This script uses code and ideas from the following sources:
-https://www.hackster.io/team-spy-family/team-spy-family-aa7632
-https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
'''
# SPDX-FileCopyrightText: 2021 ladyada for Adafruit Industries
# SPDX-License-Identifier: MIT
import board
import adafruit_mcp4728
import cv2
import numpy as np
import matplotlib.pyplot as plt
import math
import sys
import time
MCP4728_DEFAULT_ADDRESS = 0x60
MCP4728A4_DEFAULT_ADDRESS = 0x64
#initialize the board
i2c = board.I2C() # uses board.SCL and board.SDA
mcp4728 = adafruit_mcp4728.MCP4728(i2c, adafruit_mcp4728.MCP4728A4_DEFAULT_ADDRESS)
#VDD = 65535 = 3.3V | 65535/2 = 1.65V
#DAC channels not used
mcp4728.channel_b.value = 0
mcp4728.channel_c.value = 0
#number of stops expected on the track
expected_number_stops = 2
# arrays for making the final plots
steering_voltage = []
p_vals = []
d_vals = []
err_vals = []
speed_vals = []
voltage_denom = []
saveValues = True #for plotting
sightDebug = True #visualize heading line
#------------------------------------------------------------------------
#Throttle
forward = 1.85 #controls initial throttle
stopped = int(65535/2)
neutral = 2 #middle speed
#Steering
turn_left = int(65535/5)
turn_right = int(65535/1.2)
straight = int(65535/2.1)
#op encode
speed = 0
prev_speed = 0
go_faster_tick = 0 # Do not change this here. Code will set this value after seeing stop sign
# Encoder related variables
speedCheck = 10 # number of frames in between speed adjustment
TARGET = 30 #controls desired speed. Target value we want to get from our encoder
SPEED_STEP = 0.005 #acceleration
go_forward = 1.85
prev = 0
SPEED_CEIL = 1.84 #controls max voltage to motors
def initialize_car():
#stops motor
mcp4728.channel_a.value = stopped #throttle
# wait for car to be ready
mcp4728.channel_d.value = straight #steering
def stop():
"""
Stops the car
:return: none
"""
mcp4728.channel_a.value = int(65535 / stopped)
def go():
"""
Sends the car forward at a default speed
:return: none
"""
#mcp4728.channel_a.value = forward
mcp4728.channel_a.value = int( 65535 / forward)
def detect_edges(frame):
# filter for blue lane lines
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
lower_blue = np.array([90, 120, 0], dtype="uint8")
upper_blue = np.array([150, 255, 255], dtype="uint8")
mask = cv2.inRange(hsv, lower_blue, upper_blue)
# detect edges
edges = cv2.Canny(mask, 50, 100)
# cv2.imshow("edges",edges)
return edges
def region_of_interest(edges):
# focus on the lane lines and ignore anything else
height, width = edges.shape
mask = np.zeros_like(edges)
# only focus lower half of the screen
polygon = np.array([[
(0, height),
(0, height / 2),
(width, height / 2),
(width, height),
]], np.int32)
cv2.fillPoly(mask, polygon, 255)
cropped_edges = cv2.bitwise_and(edges, mask)
return cropped_edges
def detect_line_segments(cropped_edges):
#detect lines in each frame
rho = 1
theta = np.pi / 180
min_threshold = 10
line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
np.array([]), minLineLength=5, maxLineGap=150)
return line_segments
def average_slope_intercept(frame, line_segments):
lane_lines = []
if line_segments is None:
# print("no line segments detected")
return lane_lines
height, width, _ = frame.shape
left_fit = []
right_fit = []
boundary = 1 / 3
left_region_boundary = width * (1 - boundary)
right_region_boundary = width * boundary
for line_segment in line_segments:
for x1, y1, x2, y2 in line_segment:
if x1 == x2:
# print("skipping vertical lines (slope = infinity")
continue
fit = np.polyfit((x1, x2), (y1, y2), 1)
slope = (y2 - y1) / (x2 - x1)
intercept = y1 - (slope * x1)
if slope < 0:
if x1 < left_region_boundary and x2 < left_region_boundary:
left_fit.append((slope, intercept))
else:
if x1 > right_region_boundary and x2 > right_region_boundary:
right_fit.append((slope, intercept))
left_fit_average = np.average(left_fit, axis=0)
if len(left_fit) > 0:
lane_lines.append(make_points(frame, left_fit_average))
right_fit_average = np.average(right_fit, axis=0)
if len(right_fit) > 0:
lane_lines.append(make_points(frame, right_fit_average))
return lane_lines
def make_points(frame, line):
#return the bounded coordinates of the lane lines
height, width, _ = frame.shape
slope, intercept = line
y1 = height # bottom of the frame
y2 = int(y1 / 2) # make points from middle of the frame down
#if horizontal line, sets slope value near 0 to prevent dividing by 0
#does not affect performance
if slope == 0:
slope = 0.1
x1 = int((y1 - intercept) / slope)
x2 = int((y2 - intercept) / slope)
return [[x1, y1, x2, y2]]
def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
#display lines on the frames
line_image = np.zeros_like(frame)
if lines is not None:
for line in lines:
for x1, y1, x2, y2 in line:
cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1) #adds two images, each with a defined weight
return line_image
def get_steering_angle(frame, lane_lines):
height, width, _ = frame.shape
if len(lane_lines) == 2: # if two lane lines are detected
_, _, left_x2, _ = lane_lines[0][0] # extract left x2 from lane_lines array
_, _, right_x2, _ = lane_lines[1][0] # extract right x2 from lane_lines array
mid = int(width / 2)
x_offset = (left_x2 + right_x2) / 2 - mid
y_offset = int(height / 2)
elif len(lane_lines) == 1: # if only one line is detected
x1, _, x2, _ = lane_lines[0][0]
x_offset = x2 - x1
y_offset = int(height / 2)
elif len(lane_lines) == 0: # if no line is detected
x_offset = 0
y_offset = int(height / 2)
angle_to_mid_radian = math.atan(x_offset / y_offset)
angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
steering_angle = angle_to_mid_deg + 90
return steering_angle
def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
#heading line determines direction and speed
heading_image = np.zeros_like(frame)
height, width, _ = frame.shape
steering_angle_radian = steering_angle / 180.0 * math.pi
x1 = int(width / 2)
y1 = height
x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
y2 = int(height / 2)
cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)
return heading_image
#howdy from the Multicultural Center
# set up the car throttle and steering
initialize_car()
# set up video
video = cv2.VideoCapture(0)
#sets resolution to 320x240
video.set(cv2.CAP_PROP_FRAME_WIDTH, 320)
video.set(cv2.CAP_PROP_FRAME_HEIGHT, 240)
# wait for video to load
time.sleep(1)
# PD variables
#error increases, P action increases
#slope of the error, D
kp = 0.4
kd = kp * 0.65
lastTime = 0
lastError = 0
counter = 0 # counter for number of ticks
max_ticks = 2000
#-----------------------------------
# start the engines
go()
frame_frequency = 10 #10 frames
signs_seen = 0
i = 0
print("Starting loop!")
#frame = cv2.flip(frame,-1) - inverts image
while counter < max_ticks:
ret, original_frame = video.read()
frame = cv2.resize(original_frame, (160, 120)) #resizes to 160*120
i += 1
#checks for red square every 10 frames
if counter % frame_frequency == 0:
hsv_red = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
#define range of red in HSV
lower_red = np.array([155,3, 140])
upper_red = np.array([175, 22, 160])
#threshold the HSV image to get only red colors and count pixels yay
mask_red = cv2.inRange(hsv_red, lower_red, upper_red)
countRed = cv2.countNonZero(mask_red)
#if pink pixels are significant, stop
if (countRed > 250 and i > 70): #250 pixels works too!
mcp4728.channel_a.value = stopped
print("saw a sign!...stopping car.")
time.sleep(2) #waits
signs_seen += 1
#checks number of signs it sees
if (signs_seen == expected_number_stops):
initialize_car()
break
mcp4728.channel_a.value = int(65535 / forward)
i = 0 #resets counter!
print("One more to go!!", signs_seen)
#process camera input for lane keeping using openCV
edges = detect_edges(frame)
roi = region_of_interest(edges)
line_segments = detect_line_segments(roi)
lane_lines = average_slope_intercept(frame, line_segments)
lane_lines_image = display_lines(frame, lane_lines)
steering_angle = get_steering_angle(frame, lane_lines)
heading_angle = display_heading_line(lane_lines_image, steering_angle)
if sightDebug:
cv2.imshow("heading_line.jpg", heading_angle)
#Calculate changes for PD
now = time.time()
dt = now - lastTime
deviation = steering_angle - 90
error = abs(deviation)
# speed adjustment ---------------[From Hackster SpyxFamily]
if counter % speedCheck == 0:
with open('/sys/module/Speed_encoder/parameters/op_count', 'r') as fileread:
read = int(fileread.read())
speed = read - prev
prev = read
# print(speed)
if speed > TARGET:
go_forward = go_forward + SPEED_STEP
elif speed < TARGET:
go_forward = go_forward - SPEED_STEP
print("speed:",speed," motor voltage:",go_forward,"from op_count")
#end speed adjustment--------------------
#controls car steering
if deviation < 5 and deviation > -5: #buffer of 10 degrees
deviation = 0
error = 0
mcp4728.channel_d.value = straight #steering
elif deviation > 5:
mcp4728.channel_d.value = turn_right #steering
elif deviation < -5:
mcp4728.channel_d.value = turn_left #steering
derivative = kd * (error - lastError) / dt
proportional = kp * error
PD = int(speed + derivative + proportional)
spd = abs(PD)
lastError = error
lastTime = time.time()
#print(spd)
#ensures car doesn't go too fast
if go_forward < SPEED_CEIL:
go_forward = SPEED_CEIL
#determines throttle
mcp4728.channel_a.value = int( 65525 / go_forward)
# take values for graphs
p_vals.append(proportional)
d_vals.append(derivative)
err_vals.append(error)
voltage_denom.append(go_forward)
speed_vals.append(speed)
voltage = int(65535 / go_forward)
steering_voltage.append(voltage)
counter += 1
key = cv2.waitKey(1)
if key == 27:
break
if saveValues:
d_vals_str = str(d_vals)
p_vals_str = str(p_vals)
err_vals_str = str(err_vals)
steering_voltage_str = str(steering_voltage)
speed_vals_str = str(speed_vals)
voltage_denom_str = str(voltage_denom)
#writing lists to text file preserving list structure for external plotting
with open('PD_data_new.txt', 'w') as file:
file.write(f'D={d_vals_str}\n')
file.write(f'P={p_vals_str}\n')
file.write(f'error={err_vals_str}\n')
file.write(f'voltage={steering_voltage_str}\n')
file.write(f'speed={speed_vals_str}\n')
file.write(f'voltage_denom={voltage_denom_str}\n')
print("Values written to 'Car_data.txt' successfully.")
#clean up resources
video.release()
cv2.destroyAllWindows()
print("Finishing... ")
#stops car and straightens wheels
mcp4728.channel_a.value = stopped #throttle
mcp4728.channel_d.value = straight #steering
