Particle Photon Mail Detector Fall 2018 3171

Do you ever wonder when the mail man delivers your mail? Well worry no more, we have the device for you.

Beginner24 hours667

Particle Photon Mail Detector Fall 2018 3171

Things used in this project

Hardware components

Particle Photon

Seeed Studio Grove - PIR Motion Sensor

Male/Male Jumper Wires

Male/Female Jumper Wires

Adafruit SSD1306 OLED Display

Micro-USB to USB Cable (Generic)

Solderless Breadboard Half Size

Software apps and online services

Particle Pi

Fritzing

IFTTT Maker service

Story

We designed and developed a device for the busy person who doesn't want to sit around waiting for the mail. This device will notify you on the display when, ail has been received, as well as keep track of what time it was delivered. This allows you to learn the mail mans schedule so you can plan mail deliveries accordingly.

How It Works:

The first particle is used to detect motion by using a PIR motion sensor. when the motion sensor detects motion, such as the mail box door opening and mail being placed inside, it publishes an event to that is then received by the second photon. This is displayed in the video below. Once this event is received the second photon sends a message back allowing the first photon to publish another event keeping track of what time the mail was detected through If This Than That.

https://docs.google.com/spreadsheets/d/1XvD2uGaHXLkhpxz40Ojd75yS90qVXdyV21bdZU9l2TI/edit?usp=sharing

The second photon controls the OLED display which displays the text "you have mail." The text will display on the screen once motion has been detected and this is what will notify the owner if mail has been delivered. The message will only display for a short while and once it turns off it publishes an event for the first photon to receive. This message resets the first photon and allows it to restart the cycle for the next time mail is put into your mailbox.

Code

// This #include statement was automatically added by the Particle IDE.
#include <Adafruit_SSD1306.h>


int PIRSensor = D0;
int led = D7;
int var=0;
int last=0;

void setup()
{
    pinMode(led, OUTPUT);
    Particle.subscribe("LEDoff2018", myHandler, "2f0017000d47363330353437");

}

void myHandler(const char *event, const char *data)
{
    digitalWrite(led, LOW);
}

void loop() {

    var=digitalRead(PIRSensor);
    if((digitalRead(PIRSensor) == HIGH) && (last == LOW))
    {
        digitalWrite(led, HIGH);


        String data = String(var);
        // stuff happens here

        Particle.publish("YHM2018", "motion is detected");

    }

    last = var;

    if(digitalRead(PIRSensor) == LOW)
    {
        last = 0;

    }
    delay(10000);
}

// This #include statement was automatically added by the Particle IDE.
#include <Adafruit_SSD1306.h>


// use hardware SPI
#define OLED_DC     D3
#define OLED_CS     D4
#define OLED_RESET  D5
Adafruit_SSD1306 display(OLED_DC, OLED_RESET, OLED_CS);


//int  x, minX; // variables for scrolling code

void setup() {

    Particle.subscribe("YHM2018", myHandler, "2f0021000d47363330353437");


}

void loop() {delay(1);
}

void myHandler(const char *event, const char *data) {

  display.begin(SSD1306_SWITCHCAPVCC);


 display.setTextSize(2);       // text size
  display.setTextColor(WHITE); // text color
  display.clearDisplay();
  display.println("You Have");
  display.println("Mail");
  display.display();
  delay(10000);

  display.setCursor(0,0);
  display.clearDisplay();
  display.display();

Particle.publish("LEDoff2018", "led off");
}
