed": 595, "cmd": "move.linear"}
{"y": 102.787, "x": -71.875, "feed": 476, "cmd": "move.linear"}
{"y": 102.547, "x": -71.824, "feed": 478.206, "cmd": "move.linear"}
{"y": 102.497, "x": -71.792, "feed": 595, "cmd": "move.linear"}
{"y": 102.572, "x": -71.762, "feed": 316, "cmd": "move.linear"}
{"y": 102.717, "x": -71.76000000000001, "feed": 396, "cmd": "move.linear"}
{"y": 102.861, "x": -71.75700000000001, "feed": 395.288, "cmd": "move.linear"}
{"y": 103.086, "x": -71.80500000000001, "feed": 475, "cmd": "move.linear"}
{"y": 103.311, "x": -71.852, "feed": 474, "cmd": "move.linear"}
{"y": 103.535, "x": -71.898, "feed": 473.54, "cmd": "move.linear"}
{"y": 103.549, "x": -71.88, "feed": 278, "cmd": "move.linear"}
{"y": 103.396, "x": -71.80200000000001, "feed": 573, "cmd": "move.linear"}
{"y": 103.195, "x": -71.727, "feed": 535, "cmd": "move.linear"}
{"y": 102.993, "x": -71.651, "feed": 536.452, "cmd": "move.linear"}
{"y": 102.819, "x": -71.61499999999999, "feed": 475, "cmd": "move.linear"}
{"y": 102.697, "x": -71.568, "feed": 540, "cmd": "move.linear"}
{"y": 102.614, "x": -71.505, "feed": 595, "cmd": "move.linear"}
{"y": 102.597, "x": -71.455, "feed": 396, "cmd": "move.linear"}
{"y": 102.673, "x": -71.45, "feed": 381, "cmd": "move.linear"}
{"y": 102.777, "x": -71.47199999999999, "feed": 475, "cmd": "move.linear"}
{"y": 102.843, "x": -71.465, "feed": 370, "cmd": "move.linear"}
{"y": 102.801, "x": -71.41, "feed": 515, "cmd": "move.linear"}
{"y": 102.694, "x": -71.342, "feed": 594, "cmd": "move.linear"}
{"y": 102.561, "x": -71.29300000000001, "feed": 534, "cmd": "move.linear"}
{"y": 102.494, "x": -71.279, "feed": 477, "cmd": "move.linear"}
{"y": 102.365, "x": -71.23099999999999, "feed": 537, "cmd": "move.linear"}
{"y": 102.265, "x": -71.164, "feed": 597, "cmd": "move.linear"}
{"y": 102.231, "x": -71.111, "feed": 481, "cmd": "move.linear"}
{"y": 102.3, "x": -71.105, "feed": 374, "cmd": "move.linear"}
{"y": 102.344, "x": -71.114, "feed": 476, "cmd": "move.linear"}
{"y": 102.41, "x": -71.107, "feed": 369, "cmd": "move.linear"}
{"y": 102.368, "x": -71.05200000000001, "feed": 516, "cmd": "move.linear"}
{"y": 102.26, "x": -70.98399999999999, "feed": 595, "cmd": "move.linear"}
{"y": 102.128, "x": -70.935, "feed": 536, "cmd": "move.linear"}
{"y": 102.099, "x": -70.929, "feed": 477, "cmd": "move.linear"}
{"y": 101.968, "x": -70.881, "feed": 537, "cmd": "move.linear"}
{"y": 101.864, "x": -70.813, "feed": 598, "cmd": "move.linear"}
{"y": 101.826, "x": -70.76000000000001, "feed": 497, "cmd": "move.linear"}
{"y": 101.893, "x": -70.753, "feed": 372, "cmd": "move.linear"}
{"y": 101.91, "x": -70.756, "feed": 477, "cmd": "move.linear"}
{"y": 101.975, "x": -70.75, "feed": 370, "cmd": "move.linear"}
{"y": 101.934, "x": -70.69499999999999, "feed": 515, "cmd": "move.linear"}
{"y": 101.826, "x": -70.627, "feed": 597, "cmd": "move.linear"}
{"y": 101.692, "x": -70.578, "feed": 537, "cmd": "move.linear"}
{"y": 101.685, "x": -70.57599999999999, "feed": 487, "cmd": "move.linear"}
{"y": 101.553, "x": -70.52800000000001, "feed": 538, "cmd": "move.linear"}
{"y": 101.449, "x": -70.45999999999999, "feed": 599, "cmd": "move.linear"}
{"y": 101.41, "x": -70.407, "feed": 501, "cmd": "move.linear"}
{"y": 101.477, "x": -70.40000000000001, "feed": 371, "cmd": "move.linear"}
{"y": 101.48, "x": -70.401, "feed": 478, "cmd": "move.linear"}
{"y": 101.544, "x": -70.393, "feed": 366, "cmd": "move.linear"}
{"y": 101.502, "x": -70.339, "feed": 515, "cmd": "move.linear"}
{"y": 101.396, "x": -70.271, "feed": 599, "cmd": "move.linear"}
{"y": 101.265, "x": -70.223, "feed": 540, "cmd": "move.linear"}
{"y": 101.264, "x": -70.223, "feed": 478, "cmd": "move.linear"}
{"y": 101.136, "x": -70.175, "feed": 541, "cmd": "move.linear"}
{"y": 101.032, "x": -70.108, "feed": 601, "cmd": "move.linear"}
{"y": 100.992, "x": -70.054, "feed": 506, "cmd": "move.linear"}
{"y": 101.056, "x": -70.047, "feed": 367, "cmd": "move.linear"}
{"y": 101.058, "x": -70.047, "feed": 479, "cmd": "move.linear"}
{"y": 101.119, "x": -70.039, "feed": 364, "cmd": "move.linear"}
{"y": 101.078, "x": -69.985, "feed": 511, "cmd": "move.linear"}
{"y": 100.975, "x": -69.91800000000001, "feed": 601, "cmd": "move.linear"}
{"y": 100.847, "x": -69.871, "feed": 543, "cmd": "move.linear"}
{"y": 100.846, "x": -69.871, "feed": 479, "cmd": "move.linear"}
{"y": 100.72, "x": -69.82299999999999, "feed": 544, "cmd": "move.linear"}
{"y": 100.618, "x": -69.756, "feed": 603, "cmd": "move.linear"}
{"y": 100.579, "x": -69.703, "feed": 505, "cmd": "move.linear"}
{"y": 100.641, "x": -69.69499999999999, "feed": 365, "cmd": "move.linear"}
{"y": 100.641, "x": -69.696, "feed": 480, "cmd": "move.linear"}
{"y": 100.702, "x": -69.688, "feed": 364, "cmd": "move.linear"}
{"y": 100.662, "x": -69.634, "feed": 507, "cmd": "move.linear"}
{"y": 100.56, "x": -69.56699999999999, "feed": 603, "cmd": "move.linear"}
{"y": 100.434, "x": -69.52, "feed": 544, "cmd": "move.linear"}
{"y": 100.434, "x": -69.52, "feed": 480, "cmd": "move.linear"}
{"y": 100.309, "x": -69.473, "feed": 546, "cmd": "move.linear"}
{"y": 100.208, "x": -69.407, "feed": 604, "cmd": "move.linear"}
{"y": 100.17, "x": -69.354, "feed": 500, "cmd": "move.linear"}
{"y": 100.232, "x": -69.346, "feed": 365, "cmd": "move.linear"}
{"y": 100.232, "x": -69.346, "feed": 270, "cmd": "move.linear"}
{"y": 100.293, "x": -69.339, "feed": 365, "cmd": "move.linear"}
{"y": 100.255, "x": -69.285, "feed": 500, "cmd": "move.linear"}
{"y": 100.154, "x": -69.21899999999999, "feed": 604, "cmd": "move.linear"}
{"y": 100.029, "x": -69.172, "feed": 546, "cmd": "move.linear"}
{"y": 100.029, "x": -69.172, "feed": 500, "cmd": "move.linear"}
{"y": 99.904, "x": -69.126, "feed": 547, "cmd": "move.linear"}
{"y": 99.803, "x": -69.059, "feed": 606, "cmd": "move.linear"}
{"y": 99.765, "x": -69.006, "feed": 497, "cmd": "move.linear"}
{"y": 99.827, "x": -68.999, "feed": 365, "cmd": "move.linear"}
{"y": 99.82899999999999, "x": -68.999, "feed": 481, "cmd": "move.linear"}
{"y": 99.89100000000001, "x": -68.992, "feed": 367, "cmd": "move.linear"}
{"y": 99.854, "x": -68.93899999999999, "feed": 494, "cmd": "move.linear"}
{"y": 99.754, "x": -68.873, "feed": 606, "cmd": "move.linear"}
{"y": 99.628, "x": -68.82599999999999, "feed": 548, "cmd": "move.linear"}
{"y": 99.628, "x": -68.82599999999999, "feed": 500, "cmd": "move.linear"}
{"y": 99.503, "x": -68.779, "feed": 548, "cmd": "move.linear"}
{"y": 99.40300000000001, "x": -68.71299999999999, "feed": 607, "cmd": "move.linear"}
{"y": 99.366, "x": -68.66, "feed": 493, "cmd": "move.linear"}
{"y": 99.429, "x": -68.65300000000001, "feed": 367, "cmd": "move.linear"}
{"y": 99.431, "x": -68.654, "feed": 482, "cmd": "move.linear"}
{"y": 99.495, "x": -68.64700000000001, "feed": 369, "cmd": "move.linear"}
{"y": 99.45999999999999, "x": -68.59399999999999, "feed": 486, "cmd": "move.linear"}
{"y": 99.36, "x": -68.52800000000001, "feed": 608, "cmd": "move.linear"}
{"y": 99.23399999999999, "x": -68.482, "feed": 548, "cmd": "move.linear"}
{"y": 99.23399999999999, "x": -68.482, "feed": 500, "cmd": "move.linear"}
{"y": 99.108, "x": -68.435, "feed": 549, "cmd": "move.linear"}
{"y": 99.009, "x": -68.369, "feed": 609, "cmd": "move.linear"}
{"y": 98.973, "x": -68.316, "feed": 484, "cmd": "move.linear"}
{"y": 99.038, "x": -68.31, "feed": 369, "cmd": "move.linear"}
{"y": 99.04000000000001, "x": -68.31, "feed": 483, "cmd": "move.linear"}
{"y": 99.10599999999999, "x": -68.304, "feed": 371, "cmd": "move.linear"}
{"y": 99.072, "x": -68.252, "feed": 478, "cmd": "move.linear"}
{"y": 98.973, "x": -68.18600000000001, "feed": 609, "cmd": "move.linear"}
{"y": 98.846, "x": -68.139, "feed": 549, "cmd": "move.linear"}
{"y": 98.846, "x": -68.139, "feed": 483, "cmd": "move.linear"}
{"y": 98.718, "x": -68.092, "feed": 549, "cmd": "move.linear"}
{"y": 98.62, "x": -68.026, "feed": 610, "cmd": "move.linear"}
{"y": 98.586, "x": -67.97499999999999, "feed": 473, "cmd": "move.linear"}
{"y": 98.654, "x": -67.96899999999999, "feed": 373, "cmd": "move.linear"}
{"y": 98.655, "x": -67.96899999999999, "feed": 484, "cmd": "move.linear"}
{"y": 98.723, "x": -67.96299999999999, "feed": 374, "cmd": "move.linear"}
{"y": 98.691, "x": -67.91200000000001, "feed": 469, "cmd": "move.linear"}
{"y": 98.593, "x": -67.846, "feed": 611, "cmd": "move.linear"}
{"y": 98.465, "x": -67.79900000000001, "feed": 551, "cmd": "move.linear"}
{"y": 98.46299999999999, "x": -67.79900000000001, "feed": 484, "cmd": "move.linear"}
{"y": 98.33499999999999, "x": -67.751, "feed": 551, "cmd": "move.linear"}
{"y": 98.236, "x": -67.68600000000001, "feed": 612, "cmd": "move.linear"}
{"y": 98.20399999999999, "x": -67.634, "feed": 464, "cmd": "move.linear"}
{"y": 98.274, "x": -67.629, "feed": 375, "cmd": "move.linear"}
{"y": 98.27500000000001, "x": -67.629, "feed": 419, "cmd": "move.linear"}
{"y": 98.346, "x": -67.624, "feed": 378, "cmd": "move.linear"}
{"y": 98.315, "x": -67.57299999999999, "feed": 457, "cmd": "move.linear"}
{"y": 98.217, "x": -67.508, "feed": 612, "cmd": "move.linear"}
{"y": 98.08799999999999, "x": -67.45999999999999, "feed": 551, "cmd": "move.linear"}
{"y": 98.087, "x": -67.45999999999999, "feed": 485, "cmd": "move.linear"}
{"y": 97.95699999999999, "x": -67.41200000000001, "feed": 551, "cmd": "move.linear"}
{"y": 97.86, "x": -67.34699999999999, "feed": 613, "cmd": "move.linear"}
{"y": 97.82899999999999, "x": -67.29600000000001, "feed": 457, "cmd": "move.linear"}
{"y": 97.901, "x": -67.291, "feed": 377, "cmd": "move.linear"}
{"y": 97.902, "x": -67.292, "feed": 542, "cmd": "move.linear"}
{"y": 97.97499999999999, "x": -67.28700000000001, "feed": 379, "cmd": "move.linear"}
{"y": 97.94499999999999, "x": -67.236, "feed": 449, "cmd": "move.linear"}
{"y": 97.849, "x": -67.17100000000001, "feed": 613, "cmd": "move.linear"}
{"y": 97.71899999999999, "x": -67.124, "feed": 552, "cmd": "move.linear"}
{"y": 97.71599999999999, "x": -67.123, "feed": 486, "cmd": "move.linear"}
{"y": 97.587, "x": -67.075, "feed": 552, "cmd": "move.linear"}
{"y": 97.48999999999999, "x": -67.011, "feed": 615, "cmd": "move.linear"}
{"y": 97.461, "x": -66.95999999999999, "feed": 447, "cmd": "move.linear"}
{"y": 97.533, "x": -66.955, "feed": 379, "cmd": "move.linear"}
{"y": 97.53700000000001, "x": -66.956, "feed": 486, "cmd": "move.linear"}
{"y": 97.61, "x": -66.95099999999999, "feed": 379, "cmd": "move.linear"}
{"y": 97.58199999999999, "x": -66.901, "feed": 443, "cmd": "move.linear"}
{"y": 97.48699999999999, "x": -66.837, "feed": 615, "cmd": "move.linear"}
{"y": 97.358, "x": -66.79000000000001, "feed": 553, "cmd": "move.linear"}
{"y": 97.352, "x": -66.788, "feed": 486, "cmd": "move.linear"}
{"y": 97.223, "x": -66.741, "feed": 554, "cmd": "move.linear"}
{"y": 97.128, "x": -66.67700000000001, "feed": 616, "cmd": "move.linear"}
{"y": 97.09999999999999, "x": -66.627, "feed": 440, "cmd": "move.linear"}
{"y": 97.173, "x": -66.622, "feed": 379, "cmd": "move.linear"}
{"y": 97.181, "x": -66.624, "feed": 497, "cmd": "move.linear"}
{"y": 97.255, "x": -66.619, "feed": 380, "cmd": "move.linear"}
{"y": 97.227, "x": -66.569, "feed": 440, "cmd": "move.linear"}
{"y": 97.131, "x": -66.504, "feed": 616, "cmd": "move.linear"}
{"y": 97.002, "x": -66.45699999999999, "feed": 554, "cmd": "move.linear"}
{"y": 96.996, "x": -66.456, "feed": 473, "cmd": "move.linear"}
{"y": 96.86799999999999, "x": -66.408, "feed": 556, "cmd": "move.linear"}
{"y": 96.773, "x": -66.34399999999999, "feed": 617, "cmd": "move.linear"}
{"y": 96.747, "x": -66.295, "feed": 432, "cmd": "move.linear"}
{"y": 96.821, "x": -66.29000000000001, "feed": 381, "cmd": "move.linear"}
{"y": 96.825, "x": -66.291, "feed": 468, "cmd": "move.linear"}
{"y": 96.899, "x": -66.28700000000001, "feed": 381, "cmd": "move.linear"}
{"y": 96.874, "x": -66.23699999999999, "feed": 428, "cmd": "move.linear"}
{"y": 96.78, "x": -66.17400000000001, "feed": 617, "cmd": "move.linear"}
{"y": 96.652, "x": -66.126, "feed": 556, "cmd": "move.linear"}
{"y": 96.64700000000001, "x": -66.125, "feed": 488, "cmd": "move.linear"}
{"y": 96.51900000000001, "x": -66.078, "feed": 557, "cmd": "move.linear"}
{"y": 96.42700000000001, "x": -66.015, "feed": 618, "cmd": "move.linear"}
{"y": 96.401, "x": -65.965, "feed": 422, "cmd": "move.linear"}
{"y": 96.476, "x": -65.961, "feed": 383, "cmd": "move.linear"}
{"y": 96.479, "x": -65.962, "feed": 488, "cmd": "move.linear"}
{"y": 96.554, "x": -65.95699999999999, "feed": 381, "cmd": "move.linear"}
{"y": 96.529, "x": -65.908, "feed": 420, "cmd": "move.linear"}
{"y": 96.437, "x": -65.845, "feed": 618, "cmd": "move.linear"}
{"y": 96.309, "x": -65.798, "feed": 557, "cmd": "move.linear"}
{"y": 96.307, "x": -65.797, "feed": 488, "cmd": "move.linear"}
{"y": 96.179, "x": -65.75, "feed": 558, "cmd": "move.linear"}
{"y": 96.087, "x": -65.687, "feed": 620, "cmd": "move.linear"}
{"y": 96.062, "x": -65.63800000000001, "feed": 417, "cmd": "move.linear"}
{"y": 96.137, "x": -65.634, "feed": 381, "cmd": "move.linear"}
{"y": 96.14100000000001, "x": -65.634, "feed": 489, "cmd": "move.linear"}
{"y": 96.215, "x": -65.63, "feed": 381, "cmd": "move.linear"}
{"y": 96.191, "x": -65.581, "feed": 415, "cmd": "move.linear"}
{"y": 96.09999999999999, "x": -65.518, "feed": 619, "cmd": "move.linear"}
{"y": 95.974, "x": -65.471, "feed": 559, "cmd": "move.linear"}
{"y": 95.97199999999999, "x": -65.471, "feed": 532, "cmd": "move.linear"}
{"y": 95.848, "x": -65.425, "feed": 560, "cmd": "move.linear"}
{"y": 95.759, "x": -65.36199999999999, "feed": 620, "cmd": "move.linear"}
{"y": 95.736, "x": -65.31399999999999, "feed": 407, "cmd": "move.linear"}
{"y": 95.81, "x": -65.309, "feed": 380, "cmd": "move.linear"}
{"y": 95.812, "x": -65.31, "feed": 489, "cmd": "move.linear"}
{"y": 95.884, "x": -65.30500000000001, "feed": 379, "cmd": "move.linear"}
{"y": 95.861, "x": -65.256, "feed": 413, "cmd": "move.linear"}
{"y": 95.77200000000001, "x": -65.194, "feed": 620, "cmd": "move.linear"}
{"y": 95.648, "x": -65.148, "feed": 562, "cmd": "move.linear"}
{"y": 95.646, "x": -65.14700000000001, "feed": 489, "cmd": "move.linear"}
{"y": 95.526, "x": -65.102, "feed": 563, "cmd": "move.linear"}
{"y": 95.43899999999999, "x": -65.04000000000001, "feed": 620, "cmd": "move.linear"}
{"y": 95.417, "x": -64.991, "feed": 403, "cmd": "move.linear"}
{"y": 95.489, "x": -64.98699999999999, "feed": 378, "cmd": "move.linear"}
{"y": 95.492, "x": -64.988, "feed": 518, "cmd": "move.linear"}
{"y": 95.56100000000001, "x": -64.982, "feed": 374, "cmd": "move.linear"}
{"y": 95.53700000000001, "x": -64.93300000000001, "feed": 414, "cmd": "move.linear"}
{"y": 95.45099999999999, "x": -64.871, "feed": 620, "cmd": "move.linear"}
{"y": 95.331, "x": -64.82599999999999, "feed": 564, "cmd": "move.linear"}
{"y": 95.328, "x": -64.825, "feed": 514, "cmd": "move.linear"}
{"y": 95.212, "x": -64.78100000000001, "feed": 567, "cmd": "move.linear"}
{"y": 95.129, "x": -64.72, "feed": 619, "cmd": "move.linear"}
{"y": 95.107, "x": -64.672, "feed": 402, "cmd": "move.linear"}
{"y": 95.175, "x": -64.666, "feed": 373, "cmd": "move.linear"}
{"y": 95.18000000000001, "x": -64.667, "feed": 490, "cmd": "move.linear"}
{"y": 95.24299999999999, "x": -64.661, "feed": 366, "cmd": "move.linear"}
{"y": 95.218, "x": -64.61199999999999, "feed": 420, "cmd": "move.linear"}
{"y": 95.134, "x": -64.55, "feed": 620, "cmd": "move.linear"}
{"y": 95.021, "x": -64.50700000000001, "feed": 568, "cmd": "move.linear"}
{"y": 95.014, "x": -64.505, "feed": 503, "cmd": "move.linear"}
{"y": 94.907, "x": -64.46299999999999, "feed": 574, "cmd": "move.linear"}
{"y": 94.82899999999999, "x": -64.40300000000001, "feed": 616, "cmd": "move.linear"}
{"y": 94.806, "x": -64.354, "feed": 406, "cmd": "move.linear"}
{"y": 94.867, "x": -64.34699999999999, "feed": 363, "cmd": "move.linear"}
{"y": 94.874, "x": -64.349, "feed": 490, "cmd": "move.linear"}
{"y": 94.928, "x": -64.34, "feed": 351, "cmd": "move.linear"}
{"y": 94.899, "x": -64.291, "feed": 437, "cmd": "move.linear"}
{"y": 94.819, "x": -64.23, "feed": 618, "cmd": "move.linear"}
{"y": 94.715, "x": -64.18899999999999, "feed": 577, "cmd": "move.linear"}
{"y": 94.708, "x": -64.187, "feed": 491, "cmd": "move.linear"}
{"y": 94.613, "x": -64.14700000000001, "feed": 584, "cmd": "move.linear"}
{"y": 94.539, "x": -64.08799999999999, "feed": 611, "cmd": "move.linear"}
{"y": 94.515, "x": -64.04000000000001, "feed": 415, "cmd": "move.linear"}
{"y": 94.566, "x": -64.03100000000001, "feed": 345, "cmd": "move.linear"}
{"y": 94.572, "x": -64.032, "feed": 491, "cmd": "move.linear"}
{"y": 94.617, "x": -64.021, "feed": 332, "cmd": "move.linear"}
{"y": 94.586, "x": -63.971, "feed": 448, "cmd": "move.linear"}
{"y": 94.51000000000001, "x": -63.912, "feed": 614, "cmd": "move.linear"}
{"y": 94.41800000000001, "x": -63.873, "feed": 587, "cmd": "move.linear"}
{"y": 94.414, "x": -63.872, "feed": 471, "cmd": "move.linear"}
{"y": 94.32599999999999, "x": -63.834, "feed": 592, "cmd": "move.linear"}
{"y": 94.256, "x": -63.776, "feed": 607, "cmd": "move.linear"}
{"y": 94.229, "x": -63.727, "feed": 427, "cmd": "move.linear"}
{"y": 94.27200000000001, "x": -63.716, "feed": 329, "cmd": "move.linear"}
{"y": 94.27200000000001, "x": -63.716, "feed": 500, "cmd": "move.linear"}
{"y": 94.316, "x": -63.705, "feed": 328, "cmd": "move.linear"}
{"y": 94.289, "x": -63.656, "feed": 426, "cmd": "move.linear"}
{"y": 94.21899999999999, "x": -63.598, "feed": 606, "cmd": "move.linear"}
{"y": 94.13200000000001, "x": -63.56, "feed": 592, "cmd": "move.linear"}
{"y": 94.131, "x": -63.56, "feed": 375, "cmd": "move.linear"}
{"y": 94.04300000000001, "x": -63.522, "feed": 592, "cmd": "move.linear"}
{"y": 93.97199999999999, "x": -63.463, "feed": 608, "cmd": "move.linear"}
{"y": 93.94499999999999, "x": -63.414, "feed": 428, "cmd": "move.linear"}
{"y": 93.988, "x": -63.403, "feed": 329, "cmd": "move.linear"}
{"y": 94.0, "x": -63.406, "feed": 491, "cmd": "move.linear"}
{"y": 94.065, "x": -63.4, "feed": 368, "cmd": "move.linear"}
{"y": 94.071, "x": -63.357, "feed": 278, "cmd": "move.linear"}
{"y": 94.026, "x": -63.304, "feed": 523, "cmd": "move.linear"}
{"y": 93.943, "x": -63.268, "feed": 596, "cmd": "move.linear"}
{"y": 93.89400000000001, "x": -63.257, "feed": 491, "cmd": "move.linear"}
{"y": 93.771, "x": -63.212, "feed": 568, "cmd": "move.linear"}
{"y": 93.69, "x": -63.152, "feed": 622, "cmd": "move.linear"}
{"y": 93.678, "x": -63.106, "feed": 344, "cmd": "move.linear"}
{"y": 93.76000000000001, "x": -63.103, "feed": 388, "cmd": "move.linear"}
{"y": 94.021, "x": -63.157, "feed": 490, "cmd": "move.linear"}
{"y": 94.282, "x": -63.21, "feed": 489, "cmd": "move.linear"}
{"y": 94.542, "x": -63.262, "feed": 487.635, "cmd": "move.linear"}
{"y": 94.798, "x": -63.249, "feed": 383, "cmd": "move.linear"}
{"y": 94.84699999999999, "x": -63.214, "feed": 274, "cmd": "move.linear"}
{"y": 94.78400000000001, "x": -63.182, "feed": 611, "cmd": "move.linear"}
{"y": 94.49299999999999, "x": -63.125, "feed": 485, "cmd": "move.linear"}
{"y": 94.202, "x": -63.066, "feed": 487, "cmd": "move.linear"}
{"y": 93.90900000000001, "x": -63.007, "feed": 489, "cmd": "move.linear"}
{"y": 93.616, "x": -62.947, "feed": 491, "cmd": "move.linear"}
{"y": 93.322, "x": -62.886, "feed": 492.87, "cmd": "move.linear"}
{"y": 92.961, "x": -62.747, "feed": 577, "cmd": "move.linear"}
{"y": 92.84, "x": -62.678, "feed": 631, "cmd": "move.linear"}
{"y": 92.873, "x": -62.666, "feed": 303, "cmd": "move.linear"}
{"y": 93.122, "x": -62.718, "feed": 495, "cmd": "move.linear"}
{"y": 93.37, "x": -62.769, "feed": 493, "cmd": "move.linear"}
{"y": 93.617, "x": -62.82, "feed": 491.971, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 94.60599999999999, "x": -63.019, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 94.866, "x": -63.069, "feed": 484, "cmd": "move.linear"}
{"y": 94.958, "x": -63.067, "feed": 391, "cmd": "move.linear"}
{"y": 94.994, "x": -63.03, "feed": 262, "cmd": "move.linear"}
{"y": 94.97199999999999, "x": -62.981, "feed": 401, "cmd": "move.linear"}
{"y": 94.887, "x": -62.945, "feed": 586, "cmd": "move.linear"}
{"y": 94.866, "x": -62.941, "feed": 486, "cmd": "move.linear"}
{"y": 94.798, "x": -62.908, "feed": 606, "cmd": "move.linear"}
{"y": 94.785, "x": -62.861, "feed": 354, "cmd": "move.linear"}
{"y": 94.895, "x": -62.818, "feed": 304, "cmd": "move.linear"}
{"y": 94.895, "x": -62.818, "feed": 500, "cmd": "move.linear"}
{"y": 94.961, "x": -62.81, "feed": 362, "cmd": "move.linear"}
{"y": 94.97199999999999, "x": -62.768, "feed": 268, "cmd": "move.linear"}
{"y": 94.93600000000001, "x": -62.716, "feed": 484, "cmd": "move.linear"}
{"y": 94.858, "x": -62.682, "feed": 593, "cmd": "move.linear"}
{"y": 94.857, "x": -62.681, "feed": 481, "cmd": "move.linear"}
{"y": 94.77200000000001, "x": -62.645, "feed": 586, "cmd": "move.linear"}
{"y": 94.71899999999999, "x": -62.591, "feed": 561, "cmd": "move.linear"}
{"y": 94.714, "x": -62.545, "feed": 313, "cmd": "move.linear"}
{"y": 94.773, "x": -62.537, "feed": 353, "cmd": "move.linear"}
{"y": 94.783, "x": -62.538, "feed": 472, "cmd": "move.linear"}
{"y": 94.845, "x": -62.53, "feed": 356, "cmd": "move.linear"}
{"y": 94.83199999999999, "x": -62.483, "feed": 352, "cmd": "move.linear"}
{"y": 94.76600000000001, "x": -62.426, "feed": 600, "cmd": "move.linear"}
{"y": 94.667, "x": -62.388, "feed": 574, "cmd": "move.linear"}
{"y": 94.657, "x": -62.386, "feed": 480, "cmd": "move.linear"}
{"y": 94.554, "x": -62.346, "feed": 571, "cmd": "move.linear"}
{"y": 94.473, "x": -62.287, "feed": 621, "cmd": "move.linear"}
{"y": 94.444, "x": -62.237, "feed": 440, "cmd": "move.linear"}
{"y": 94.497, "x": -62.227, "feed": 341, "cmd": "move.linear"}
{"y": 94.505, "x": -62.228, "feed": 481, "cmd": "move.linear"}
{"y": 94.54300000000001, "x": -62.215, "feed": 313, "cmd": "move.linear"}
{"y": 94.49299999999999, "x": -62.161, "feed": 552, "cmd": "move.linear"}
{"y": 94.288, "x": -62.058, "feed": 611, "cmd": "move.linear"}
{"y": 94.286, "x": -62.058, "feed": 481, "cmd": "move.linear"}
{"y": 94.068, "x": -61.953, "feed": 607, "cmd": "move.linear"}
{"y": 94.006, "x": -61.897, "feed": 590, "cmd": "move.linear"}
{"y": 94.038, "x": -61.883, "feed": 296, "cmd": "move.linear"}
{"y": 94.041, "x": -61.883, "feed": 512, "cmd": "move.linear"}
{"y": 94.06699999999999, "x": -61.868, "feed": 283, "cmd": "move.linear"}
{"y": 93.997, "x": -61.811, "feed": 609, "cmd": "move.linear"}
{"y": 93.76900000000001, "x": -61.704, "feed": 605, "cmd": "move.linear"}
{"y": 93.76900000000001, "x": -61.704, "feed": 500, "cmd": "move.linear"}
{"y": 93.526, "x": -61.593, "feed": 601, "cmd": "move.linear"}
{"y": 93.44499999999999, "x": -61.534, "feed": 624, "cmd": "move.linear"}
{"y": 93.467, "x": -61.518, "feed": 270, "cmd": "move.linear"}
{"y": 93.476, "x": -61.52, "feed": 484, "cmd": "move.linear"}
{"y": 93.508, "x": -61.506, "feed": 296, "cmd": "move.linear"}
{"y": 93.435, "x": -61.448, "feed": 614, "cmd": "move.linear"}
{"y": 93.191, "x": -61.337, "feed": 602, "cmd": "move.linear"}
{"y": 93.176, "x": -61.334, "feed": 485, "cmd": "move.linear"}
{"y": 92.89400000000001, "x": -61.216, "feed": 592, "cmd": "move.linear"}
{"y": 92.81, "x": -61.157, "feed": 629, "cmd": "move.linear"}
{"y": 92.84699999999999, "x": -61.144, "feed": 309, "cmd": "move.linear"}
{"y": 93.00700000000001, "x": -61.175, "feed": 486, "cmd": "move.linear"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(False)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 93.623, "x": -60.515, "cmd": "move.rapid"}
{"seconds": 0.2, "cmd": "sleep"}
{"eval": "set_pen(True)", "cmd": "eval"}
{"seconds": 0.2, "cmd": "sleep"}
{"y": 93.739, "x": -60.715, "feed": 438, "cmd": "move.linear"}
{"y": 93.854, "x": -60.915, "feed": 437, "cmd": "move.linear"}
{"y": 93.96899999999999, "x": -61.114, "feed": 436.401, "cmd": "move.linear"}
{"y": 94.158, "x": -61.353, "feed": 509, "cmd": "move.linear"}
{"y": 94.34699999999999, "x": -61.591, "feed": 508, "cmd": "move.linear"}
{"y": 94.535, "x": -61.829, "feed": 507.605, "cmd": "move.linear"}
{"y": 94.753, "x": -62.061, "feed": 551, "cmd": "move.linear"}
{"y": 94.97, "x": -62.294, "feed": 550, "cmd": "move.linear"}
{"y": 95.18600000000001, "x": -62.526, "feed": 549, "cmd": "move.linear"}
{"y": 95.402, "x": -62.759, "feed": 548.999, "cmd": "move.linear"}
{"y": 95.652, "x": -63.007, "feed": 568, "cmd": "move.linear"}
{"y": 95.901, "x": -63.256, "feed": 567, "cmd": "move.linear"}
{"y": 96.149, "x": -63.504, "feed": 566, "cmd": "move.linear"}
{"y": 96.396, "x": -63.753, "feed": 565, "cmd": "move.linear"}
{"y": 96.642, "x": -64.002, "feed": 564.742, "cmd": "move.linear"}
{"y": 96.911, "x": -64.258, "feed": 577, "cmd": "move.linear"}
{"y": 97.178, "x": -64.51300000000001, "feed": 576, "cmd": "move.linear"}
{"y": 97.444, "x": -64.76900000000001, "feed": 575.42, "cmd": "move.linear"}
{"y": 97.747, "x": -65.042, "feed": 587, "cmd": "move.linear"}
{"y": 98.04900000000001, "x": -65.316, "feed": 585, "cmd": "move.linear"}
{"y": 98.349, "x": -65.589, "feed": 584.927, "cmd": "move.linear"}
{"y": 98.59999999999999, "x": -65.806, "feed": 592, "cmd": "move.linear"}
{"y": 98.84999999999999, "x": -66.02200000000001, "feed": 591, "cmd": "move.linear"}
{"y": 99.099, "x": -66.239, "feed": 591, "cmd": "move.linear"}
{"y": 99.348, "x": -66.456, "feed": 590.255, "cmd": "move.linear"}
{"y": 99.619, "x": -66.68300000000001, "feed": 595, "cmd": "move.linear"}
{"y": 99.89, "x": -66.91, "feed": 594, "cmd": "move.linear"}
{"y": 100.16, "x": -67.137, "feed": 593, "cmd": "move.linear"}
{"y": 100.43, "x": -67.364, "feed": 592.8200000000001, "cmd": "move.linear"}
{"y": 100.73, "x": -67.604, "feed": 597, "cmd": "move.linear"}
{"y": 101.029, "x": -67.843, "feed": 596, "cmd": "move.linear"}
{"y": 101.327, "x": -68.083, "feed": 595, "cmd": "move.linear"}
{"y": 101.624, "x": -68.322, "feed": 594, "cmd": "move.linear"}
{"y": 101.921, "x": -68.562, "feed": 594, "cmd": "move.linear"}
{"y": 102.216, "x": -68.80200000000001, "feed": 593, "cmd": "move.linear"}
{"y": 102.511, "x": -69.04300000000001, "feed": 592, "cmd": "move.linear"}
{"y": 102.805, "x": -69.283, "feed": 591.477, "cmd": "move.linear"}
{"y": 103.133, "x": -69.535, "feed": 594, "cmd": "move.linear"}
{"y": 103.46, "x": -69.78700000000001, "feed": 593, "cmd": "move.linear"}
{"y": 103.787, "x": -70.039, "feed": 592, "cmd": "move.linear"}
{"y": 104.112, "x": -70.291, "feed": 591, "cmd": "move.linear"}
{"y": 104.436, "x": -70.54300000000001, "feed": 590, "cmd": "move.linear"}
{"y": 104.76, "x": -70.79600000000001, "feed": 589, "cmd": "move.linear"}
{"y": 105.082, "x": -71.04900000000001, "feed": 589, "cmd": "move.linear"}
{"y": 105.404, "x": -71.30200000000001, "feed": 588.22, "cmd": "move.linear"}
{"y": 105.713, "x": -71.53100000000001, "feed": 588, "cmd": "move.linear"}
{"y": 106.021, "x": -71.761, "feed": 587, "cmd": "move.linear"}
{"y": 106.329, "x": -71.991, "feed": 587, "cmd": "move.linear"}
{"y": 106.636, "x": -72.221, "feed": 586, "cmd": "move.linear"}
{"y": 106.941, "x": -72.45099999999999, "feed": 585, "cmd": "move.linear"}
{"y": 107.247, "x": -72.682, "feed": 584, "cmd": "move.linear"}
{"y": 107.551, "x": -72.913, "feed": 583, "cmd": "move.linear"}
{"y": 107.855, "x": -73.143, "feed": 583, "cmd": "move.linear"}
{"y": 108.158, "x": -73.374, "feed": 582.475, "cmd": "move.linear"}
{"y": 108.477, "x": -73.605, "feed": 581, "cmd": "move.linear"}
{"y": 108.796, "x": -73.836, "feed": 580, "cmd": "move.linear"}
{"y": 109.114, "x": -74.066, "feed": 579, "cmd": "move.linear"}
{"y": 109.431, "x": -74.297, "feed": 578, "cmd": "move.linear"}
...
This file has been truncated, please download it to see its full contents.
Comments
Please log in or sign up to comment.
