Smart Basketball Scoreboard

What if an Arduino/Android solution was added to a regular basketball board to track my basketball training workouts? Let's go for it!

IntermediateFull instructions providedOver 1 day15,165

Things used in this project

Hardware components

Arduino Nano R3

HC-05 Bluetooth Module

E18-D80NK Infrared Proximity Sensor

Seeed Studio Grove - Vibration Sensor (SW-420)

DHT22 Temperature Sensor

8mm RGB LED

Resistor 10k ohm

Resistor 100 ohm

Through Hole Resistor, 47 ohm

Resistor 1k ohm

Resistor 2.21k ohm

9V battery (generic)

Software apps and online services

Arduino IDE

MIT App Inventor Android IDE

Story

I do basketball training workouts regularly and always track the sections' statistics (number of shots, scores, misses, etc). Track these numbers is kind of boring and hard to accomplish. The smart balls can be used for this but they have some drawbacks:

If you want to train with multiple balls you'll need to buy several (expensive) smart balls.
The accuracy isn't so good.
The durability of the ball.

In my previous project smart basketball scoreboard prototype, I used the Avnet SmartEdge device to test a method to track my basketball workouts. I used the acceleration sensor to detect the shots and the proximity sensor to detect the scores. Now, the idea of this project is to implement a definitive solution for the basketball scoreboard task.

Versions

1.x.x

At the beginning of the project, I used the hardware components I had available at home and developed the software (Arduino and Android) needed. After some tentatives and tests, the first version proved to work pretty well.

2.x.x

With the success of the first version, I decided to make some changes to use cheaper components and to implement some software improvements too. The second version showed to be even better, so I mounted it in a more robust, durable, and "definitive" enclosure. Note: It isn't "professional", but it's very better than the old model.

Step 1: Arduino

Hardware

You can see the hardware components list for version 2 in the Things section.

These are the main changes made from version 1 to version 2:

Arduino Mega 2560 => Changed to Arduino Nano R3
Bluetooth Shield => Changed to HC-05 Bluetooth Module
Rechargeable Li-ion Power => Changed to 9V Battery
DHT22 Temperature & Humidity Sensor => Added.

Some considerations about other components used in this project:

E18-D80NK Infrared Proximity Sensor: Other proximity sensors could be used in this project, but have in mind that it's better to use one that doesn't suffer from sunlight interference, like this one.
SW420 Vibration Sensor: Other vibration sensors could be used in this project, this one works really well.

The Arduino schematics for the two versions are available in the Schematics section.

Software

I used the Arduino IDE to develop the Arduino code, programmed with the following strategy:

After the initialization (variables, LED, Bluetooth, etc) it stays continuously monitoring the status of the sensors.
If the proximity sensor detects the presence of the ball, it means a shot has just happened and it's a score.
If the vibration sensor detects some movement, it means a shot has just happened but it waits for 2 seconds (maximum) to make a decision.
In this time, if the proximity sensor detects the presence of the ball, it (immediately) knows it's a score.
At the end of the 2 seconds time, if the proximity sensor didn't detect the presence of the ball, it knows it's a miss.
The Arduino informs the Android through Bluetooth that a shot (score or miss) has just happened.
The process restarts.

These are the main changes made from version 1 to version 2:

Change support from Bluetooth shield to HC-05 Bluetooth module
Add support to DHT22 Temperature & Humidity sensor
Improve the logic to detect shots, scores, and misses and to better signal through the LED.

The Arduino codes for the two versions are available in the Code section.

Step 2: Android

I used the MIT App Inventor to develop the Android code, programmed with the following strategy:

After the initialization (shots, scores, misses, Bluetooth, etc) it waits for the "Start" button to be pressed.
When the "Start" button is pressed it stays continuously monitoring the Bluetooth connection.
Every time it receives any data it updates the board and plays the correct notification sound.
The process repeats until the "Pause" button is pressed.
There're buttons to select de Bluetooth device, reset the count, and some extra buttons to adjust the board if necessary.

These are the main changes made from version 1 to version 2:

Change the layout from portrait to landscape.
Add Light, Humidity, Temperature, and Heat Index.
Improve the adjust buttons.
Add a feature to keep the screen always on.
Add press sounds on all buttons.
Adds functionality to warn each time the 50-shots mark (50, 100, 150, etc) is reached.

Android App (version 1)

Android App (version 2)

The Android codes for the two versions are available in the Code section.

Step 3: Basketball board setup

This is the original basketball board that I regularly use to do basketball training workouts.

The original basketball board

First I removed the plastic cover under the hoop and made a hole for the proximity sensor.

The plastic cover with the proximity sensor hole

Then I made a small hole to fix the vibration sensor.

The plastic cover with the vibration sensor hole

I could not attach the sensor directly to the plastic cover due to its curvature so I built a support to the sensor using MDF.

1 / 3 • The plastic cover and the internal support for the proximity sensor

I fixed the proximity and vibration sensors using some bolts and a nut.

1 / 3 • The plastic cover with the proximity and vibration sensors fixed

Then I connected the other components.

Version 1

1 / 2 • Smart basketball scoreboard (version 1) - Front / Inside

Version 2

1 / 3 • Smart basketball scoreboard (version 2) - Front / Inside

So it's time for a smoke test.

Version 1

Smart basketball scoreboard test (version 1)

Version 2

Smart basketball scoreboard test (version 2)

Finally, I installed everything on the basketball board.

Version 1

1 / 2 • Smart basketball scoreboard installed on the basketball board (version 1)

Version 2

1 / 2 • Smart basketball scoreboard installed on the basketball board (version 2)

Step 4: Basketball workout test

Now it's time to test everything.

Smart basketball scoreboard in action (version 1)

And the grand finale... it's showtime!

Smart basketball scoreboard showtime (version 1)

Step 5: Final considerations

The system proved to be very accurate, with very few false positives and rare false negatives.
It's fantastic to play with the system to know the workout statistics in real-time and after the training.

Have fun...

Code

//----------------------------------------------------------------------------//
// Filename    : Scoreboard.ino                                               //
// Description : Smart Basketball Scoreboard                                  //
// Version     : 1.1.0                                                        //
// Author      : Marcelo Avila de Oliveira <marceloavilaoliveira@gmail.com>   //
//----------------------------------------------------------------------------//

//----------------------------------------------------------------------------//
// DEFINITIONS                                                                //
//----------------------------------------------------------------------------//

// TURN ON DEBUG MODE
// #define DEBUG
// #define DEBUG_PROX
// #define DEBUG_VIBR

//----------------------------------------------------------------------------//
// CONSTANTS                                                                  //
//----------------------------------------------------------------------------//

// PINS
const int prox_pin = 2;
const int vibr_pin = 3;
const int led_r_pin = 4;
const int led_g_pin = 5;
const int led_b_pin = 6;

// TIME
const unsigned long wait_interval = 3000;

// MATH
const float percent_to_bright_factor = 100 * log10(2) / log10(255);

//----------------------------------------------------------------------------//
// VARIABLES                                                                  //
//----------------------------------------------------------------------------//

// TIME
unsigned long wait_time;

// STATUS
boolean prox = false;
boolean vibr = false;
boolean wait = false;

//----------------------------------------------------------------------------//
// FUNCTIONS (SETTINGS)                                                       //
//----------------------------------------------------------------------------//

void setup() {
    // INITIATE PINS
    pinMode(prox_pin, INPUT);
    pinMode(vibr_pin, INPUT);
    pinMode(led_r_pin, OUTPUT);
    pinMode(led_g_pin, OUTPUT);
    pinMode(led_b_pin, OUTPUT);

    set_led(5, 100);

    // INITIATE SERIAL COMMUNICATION
    Serial.begin(9600);

    // INITIATE BLUETOOTH COMMUNICATION
    setup_bluetooth();

    set_led(4, 100);

    #ifdef DEBUG
        Serial.println("Board is alive");
        Serial.println();
    #endif
}

void setup_bluetooth() {
    #ifdef DEBUG
        Serial.println("Setting Bluetooth");
        Serial.println();
    #endif

    Serial1.begin(38400);                   // Set baud rate
    Serial1.print("\r\n+STWMOD=0\r\n");     // Set to work in slave mode
    Serial1.print("\r\n+STNA=Arduino\r\n"); // Set name
    Serial1.print("\r\n+STOAUT=1\r\n");     // Permit Paired device to connect me
    Serial1.print("\r\n+STAUTO=0\r\n");     // Auto-connection should be forbidden here
    delay(2000);                            // This delay is required.
    Serial1.print("\r\n+INQ=1\r\n");        // Make the slave inquirable
    delay(2000);                            // This delay is required.
    while (Serial1.available()) {           // Clear data
        delay(50);
        Serial1.read();
    }
}

//----------------------------------------------------------------------------//
// FUNCTIONS (LIGHT)                                                          //
//----------------------------------------------------------------------------//

int percent_to_bright(int percent) {
    // PERCENT:
    // 0..100
    // RETURN BRIGHT
    // 255..0

    return 256 - pow(2, percent / percent_to_bright_factor);
}

void set_led(int color, int bright) {
    // COLOR:
    // 0 = GREEN
    // 1 = YELLOW
    // 2 = RED
    // 3 = CYAN
    // 4 = BLUE
    // 5 = MAGENTA
    // 6 = WHITE
    //
    // BRIGHT:
    // 0 = OFF
    // ..
    // 100 = MAX

    #ifdef DEBUG
        Serial.println("Setting LED");
        Serial.println();
    #endif

    if (color < 0 || color > 6 || bright < 0 || bright > 100) {
        return;
    }

    int led_r_bright = 255;
    int led_g_bright = 255;
    int led_b_bright = 255;
    int bright_aux = percent_to_bright(bright);

    switch (color) {
        case 0:
            // GREEN
            led_g_bright = bright_aux;
            break;
        case 1:
            // YELLOW
            led_r_bright = bright_aux;
            led_g_bright = bright_aux;
            break;
        case 2:
            // RED
            led_r_bright = bright_aux;
            break;
        case 3:
            // CYAN
            led_g_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
        case 4:
            // BLUE
            led_b_bright = bright_aux;
            break;
        case 5:
            // MAGENTA
            led_r_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
        case 6:
            // WHITE
            led_r_bright = bright_aux;
            led_g_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
    }

    analogWrite(led_r_pin, led_r_bright);
    analogWrite(led_g_pin, led_g_bright);
    analogWrite(led_b_pin, led_b_bright);

    return;
}

//----------------------------------------------------------------------------//
// FUNCTIONS (CHECK)                                                          //
//----------------------------------------------------------------------------//

void check_prox() {
    if (!prox) {
        if(digitalRead(prox_pin) == LOW) {
            #ifdef DEBUG_PROX
                Serial.println("Proximity detected");
                Serial.println();
            #endif

            prox = true;
            if (!vibr) {
                wait = true;
                wait_time = millis() + wait_interval;
            }
            set_shot(1);
        }
    }
}

void check_vibr() {
    if (!prox && !vibr) {
        if(digitalRead(vibr_pin) == HIGH) {
            #ifdef DEBUG_PROX
                Serial.println("Vibration detected");
                Serial.println();
            #endif

            vibr = true;
            wait = true;
            wait_time = millis() + wait_interval;
            set_led(1, 100);
        }
    }
}

void check_wait() {
    if (wait && millis() > wait_time) {
        if (!prox) {
            set_shot(0);
        }

        reset();
    }
}

//----------------------------------------------------------------------------//
// FUNCTIONS (MIS)                                                            //
//----------------------------------------------------------------------------//

void set_shot(int mode) {
    // MODE:
    // 0 = WRONG SHOT (MISS)
    // 1 = RIGHT SHOT (SCORE)

    if (mode == 0) {
        set_led(2, 100);
    } else {
        set_led(0, 100);
    }

    Serial1.print(mode);
    delay(1000);
}

void reset() {
    vibr = false;
    prox = false;
    wait = false;
    set_led(4, 100);
}

//----------------------------------------------------------------------------//
// MAIN                                                                       //
//----------------------------------------------------------------------------//

void loop() {
    check_prox();
    check_vibr();
    check_wait();
}

//----------------------------------------------------------------------------//
// Filename    : Scoreboard.ino                                               //
// Description : Smart Basketball Scoreboard                                  //
// Version     : 2.0.0                                                        //
// Author      : Marcelo Avila de Oliveira <marceloavilaoliveira@gmail.com>   //
//----------------------------------------------------------------------------//

//----------------------------------------------------------------------------//
// LIBRARIES                                                                  //
//----------------------------------------------------------------------------//

// TEMPERATURE & HUMIDITY LIBRARY
#include "DHT.h"
// MULTI SERIAL LIBRARY
#include "SoftwareSerial.h"

//----------------------------------------------------------------------------//
// DEFINITIONS                                                                //
//----------------------------------------------------------------------------//

// TURN ON DEBUG MODE
// #define DEBUG
// #define DEBUG_BLUE
// #define DEBUG_PROX
// #define DEBUG_VIBR
// #define DEBUG_DHT

// DHT SENSOR
#define DHTPIN 7
#define DHTTYPE DHT22
DHT dht(DHTPIN, DHTTYPE);

// BLUETOOTH MODULE (RX, TX)
SoftwareSerial Bluetooth(10, 11);

//----------------------------------------------------------------------------//
// CONSTANTS                                                                  //
//----------------------------------------------------------------------------//

// PINS
const int prox_pin = 2;
const int vibr_pin = 3;
const int led_r_pin = 4;
const int led_g_pin = 5;
const int led_b_pin = 6;

// TIME
const unsigned long wait_interval = 2000;
const unsigned long dht_interval = 10000;

// MATH
const float percent_to_bright_factor = 100 * log10(2) / log10(255);

//----------------------------------------------------------------------------//
// VARIABLES                                                                  //
//----------------------------------------------------------------------------//

// TIME
unsigned long wait_time;
unsigned long dht_time;

// HUMIDITY & TEMPERATURE
float humi, temp, heat;

// STATUS
boolean prox = false;
boolean vibr = false;
boolean wait = false;

//----------------------------------------------------------------------------//
// FUNCTIONS (SETTINGS)                                                       //
//----------------------------------------------------------------------------//

void setup() {
    // INITIATE PINS
    pinMode(prox_pin, INPUT);
    pinMode(vibr_pin, INPUT);
    pinMode(led_r_pin, OUTPUT);
    pinMode(led_g_pin, OUTPUT);
    pinMode(led_b_pin, OUTPUT);

    // SET LED MAGENTA
    set_led(5, 100);

    // INITIATE SERIAL COMMUNICATION
    Serial.begin(9600);

    // INITIATE BLUETOOTH COMMUNICATION
    setup_bluetooth();

    // INITIATE DHT SENSOR
    dht.begin();

    // SET LED BLUE
    set_led(4, 100);

    #ifdef DEBUG
        Serial.println("Board is alive");
        Serial.println();
    #endif
}

void setup_bluetooth() {
    #ifdef DEBUG_BLUE
        Serial.println("Setting Bluetooth");
        Serial.println();
    #endif

    // SET BAUD RATE
    Bluetooth.begin(9600);
    // CLEAR ANY AVAILABLE DATA
    while (Bluetooth.available()) {
        delay(50);
        Bluetooth.read();
    }
}

//----------------------------------------------------------------------------//
// FUNCTIONS (LIGHT)                                                          //
//----------------------------------------------------------------------------//

int percent_to_bright(int percent) {
    // PERCENT:
    // 0..100
    // RETURN BRIGHT
    // 255..0

    return 256 - pow(2, percent / percent_to_bright_factor);
}

void set_led(int color, int bright) {
    // COLOR:
    // 0 = GREEN
    // 1 = YELLOW
    // 2 = RED
    // 3 = CYAN
    // 4 = BLUE
    // 5 = MAGENTA
    // 6 = WHITE
    //
    // BRIGHT:
    // 0 = OFF
    // ..
    // 100 = MAX

    #ifdef DEBUG
        Serial.println("Setting LED");
        Serial.println();
    #endif

    if (color < 0 || color > 6 || bright < 0 || bright > 100) {
        return;
    }

    int led_r_bright = 255;
    int led_g_bright = 255;
    int led_b_bright = 255;
    int bright_aux = percent_to_bright(bright);

    switch (color) {
        case 0:
            // GREEN
            led_g_bright = bright_aux;
            break;
        case 1:
            // YELLOW
            led_r_bright = bright_aux;
            led_g_bright = bright_aux;
            break;
        case 2:
            // RED
            led_r_bright = bright_aux;
            break;
        case 3:
            // CYAN
            led_g_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
        case 4:
            // BLUE
            led_b_bright = bright_aux;
            break;
        case 5:
            // MAGENTA
            led_r_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
        case 6:
            // WHITE
            led_r_bright = bright_aux;
            led_g_bright = bright_aux;
            led_b_bright = bright_aux;
            break;
    }

    analogWrite(led_r_pin, led_r_bright);
    analogWrite(led_g_pin, led_g_bright);
    analogWrite(led_b_pin, led_b_bright);

    return;
}

//----------------------------------------------------------------------------//
// FUNCTIONS (CHECK)                                                          //
//----------------------------------------------------------------------------//

void check_prox() {
    if (!prox) {
        // CHECK PROXIMITY ONLY IF PROXIMITY WASN'T DETECTED

        if(digitalRead(prox_pin) == LOW) {
            #ifdef DEBUG_PROX
                Serial.println("Proximity detected");
                Serial.println();
            #endif

            // SET LED GREEN
            set_led(0, 100);
            send_data(2);

            prox = true;
            if (!vibr) {
                wait = true;
                wait_time = millis() + wait_interval;
            }
        }
    }
}

void check_vibr() {
    if (!prox && !vibr) {
        // CHECK VIBRATION ONLY IF PROXIMITY AND VIBRATION WEREN'T DETECTED

        if(digitalRead(vibr_pin) == HIGH) {
            #ifdef DEBUG_VIBR
                Serial.println("Vibration detected");
                Serial.println();
            #endif

            // SET LED YELLOW
            set_led(1, 100);

            vibr = true;
            wait = true;
            wait_time = millis() + wait_interval;
        }
    }
}

void check_wait() {
    if (wait && millis() > wait_time) {
        if (!prox) {
            // SET LED RED
            set_led(2, 100);
            send_data(1);
        }

        reset();
    }
}

void check_dht() {
    if (!prox && !vibr) {
        // CHECK DHT ONLY IF VIBRATION WASN'T DETECTED

        if (millis() > dht_time) {
            humi = dht.readHumidity();
            temp = dht.readTemperature();
            heat = dht.computeHeatIndex(temp, humi, false);

            #ifdef DEBUG_DHT
                Serial.print("Humidity   : ");
                Serial.print(humi);
                Serial.println("%");
                Serial.print("Temperature: ");
                Serial.print(temp);
                Serial.println("C");
                Serial.print("Head Index : ");
                Serial.print(heat);
                Serial.println("C");
                Serial.println("");
           #endif

            send_data(0);
            dht_time = millis() + dht_interval;
        }
    }
}

//----------------------------------------------------------------------------//
// FUNCTIONS (MIS)                                                            //
//----------------------------------------------------------------------------//

void send_data(int shot) {
    // SHOT:
    // 0 = NO DATA
    // 1 = WRONG SHOT (MISS)
    // 2 = RIGHT SHOT (SCORE)

    Bluetooth.print(humi);
    Bluetooth.print(temp);
    Bluetooth.print(heat);
    Bluetooth.print(shot);

    #ifdef DEBUG_BLUE
        Serial.println("Bluetooth sent");
        Serial.println();
    #endif
}

void reset() {
    vibr = false;
    prox = false;
    wait = false;

    delay(1000);

    // SET LED BLUE
    set_led(4, 100);
}

//----------------------------------------------------------------------------//
// MAIN                                                                       //
//----------------------------------------------------------------------------//

void loop() {
    check_prox();
    check_vibr();
    check_wait();
    check_dht();
}

Credits

Marcelo Ávila de Oliveira

5 projects • 9 followers

Smart Basketball Scoreboard

Things used in this project

Hardware components

Software apps and online services

Story

Versions

Step 1: Arduino

Step 2: Android

Step 3: Basketball board setup

Step 4: Basketball workout test

Step 5: Final considerations

Schematics

Arduino schematics (1.1.0)

Arduino schematics (2.0.0)

Code

Arduino code (1.1.0)

Android code (1.1.0)

Arduino code (2.0.0)

Android code (2.0.0)

Credits

Marcelo Ávila de Oliveira

Comments

Embed the widget on your own site

Smart Basketball Scoreboard

Smart Basketball Scoreboard

Things used in this project

Hardware components

Software apps and online services

Story

Versions

Step 1: Arduino

Step 2: Android

Step 3: Basketball board setup

Step 4: Basketball workout test

Step 5: Final considerations

Schematics

Arduino schematics (1.1.0)

Arduino schematics (2.0.0)

Code

Arduino code (1.1.0)

Android code (1.1.0)

Arduino code (2.0.0)

Android code (2.0.0)

Credits

Marcelo Ávila de Oliveira

Comments

Related channels and tags
