DeterFuga

Intelligent Flow Monitoring System with Predictive Analytics

We have developed a comprehensive solution that democratizes access to advanced water monitoring technology by combining:

Affordable hardware: Using ESP32 XIAO, inexpensive flow sensors, and standard components with an approximate cost of 350, 000 pesos per system

A capacitor

A 5V power supply

Resistors

Intelligent backend: Automatic analysis platform that detects anomalous patterns and predicts potential leaks before they become apparent

The Python backend used a database with the following initial schema

The frontend allows for a pleasant understanding of the

##code

#include <WiFi.h>

#include <HTTPClient.h>

// Wi-Fi credentials

const char* ssid = "Hacking";

const char* password = "overpatojito";

// Backend URL

const char* serverUrl = "http://192.168.248.49:8000/flujo";

// Pin del potenciómetro

const int potPin = A0;

float flujoAnterior = -1; // Valor anterior del flujo

const float delta = 10; // Umbral de cambio mínimo (%)

void setup() {

Serial.begin(115200);

delay(1000);

WiFi.begin(ssid, password);

Serial.print("Conectando a WiFi...");

while (WiFi.status() != WL_CONNECTED) {

delay(500);

Serial.print(".");

}

Serial.println("\nConectado a WiFi");

}

void loop() {

// Leer y mapear el valor del potenciómetro

int potValue = analogRead(potPin);

float flujoActual = map(potValue, 0, 4095, 0, 100); // Valor de 0 a 100%

// Comprobar si cambió significativamente

if (abs(flujoActual - flujoAnterior) >= delta) {

flujoAnterior = flujoActual;

Serial.print("Flujo de agua: ");

Serial.println(flujoActual);

if (WiFi.status() == WL_CONNECTED) {

HTTPClient http;

http.begin(serverUrl);

http.addHeader("Content-Type", "application/json");

String jsonPayload = "{\"flujo\":" + String(flujoActual) + "}";

int httpResponseCode = http.POST(jsonPayload);

if (httpResponseCode > 0) {

String response = http.getString();

Serial.println("Respuesta del servidor: " + response);

} else {

Serial.print("Error al enviar datos. Código: ");

Serial.println(httpResponseCode);

}

http.end();

} else {

Serial.println("WiFi desconectado");

}

} else {

Serial.println("Sin cambio en el flujo.");

}

delay(500); // Revisa cada 0.5 segundos

}
