SafeDrill

Our mission is to make safe drilling available for everyone.

AdvancedWork in progress1,675

Things used in this project

Hardware components

Arduino Nano 33 BLE Sense
Arduino Nano 33 BLE Sense
×1

Software apps and online services

Edge Impulse Studio
Edge Impulse Studio
MIT App Inventor
MIT App Inventor
Arduino IDE
Arduino IDE

Hand tools and fabrication machines

Drill / Driver, Cordless
Drill / Driver, Cordless
Prusa I3MK3S

Story

Read more

Custom parts and enclosures

safedrill_top.3MF

safedrill_bottom.3MF

Schematics

ML Model

The library has to be imported into your arduino IDE for the code to work.

Android app

This is the App file for your phone.

Application project

This is the MIT App Inventor project file

Code

Arduino ML code

Arduino
/* Edge Impulse Arduino examples
 * Copyright (c) 2021 EdgeImpulse Inc.
 *
 * Permission is hereby granted, free of charge, to any person obtaining a copy
 * of this software and associated documentation files (the "Software"), to deal
 * in the Software without restriction, including without limitation the rights
 * to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
 * copies of the Software, and to permit persons to whom the Software is
 * furnished to do so, subject to the following conditions:
 *
 * The above copyright notice and this permission notice shall be included in
 * all copies or substantial portions of the Software.
 *
 * THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
 * IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
 * FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
 * AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
 * LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
 * OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
 * SOFTWARE.
 */

/* Includes ---------------------------------------------------------------- */
#include <Varnost_pri_delu_-_vrtalnik_inferencing.h>
#include <Arduino_LSM9DS1.h>
#include <ArduinoBLE.h>

/* Constant defines -------------------------------------------------------- */
#define CONVERT_G_TO_MS2    9.80665f
#define MAX_ACCEPTED_RANGE  2.0f        // starting 03/2022, models are generated setting range to +-2, but this example use Arudino library which set range to +-4g. If you are using an older model, ignore this value and use 4.0f instead

/*
 ** NOTE: If you run into TFLite arena allocation issue.
 **
 ** This may be due to may dynamic memory fragmentation.
 ** Try defining "-DEI_CLASSIFIER_ALLOCATION_STATIC" in boards.local.txt (create
 ** if it doesn't exist) and copy this file to
 ** `<ARDUINO_CORE_INSTALL_PATH>/arduino/hardware/<mbed_core>/<core_version>/`.
 **
 ** See
 ** (https://support.arduino.cc/hc/en-us/articles/360012076960-Where-are-the-installed-cores-located-)
 ** to find where Arduino installs cores on your machine.
 **
 ** If the problem persists then there's not enough memory for this model and application.
 */


BLEService drillService("f104af85-a883-44f7-97fc-d2813c7ca7fd");
BLEUnsignedCharCharacteristic drillChar("ac940dba-e19d-4a25-ab7e-c561485e3bbd",  // standard 16-bit characteristic UUID
                              BLERead | BLENotify); // remote clients will be able to get notifications if this characteristic changes




/* Private variables ------------------------------------------------------- */
static bool debug_nn = false; // Set this to true to see e.g. features generated from the raw signal
static uint32_t run_inference_every_ms = 200;
static rtos::Thread inference_thread(osPriorityLow);
static float buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE] = { 0 };
static float inference_buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE];

/* Forward declaration */
void run_inference_background();

/**
* @brief      Arduino setup function
*/
void setup()
{
    // put your setup code here, to run once:
    Serial.begin(115200);

    delay(2000);

    Serial.println("Edge Impulse Inferencing Demo");

    if (!IMU.begin()) {
        ei_printf("Failed to initialize IMU!\r\n");
    }
    else {
        ei_printf("IMU initialized\r\n");
    }

    if (EI_CLASSIFIER_RAW_SAMPLES_PER_FRAME != 3) {
        ei_printf("ERR: EI_CLASSIFIER_RAW_SAMPLES_PER_FRAME should be equal to 3 (the 3 sensor axes)\n");
        return;
    }

  inference_thread.start(mbed::callback(&run_inference_background));

  pinMode(LED_BUILTIN, OUTPUT); // initialize the built-in LED pin to indicate when a central is connected

      // begin initialization
  if (!BLE.begin()) {
    Serial.println("starting BLE failed!");

    while (1);
  }

  /* Set a local name for the Bluetooth® Low Energy device
     This name will appear in advertising packets
     and can be used by remote devices to identify this Bluetooth® Low Energy device
     The name can be changed but maybe be truncated based on space left in advertisement packet
  */
  BLE.setLocalName("Safe Drill device");
  BLE.setDeviceName("Safe Drill device");
  BLE.setAdvertisedService(drillService); // add the service UUID
  drillService.addCharacteristic(drillChar); // add the gesture characteristic
  BLE.addService(drillService); // Add the gesture service

  /* Start advertising Bluetooth® Low Energy.  It will start continuously transmitting Bluetooth® Low Energy
     advertising packets and will be visible to remote Bluetooth® Low Energy central devices
     until it receives a new connection */

  // start advertising
  BLE.advertise();

  Serial.println("Edge Impulse Inferencing Demo");
  Serial.println("Bluetooth® device active, waiting for connections...");

  delay(1000);

}

/**
 * @brief Return the sign of the number
 *
 * @param number
 * @return int 1 if positive (or 0) -1 if negative
 */
float ei_get_sign(float number) {
    return (number >= 0.0) ? 1.0 : -1.0;
}

/**
 * @brief      Run inferencing in the background.
 */
void run_inference_background()
{
    // wait until we have a full buffer
    delay((EI_CLASSIFIER_INTERVAL_MS * EI_CLASSIFIER_RAW_SAMPLE_COUNT) + 100);

    // This is a structure that smoothens the output result
    // With the default settings 70% of readings should be the same before classifying.
    ei_classifier_smooth_t smooth;
    ei_classifier_smooth_init(&smooth, 10 /* no. of readings */, 7 /* min. readings the same */, 0.8 /* min. confidence */, 0.3 /* max anomaly */);

    while (1) {
        // copy the buffer
        memcpy(inference_buffer, buffer, EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE * sizeof(float));

        // Turn the raw buffer in a signal which we can the classify
        signal_t signal;
        int err = numpy::signal_from_buffer(inference_buffer, EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE, &signal);
        if (err != 0) {
            ei_printf("Failed to create signal from buffer (%d)\n", err);
            return;
        }

        // Run the classifier
        ei_impulse_result_t result = { 0 };

        err = run_classifier(&signal, &result, debug_nn);
        if (err != EI_IMPULSE_OK) {
            ei_printf("ERR: Failed to run classifier (%d)\n", err);
            return;
        }

        // print the predictions
        ei_printf("Predictions ");
        ei_printf("(DSP: %d ms., Classification: %d ms., Anomaly: %d ms.)",
            result.timing.dsp, result.timing.classification, result.timing.anomaly);
        ei_printf(": ");

        // ei_classifier_smooth_update yields the predicted label
        const char *prediction = ei_classifier_smooth_update(&smooth, &result);
        ei_printf("%s ", prediction);

// ---------------------------------Sending packages via BLE------------------------------------------

  int pred_BLE;

  //strcmp vrze 0 ce sta stringa enaka
  if (strcmp(prediction, "uncertain") == 0){
    pred_BLE = 0;
  }
  else if (strcmp(prediction, "Sveder beton - material beton") == 0){
    pred_BLE = 1;
  }
  else if (strcmp(prediction, "Sveder beton - material kovina") == 0){
    pred_BLE = 2;
  }
  else if (strcmp(prediction, "Sveder beton - material les") == 0){
    pred_BLE = 3;
  }
  else if (strcmp(prediction, "Sveder kovina - material beton") == 0){
    pred_BLE = 4;
  }
  else if (strcmp(prediction, "Sveder Kovina - material kovina") == 0){
    pred_BLE = 5;
  }
  else if (strcmp(prediction, "Sveder Kovina - material les") == 0){
    pred_BLE = 6;
  }
  else if (strcmp(prediction, "Sveder les - material beton") == 0){
    pred_BLE = 7;
  }
  else if (strcmp(prediction, "Sveder les - material kovina") == 0){
    pred_BLE = 8;
  }
  else if (strcmp(prediction, "Sveder Les - material les") == 0){
    pred_BLE = 9;
  }

  drillChar.writeValue(pred_BLE);


//---------------------------------------------------------------------------------------------------------------------------------------

        // print the cumulative results
        ei_printf(" [ ");
        for (size_t ix = 0; ix < smooth.count_size; ix++) {
            ei_printf("%u", smooth.count[ix]);
            if (ix != smooth.count_size + 1) {
                ei_printf(", ");
            }
            else {
              ei_printf(" ");
            }
        }
        ei_printf("]\n");

        delay(run_inference_every_ms);
    }

    ei_classifier_smooth_free(&smooth);
}

/**
* @brief      Get data and run inferencing
*
* @param[in]  debug  Get debug info if true
*/
void loop()
{
    while (1) {

// wait for a Bluetooth® Low Energy central
    BLEDevice central = BLE.central();

    if (central) {
      Serial.print("Connected to central: ");
      // print the central's BT address:
      Serial.println(central.address());
      // turn on the LED to indicate the connection:
      digitalWrite(LED_BUILTIN, HIGH);

      while (central.connected()) {

        // Determine the next tick (and then sleep later)
        uint64_t next_tick = micros() + (EI_CLASSIFIER_INTERVAL_MS * 1000);

        // roll the buffer -3 points so we can overwrite the last one
        numpy::roll(buffer, EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE, -3);

        // read to the end of the buffer
        IMU.readAcceleration(
            buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 3],
            buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 2],
            buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 1]
        );

        for (int i = 0; i < 3; i++) {
            if (fabs(buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 3 + i]) > MAX_ACCEPTED_RANGE) {
                buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 3 + i] = ei_get_sign(buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 3 + i]) * MAX_ACCEPTED_RANGE;
            }
        }

        buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 3] *= CONVERT_G_TO_MS2;
        buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 2] *= CONVERT_G_TO_MS2;
        buffer[EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE - 1] *= CONVERT_G_TO_MS2;

        // and wait for next tick
        uint64_t time_to_wait = next_tick - micros();
        delay((int)floor((float)time_to_wait / 1000.0f));
        delayMicroseconds(time_to_wait % 1000);
      }
      // when the central disconnects, turn off the LED:
      digitalWrite(LED_BUILTIN, LOW);
      Serial.print("Disconnected from central: ");
      Serial.println(central.address());
    }
}
}
#if !defined(EI_CLASSIFIER_SENSOR) || EI_CLASSIFIER_SENSOR != EI_CLASSIFIER_SENSOR_ACCELEROMETER
#error "Invalid model for current sensor"
#endif
