In this project, the focus is on exploring different modes of USART communication on an STM32 microcontroller. Specifically, the project will cover three modes: polling, interrupt, and DMA.
In polling mode, the microcontroller continuously checks for incoming data from the USART and processes it. This mode is relatively simple but can consume significant processing power.
In interrupt mode, the microcontroller receives a signal from the USART when data is ready to be processed. This mode is more efficient since the microcontroller can perform other tasks while waiting for data to arrive.
In DMA (Direct Memory Access) mode, the microcontroller can transfer data between the USART and memory without CPU intervention. This mode can significantly reduce the processing overhead and improve the overall performance of the system.
The project will cover the configuration and implementation of each mode on the STM32 microcontroller using the HAL (Hardware Abstraction Layer) library. The project will also include practical examples of using each mode for data transfer between STM32 and Virtual Terminal.
Step One:- Open CubeMX & Create New Project Choose The Target MCU STM32F103C6 & Double-Click Its Name
- Go To The Clock Configuration & Set The System Clock To 16MHz
- Enable USART1 and USART2 Module (Asynchronous Mode)
- Set the USART1 and USART2 communication parameters (baud rate = 9600, parity=NON, stop bits =1, and word length =8bits)
- In the NVIC settings tab, enable the interrupt for the USART1 peripheral
- In the DMA settings tab, enable the DMA for the USART2 peripheral
- Configure The GPIO Pins PB0, and PB1 as Input Pin
- Configure The GPIO Pins PB14, and PB15 as Output Pin
- Generate The Initialization Code & Open The Project In CubeIDE
- Write The Application Layer Code
You can access the source code files via this
link
.
- Open Proteus & Create New Project and click next
- Click on Pick Device
- Search for STM32F103C6 & SW-SPDT(switch) & LED_RED BLUE and YELLOW
- Click on Virtual Instruments Mode then choose VIRTUAL TERMINAL
- Click on Terminal Mode then choose (DEFAULT & POWER &GROUND)
- finally make the circuit below and start the simulation
If you have any questions or suggestions don't hesitate to leave a comment below
