PIR Motion sensor+LDR+Relay, Without Arduino UNO

When dark and movement in room: light ON.

BeginnerFull instructions provided1 hour5,327
PIR Motion sensor+LDR+Relay, Without Arduino UNO

Things used in this project

Hardware components

PIR Motion sensor
×1
Relay 5V
×1
LDR
×1
Linear Regulator (7805)
Linear Regulator (7805)
×1
Breadboard (generic)
Breadboard (generic)
×1
Jumper wires (generic)
Jumper wires (generic)
×1
9V battery (generic)
9V battery (generic)
×1
LED 5mm Blue
×4
LED 3mm
×1
Resistor 270 Ohm
×4
Resistor 82 Ohm
×1
Resistor 10k ohm
Resistor 10k ohm
×1
Resistor 1k ohm
Resistor 1k ohm
×1
Resistor 470 Ohm
×1
Single Turn Potentiometer- 10k ohms
Single Turn Potentiometer- 10k ohms
×1
1N4007 – High Voltage, High Current Rated Diode
1N4007 – High Voltage, High Current Rated Diode
×1
Diode 1N4148
×1
Transistor 2N2222
×1
Transistor 2N3906
×1

Story

Read more

Schematics

Schematics

PIR Motion Sensor 01

Relay 5V

FRITZING Schematic

Dark+Movement = LED ON

PIR Motion Sensor 02

Fontain
