I revamped my car headlights with ws2812 and arduino nano! S

Look the results!!
AdvancedFull instructions providedOver 4 days1,446
I revamped my car headlights with ws2812 and arduino nano! S
Story

Introduction

summary video
I decided to try revamping my car headlights with arduino nano and ws2812.
Previous attempts

I started welding a lot a single leds to make a matrix.
Single led on pcb that i used for the first attemp.
But unfortunately this didin't work, the comunication bus suffer from too much hand made weldings.
I decided to buy led strips that have capacitor on each led.
Additionals car wiring

I started making new wiring identical to the old one so I i want I can mount traditional headlamps too.
I added some signals to increase the brightness of the headlights if low-beam or high-beam are on, I also added a relay and a signal to power the arduinos only when the car is on.
Long terms problems

I don't feel confident that led strip welded to a pcb can resist to hurts and vibrations for a long amount of time, i'll keep you updated if something stop working.
PCB Schematic

The schematic is simple, we just need a voltage divider for each digital input and a DC-DC to power the arduino ( Traco TSR_2-2450 I paid 15$ for each DC-DC what else could I use? I wanted something reliable).
I bought a led strip on Aliexpress and now I manage to make it work.
I bough 2 strips on differents months(sameplace) and the make different colors! I had to adjust the code to hide this but the white is still not identical
I feel satisfied with the result, certainly could have been done better but it works.
Was even the first time that I order a custom PCB,
CODE

I attach the code to this repository but I don't want to comment it, is written very bad, is not clear at all, but if someone want take a look it is in the attached files.
Code

Headlight firmware
#include <Adafruit_NeoPixel.h>
#ifdef __AVR__
#include <avr/power.h>
#endif
#define LED_PIN     6  //pin data connected to led strip
#define LED_COUNT  60  //total led number
#define BRIGHTNESS 255 // NeoPixel brightness, 0 (min) to 255 (max)


Adafruit_NeoPixel strip(LED_COUNT, LED_PIN, NEO_GRB + NEO_KHZ800); // Declare our NeoPixel strip object:

unsigned long Millis = 0;
//variabili per Startup
int i=0;//numero di volte che viene ripetuto il loop nella procedura di startup
int RStart =0;
int GStart =0;
int BStart =0;
int delayStart =7;

//variables for KITT mode

int KITTstack = 0;
int KITTSTATUS = 0;
unsigned long lastKITT=0;
int KITTtime=1;
int KITTfade=0;
int KITTrev=0;
//variables for POLICE mode

int POLICEstack = 0;
int POLICESTATUS = 0;

int POLICEtime = 1000;
int POLICEsequence = 1;

unsigned long lastPOLICE = 0;



int REMOVEstackT=30000;
unsigned long LastREMOVE=0;

unsigned long lastupdate=0;
unsigned long TriggerTime = 0; //time passed from the HIGH input


int debounceDIRLIGHT=0;
unsigned long lastdebounceDIRLIGHT=0;
bool Arrow = 0; //is 1 when the input become HIGH


int debounceRUNLIGHT=0;
unsigned long lastdebounceRUNLIGHT=0;
bool RUNLIGHTSTATUS=0;

int debounceLOWLIGHT=0;
unsigned long lastdebounceLOWLIGHT=0;
bool LOWLIGHTSTATUS=0;

int debounceHIGHLIGHT=0;
unsigned long lastdebounceHIGHLIGHT=0;
bool HIGHLIGHTSTATUS=0;



int DIRLIGHTPIN = 5;
int RUNLIGHTPIN = 7;
int LOWLIGHTPIN = 9;
int HIGHLIGHTPIN = 10;



int ROUT = 0;
int GOUT = 0;
int BOUT = 0;

//modifiers to obtain warm white
float RWW =1;
float GWW =0.94;
float BWW =0.88;



//USER SETTING
int CycleTime= 300; //ms of the animation of direction light
float ArrowBRI=0.5; //arrow brightness 1=100% 0.4 = 40% ect ect
float RunningBRI=0.2; //running lights brightness 1=100% 0.4 = 40% ect ect
float LowBeamBRI=0.3; //running lights brightness 1=100% 0.4 = 40% ect ect
float HighBeamBRI=0.5; //running lights brightness 1=100% 0.4 = 40% ect ect
bool WarmWhite = 0;



void setup()
  {
  pinMode(5,INPUT); // Direction light signal pin
  pinMode(7,INPUT); // Direction light signal pin
  pinMode(9,INPUT); // Direction light signal pin
  pinMode(10,INPUT); // Direction light signal pin
  pinMode(6,OUTPUT);
  // These lines are specifically to support the Adafruit Trinket 5V 16 MHz.
  // Any other board, you can remove this part (but no harm leaving it):
#if defined(__AVR_ATtiny85__) && (F_CPU == 16000000)
  clock_prescale_set(clock_div_1);
#endif
  // END of Trinket-specific code.
  Serial.begin(9600);      //DEBUG FUNCTION ONLY
  strip.begin();           // INITIALIZE NeoPixel strip object (REQUIRED)
  strip.show();            // Turn OFF all pixels ASAP
  strip.setBrightness(255);  // Set BRIGHTNESS to about 1/5 (max = 255)
  Startup();





}

void loop() {
Millis= millis();


 if (KITTstack==10)//if i reach x stacks i activate the KITTMODE mode
 {
 KITTSTATUS = !KITTSTATUS;
 POLICESTATUS=0;
 KITTstack =0;

 }


if (POLICEstack==10)//if i reach x stacks i activate the POLICE mode
 {
 POLICESTATUS=!POLICESTATUS;
 POLICEstack=0;
 KITTSTATUS = 0;
 }

if (KITTSTATUS==1) //if is 1 police status is on
 {
 KITT(); //updating leds for police mode
 }



if (POLICESTATUS==1) //if is 1 police status is on
 {
 POLICE(); //updating leds for police mode
 }

 if ((KITTSTATUS==0)&(POLICESTATUS==0))
 {
 Dirlight(); //updating leds for direction lights
 }


if ((Millis-LastREMOVE)>3000)// removing one stack every x millis
{
      if (KITTstack>0)
      {
       KITTstack--;
      }
      if (POLICEstack>0)
      {
       POLICEstack--;
      }

LastREMOVE=Millis;
}

if ((Millis-lastupdate)>1)// updating led states arduino nano too slow to keep this commands in the loop
{
strip.show();
lastupdate=Millis;
}


if (WarmWhite == 1)

{
RWW = 100;
GWW = 94;
BWW = 88;
}
else
RWW = 1;
GWW = 1;
BWW = 1;

if (Arrow==1)

{
ROUT = 0;
GOUT = 0;
BOUT = 0;
}


if ((RUNLIGHTSTATUS==0)&(Arrow==0)&(POLICESTATUS==0)&(KITTSTATUS==0))

{
ROUT = 0;
GOUT = 0;
BOUT = 0;
}

//--------------------change white leds status depends on inputs
if ((RUNLIGHTSTATUS==1)&(Arrow==0)&(LOWLIGHTSTATUS==0)&(POLICESTATUS==0)&(KITTSTATUS==0)&((Millis-TriggerTime)>(CycleTime*5)))
//why ((Millis-TriggerTime)>(CycleTime*5)) ?? Because i don't want the carlight flash white between arrow animations
{
ROUT = (RunningBRI*255);
GOUT = (RunningBRI*255);
BOUT = (RunningBRI*255);
}


if ((RUNLIGHTSTATUS==1)&(LOWLIGHTSTATUS==1)&(HIGHLIGHTSTATUS==0)&(POLICESTATUS==0)&(KITTSTATUS==0)&(Arrow==0)&((Millis-TriggerTime)>(CycleTime*5)))
//why ((Millis-TriggerTime)>(CycleTime*5)) ?? Because i don't want the carlight flash white between arrow animations
{
ROUT = (LowBeamBRI*255);
GOUT = (LowBeamBRI*255);
BOUT = (LowBeamBRI*255);
}

if ((RUNLIGHTSTATUS==1)&(LOWLIGHTSTATUS==1)&(HIGHLIGHTSTATUS==1)&(POLICESTATUS==0)&(KITTSTATUS==0)&(Arrow==0)&((Millis-TriggerTime)>(CycleTime*5)))
//why ((Millis-TriggerTime)>(CycleTime*5)) ?? Because i don't want the carlight flash white between arrow animations
{
ROUT = (HighBeamBRI*255);
GOUT = (HighBeamBRI*255);
BOUT = (HighBeamBRI*255);
}



if ((Millis-lastdebounceDIRLIGHT)>2)// debouncing the input DIRLIGHT
  {
      if ((digitalRead(DIRLIGHTPIN)==1)&(debounceDIRLIGHT<40))
      {
      debounceDIRLIGHT++;
           if (debounceDIRLIGHT==10)
           {
           Arrow=1;
           POLICESTATUS=0;
           KITTSTATUS=0;
           TriggerTime=Millis;
           }
      }
      if ((digitalRead(DIRLIGHTPIN)==0)&(debounceDIRLIGHT>0))
      {
      debounceDIRLIGHT--;
          if (debounceDIRLIGHT<2)
           {
           Arrow=0;
           }
      }
 lastdebounceDIRLIGHT=Millis;

 }

if ((Millis-lastdebounceRUNLIGHT)>2)// debouncing the input RUNLIGHT
  {
      if ((digitalRead(RUNLIGHTPIN)==1)&(debounceRUNLIGHT<101))
      {
      debounceRUNLIGHT++;
           if (debounceRUNLIGHT==20)
           {
           RUNLIGHTSTATUS=1;
           }
      }
      if ((digitalRead(RUNLIGHTPIN)==0)&(debounceRUNLIGHT>0))
      {
      debounceRUNLIGHT--;
          if (debounceRUNLIGHT<2)
           {
           RUNLIGHTSTATUS=0;
           }
      }
 lastdebounceRUNLIGHT=Millis;

 }


  if ((Millis-lastdebounceLOWLIGHT)>1)// debouncing the input LOWLIGHT
  {
      if ((digitalRead(LOWLIGHTPIN)==1)&(debounceLOWLIGHT<30))
      {
      debounceLOWLIGHT++;
           if (debounceLOWLIGHT==20)
           {
           LOWLIGHTSTATUS=1;
           KITTstack++;
           Serial.println(KITTSTATUS); //debug remove later
           Serial.println(KITTstack);

           }
      }
      if ((digitalRead(LOWLIGHTPIN)==0)&(debounceLOWLIGHT>0))
      {
      debounceLOWLIGHT--;
          if (debounceLOWLIGHT<2)
           {
           LOWLIGHTSTATUS=0;
           }
      }
 lastdebounceLOWLIGHT=Millis;

 }


if ((Millis-lastdebounceHIGHLIGHT)>2)// debouncing the input RUNLIGHT
  {
      if ((digitalRead(HIGHLIGHTPIN)==1)&(debounceHIGHLIGHT<101))
      {
      debounceHIGHLIGHT++;
           if (debounceHIGHLIGHT==20)
           {
           HIGHLIGHTSTATUS=1;
           POLICEstack++;

           }
      }
      if ((digitalRead(HIGHLIGHTPIN)==0)&(debounceHIGHLIGHT>0))
      {
      debounceHIGHLIGHT--;
          if (debounceHIGHLIGHT<2)
           {
           HIGHLIGHTSTATUS=0;
           }
      }
 lastdebounceHIGHLIGHT=Millis;

 }

}

void Dirlight() //direction light function
 {
 if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.05))
 {
  strip.setPixelColor(0, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(39, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(40, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(0, ROUT, GOUT, BOUT);
  strip.setPixelColor(39, ROUT, GOUT, BOUT);
  strip.setPixelColor(40, ROUT, GOUT, BOUT);
 }


  if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.10))
 {
  strip.setPixelColor(1, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(38, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(41, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(1, ROUT, GOUT, BOUT);
  strip.setPixelColor(38, ROUT, GOUT, BOUT);
  strip.setPixelColor(41, ROUT, GOUT, BOUT);
 }


 if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.15))
 {
  strip.setPixelColor(2, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(37, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(42, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(2,ROUT, GOUT, BOUT);
  strip.setPixelColor(37, ROUT, GOUT, BOUT);
  strip.setPixelColor(42, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.20))
 {
  strip.setPixelColor(3, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(36, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(43, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(3, ROUT, GOUT, BOUT);
  strip.setPixelColor(36, ROUT, GOUT, BOUT);
  strip.setPixelColor(43, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.25))
 {
  strip.setPixelColor(4, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(35, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(44, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(4, ROUT, GOUT, BOUT);
  strip.setPixelColor(35, ROUT, GOUT, BOUT);
  strip.setPixelColor(44, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.30))
 {
  strip.setPixelColor(5, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(34, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(45, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(5, ROUT, GOUT, BOUT);
  strip.setPixelColor(34, ROUT, GOUT, BOUT);
  strip.setPixelColor(45, ROUT, GOUT, BOUT);
 }


if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.35))
 {
  strip.setPixelColor(6, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(33, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(46, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(6, ROUT, GOUT, BOUT);
  strip.setPixelColor(33, ROUT, GOUT, BOUT);
  strip.setPixelColor(46, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.40))
 {
  strip.setPixelColor(7, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(32, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(47, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(7, ROUT, GOUT, BOUT);
  strip.setPixelColor(32, ROUT, GOUT, BOUT);
  strip.setPixelColor(47, ROUT, GOUT, BOUT);
 }


if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.45))
 {
  strip.setPixelColor(8, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(31, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(48, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(8, ROUT, GOUT, BOUT);
  strip.setPixelColor(31, ROUT, GOUT, BOUT);
  strip.setPixelColor(48, ROUT, GOUT, BOUT);
 }


if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.50))
 {
  strip.setPixelColor(9, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(30, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(49, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(9, ROUT, GOUT, BOUT);
  strip.setPixelColor(30, ROUT, GOUT, BOUT);
  strip.setPixelColor(49, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.55))
 {
  strip.setPixelColor(10, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(29, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(50, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(10, ROUT, GOUT, BOUT);
  strip.setPixelColor(29, ROUT, GOUT, BOUT);
  strip.setPixelColor(50, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.60))
 {
  strip.setPixelColor(11, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(28, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(51, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(11, ROUT, GOUT, BOUT);
  strip.setPixelColor(28, ROUT, GOUT, BOUT);
  strip.setPixelColor(51, ROUT, GOUT, BOUT);
 }


  if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.65))
 {
  strip.setPixelColor(12, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(27, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(52, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(12, ROUT, GOUT, BOUT);
  strip.setPixelColor(27, ROUT, GOUT, BOUT);
  strip.setPixelColor(52, ROUT, GOUT, BOUT);
 }


 if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.70))
 {
  strip.setPixelColor(13, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(26, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(53, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(13, ROUT, GOUT, BOUT);
  strip.setPixelColor(26, ROUT, GOUT, BOUT);
  strip.setPixelColor(53, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.75))
 {
  strip.setPixelColor(14, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(25, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(54, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(14, ROUT, GOUT, BOUT);
  strip.setPixelColor(25, ROUT, GOUT, BOUT);
  strip.setPixelColor(54, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.80))
 {
  strip.setPixelColor(15, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(24, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(55, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(15, ROUT, GOUT, BOUT);
  strip.setPixelColor(24, ROUT, GOUT, BOUT);
  strip.setPixelColor(55, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.85))
 {
  strip.setPixelColor(16, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(23, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(56, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(16, ROUT, GOUT, BOUT);
  strip.setPixelColor(23, ROUT, GOUT, BOUT);
  strip.setPixelColor(56, ROUT, GOUT, BOUT);
 }


if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.90))
 {
  strip.setPixelColor(17, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(22, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(57, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(17, ROUT, GOUT, BOUT);
  strip.setPixelColor(22, ROUT, GOUT, BOUT);
  strip.setPixelColor(57, ROUT, GOUT, BOUT);
 }

if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*0.95))
 {
  strip.setPixelColor(18, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(21, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(58, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(18, ROUT, GOUT, BOUT);
  strip.setPixelColor(21, ROUT, GOUT, BOUT);
  strip.setPixelColor(58, ROUT, GOUT, BOUT);
 }


if ((Arrow==1)&(Millis-TriggerTime)>(CycleTime*1))
 {
  strip.setPixelColor(19, (255*ArrowBRI), (40*ArrowBRI), 0);
  strip.setPixelColor(20, (255*ArrowBRI),(40*ArrowBRI), 0);
  strip.setPixelColor(59, (255*ArrowBRI),(40*ArrowBRI), 0);
 }
 else
 {
  strip.setPixelColor(19, ROUT, GOUT, BOUT);
  strip.setPixelColor(20, ROUT, GOUT, BOUT);
  strip.setPixelColor(59, ROUT, GOUT, BOUT);
 }
 }

 //PROCEDURA STARTUP //////////////////////////////////////////////////////////////////////////////////////
   void Startup()
     {


   //fine ciclo for startup

   RStart=255;


   strip.setPixelColor(29, RStart, 0, BStart);
   strip.setPixelColor(30, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(28, RStart, 0, BStart);
   strip.setPixelColor(31, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(27, RStart, 0, BStart);
   strip.setPixelColor(32, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(26, RStart, 0, BStart);
   strip.setPixelColor(33, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(25, RStart, 0, BStart);
   strip.setPixelColor(34, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(24, RStart, 0, BStart);
   strip.setPixelColor(35, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(23, RStart, 0, BStart);
   strip.setPixelColor(36, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(22, RStart, 0, BStart);
   strip.setPixelColor(37, RStart, 0, BStart);
   strip.show();
   delay (100);
   strip.setPixelColor(21, RStart, 0, BStart);
   strip.setPixelColor(38, RStart, 0, BStart);
   strip.show();
   delay (100);

   strip.setPixelColor(20, RStart, 0, BStart);
   strip.setPixelColor(39, RStart, 0, BStart);
   strip.show();
   delay (100);
   }



 void POLICE()
 {



      if ((Millis-lastPOLICE)>POLICEtime)//every POLICETIME
           {       Serial.println("TASKPOLICE");
                 POLICEsequence++;
                 if(POLICEsequence==6)
                 {
                 POLICEsequence=1;
                 }







                 if (POLICEsequence==1)
                 {
                    for (i=0;i<61;i++)
                    {

                    strip.setPixelColor((i), 0, 0, 255);
                    POLICEtime=400;
                    }

                 }

                 if (POLICEsequence==2)
                 {
                    for (i=0;i<61;i++)
                    {

                    strip.setPixelColor((i), 255, 0, 0 );
                    POLICEtime=300;
                    }

                 }
                 if (POLICEsequence==3)
                 {
                    for (i=0;i<61;i++)
                    {

                    strip.setPixelColor((i), 0, 0, 255);
                    POLICEtime=150;
                    }

                 }
                 if (POLICEsequence==4)
                 {
                    for (i=0;i<61;i++)
                    {

                    strip.setPixelColor((i), 255, 0, 0);
                    POLICEtime=600;
                    }

                 }
                 if (POLICEsequence==5)
                 {
                    for (i=0;i<61;i++)
                    {

                    strip.setPixelColor((i), 0, 0, 255);
                    POLICEtime=450;
                    }

                 }

                 lastPOLICE=Millis;
               strip.show();
               }

         }

 void KITT()
 {


         if ((Millis-lastKITT)>KITTtime)//every KITTTIME
         {      Serial.println("MAICOL"); //debug remove later
                Serial.println(KITTfade); //debug remove later
                Serial.println(KITTrev); //debug remove later
                if (KITTfade==0)
                {
                KITTrev=0;
                }
                if (KITTfade==1400)
                {
                KITTrev=1;
                }


                if (KITTrev==0)
                {
                 KITTfade=(KITTfade+5);
                }
                if (KITTrev==1)
                {
                 KITTfade=(KITTfade-5);
                }

   if (((KITTfade-0)<255)&((KITTfade-0)>0))
   {
   strip.setPixelColor(0, KITTfade, 0, 0);
   strip.setPixelColor(39, KITTfade, 0, 0);
   strip.setPixelColor(40, KITTfade, 0, 0);
   }
   else
   {
   strip.setPixelColor(0, 0, 0, 0);
   strip.setPixelColor(39, 0, 0, 0);
   strip.setPixelColor(40, 0, 0, 0);
   }

   if (((KITTfade-60)<255)&((KITTfade-60)>0))
   {
   strip.setPixelColor(1, (KITTfade-60), 0, 0);
   strip.setPixelColor(38, (KITTfade-60), 0, 0);
   strip.setPixelColor(41, (KITTfade-60), 0, 0);
   }
   else
   {
   strip.setPixelColor(1, 0, 0, 0);
   strip.setPixelColor(38,0, 0, 0);
   strip.setPixelColor(41,0, 0, 0);
   }

    if (((KITTfade-120)<255)&((KITTfade-120)>0))
   {
   strip.setPixelColor(2,  (KITTfade-120), 0, 0);
   strip.setPixelColor(37, (KITTfade-120), 0, 0);
   strip.setPixelColor(42, (KITTfade-120), 0, 0);
   }
   else
   {
   strip.setPixelColor(2, 0, 0, 0);
   strip.setPixelColor(37, 0, 0, 0);
   strip.setPixelColor(42, 0, 0, 0);
   }


   if (((KITTfade-180)<255)&((KITTfade-180)>0))
   {
   strip.setPixelColor(3, (KITTfade-180), 0, 0);
   strip.setPixelColor(36, (KITTfade-180), 0, 0);
   strip.setPixelColor(43, (KITTfade-180), 0, 0);
   }
   else
   {
   strip.setPixelColor(3, 0, 0, 0);
   strip.setPixelColor(36, 0, 0, 0);
   strip.setPixelColor(43, 0, 0, 0);
   }


   if (((KITTfade-240)<255)&((KITTfade-240)>0))
   {
   strip.setPixelColor(4, (KITTfade-240), 0, 0);
   strip.setPixelColor(35, (KITTfade-240), 0, 0);
   strip.setPixelColor(44, (KITTfade-240), 0, 0);
   }
   else
   {
   strip.setPixelColor(4, 0, 0, 0);
   strip.setPixelColor(35, 0, 0, 0);
   strip.setPixelColor(44, 0, 0, 0);
   }



   if (((KITTfade-300)<255)&((KITTfade-300)>0))
   {
   strip.setPixelColor(5, (KITTfade-300), 0, 0);
   strip.setPixelColor(34, (KITTfade-300), 0, 0);
   strip.setPixelColor(45, (KITTfade-300), 0, 0);
   }
   else
   {
   strip.setPixelColor(5, 0, 0, 0);
   strip.setPixelColor(34, 0, 0, 0);
   strip.setPixelColor(45, 0, 0, 0);
   }

   if (((KITTfade-360)<255)&((KITTfade-360)>0))
   {
   strip.setPixelColor(6, (KITTfade-360), 0, 0);
   strip.setPixelColor(33, (KITTfade-360), 0, 0);
   strip.setPixelColor(46, (KITTfade-360), 0, 0);
   }
   else
   {
   strip.setPixelColor(6,0, 0, 0);
   strip.setPixelColor(33, 0, 0, 0);
   strip.setPixelColor(46, 0, 0, 0);
   }

   if (((KITTfade-420)<255)&((KITTfade-420)>0))
   {
   strip.setPixelColor(7,  (KITTfade-420), 0, 0);
   strip.setPixelColor(32, (KITTfade-420), 0, 0);
   strip.setPixelColor(47, (KITTfade-420), 0, 0);
   }
   else
   {
   strip.setPixelColor(7,  0, 0, 0);
   strip.setPixelColor(32, 0, 0, 0);
   strip.setPixelColor(47, 0, 0, 0);
   }

   if (((KITTfade-480)<255)&((KITTfade-480)>0))
   {
   strip.setPixelColor(8,  (KITTfade-480), 0, 0);
   strip.setPixelColor(31, (KITTfade-480), 0, 0);
   strip.setPixelColor(48, (KITTfade-480), 0, 0);
   }
   else
   {
   strip.setPixelColor(8,  0, 0, 0);
   strip.setPixelColor(31, 0, 0, 0);
   strip.setPixelColor(48, 0, 0, 0);
   }

   if (((KITTfade-540)<255)&((KITTfade-540)>0))
   {
   strip.setPixelColor(9,  (KITTfade-540), 0, 0);
   strip.setPixelColor(30, (KITTfade-540), 0, 0);
   strip.setPixelColor(49, (KITTfade-540), 0, 0);
   }
   else
   {
   strip.setPixelColor(9, 0, 0, 0);
   strip.setPixelColor(30, 0, 0, 0);
   strip.setPixelColor(49, 0, 0, 0);
   }

   if (((KITTfade-600)<255)&((KITTfade-600)>0))
   {
   strip.setPixelColor(10,(KITTfade-600), 0, 0);
   strip.setPixelColor(29, (KITTfade-600), 0, 0);
   strip.setPixelColor(50, (KITTfade-600), 0, 0);
   }
   else
   {
   strip.setPixelColor(10, 0, 0, 0);
   strip.setPixelColor(29, 0, 0, 0);
   strip.setPixelColor(50, 0, 0, 0);
   }

   if (((KITTfade-660)<255)&((KITTfade-660)>0))
   {
   strip.setPixelColor(11, (KITTfade-660), 0, 0);
   strip.setPixelColor(28, (KITTfade-660), 0, 0);
   strip.setPixelColor(51, (KITTfade-660), 0, 0);
   }
   else
   {
   strip.setPixelColor(11, 0, 0, 0);
   strip.setPixelColor(28, 0, 0, 0);
   strip.setPixelColor(51, 0, 0, 0);
   }

   if (((KITTfade-720)<255)&((KITTfade-720)>0))
   {
   strip.setPixelColor(12, (KITTfade-720), 0, 0);
   strip.setPixelColor(27, (KITTfade-720), 0, 0);
   strip.setPixelColor(52, (KITTfade-720), 0, 0);
   }
   else
   {
   strip.setPixelColor(12, 0, 0, 0);
   strip.setPixelColor(27, 0, 0, 0);
   strip.setPixelColor(52, 0, 0, 0);
   }


   if (((KITTfade-780)<255)&((KITTfade-780)>0))
   {
   strip.setPixelColor(13, (KITTfade-780), 0, 0);
   strip.setPixelColor(26, (KITTfade-780), 0, 0);
   strip.setPixelColor(53, (KITTfade-780), 0, 0);
   }
   else
   {
   strip.setPixelColor(13, 0, 0, 0);
   strip.setPixelColor(26, 0, 0, 0);
   strip.setPixelColor(53, 0, 0, 0);
   }

   if (((KITTfade-840)<255)&((KITTfade-840)>0))
   {
   strip.setPixelColor(14, (KITTfade-840), 0, 0);
   strip.setPixelColor(25, (KITTfade-840), 0, 0);
   strip.setPixelColor(54, (KITTfade-840), 0, 0);
   }
   else
   {
   strip.setPixelColor(14, 0, 0, 0);
   strip.setPixelColor(25, 0, 0, 0);
   strip.setPixelColor(54, 0, 0, 0);
   }

   if (((KITTfade-900)<255)&((KITTfade-900)>0))
   {
   strip.setPixelColor(15, (KITTfade-900), 0, 0);
   strip.setPixelColor(24, (KITTfade-900), 0, 0);
   strip.setPixelColor(55, (KITTfade-900), 0, 0);
   }
   else
   {
   strip.setPixelColor(15, 0, 0, 0);
   strip.setPixelColor(24, 0, 0, 0);
   strip.setPixelColor(55, 0, 0, 0);
   }

   if (((KITTfade-960)<255)&((KITTfade-960)>0))
   {
   strip.setPixelColor(16, (KITTfade-960), 0, 0);
   strip.setPixelColor(23, (KITTfade-960), 0, 0);
   strip.setPixelColor(56, (KITTfade-960), 0, 0);
   }
   else
   {
   strip.setPixelColor(16, 0, 0, 0);
   strip.setPixelColor(23, 0, 0, 0);
   strip.setPixelColor(56, 0, 0, 0);
   }

    if (((KITTfade-1020)<255)&((KITTfade-1020)>0))
   {
   strip.setPixelColor(17, (KITTfade-1020), 0, 0);
   strip.setPixelColor(22, (KITTfade-1020), 0, 0);
   strip.setPixelColor(57, (KITTfade-1020), 0, 0);
   }
   else
   {
...

This file has been truncated, please download it to see its full contents.
I revamped my car headlights with ws2812 and arduino nano! S

Story

Introduction

Previous attempts

Additionals car wiring

Long terms problems

PCB Schematic

CODE

Schematics

Harness schematic

PCB schematic

Code

Headlight firmware

Credits

NeedToDIY

Comments

Embed the widget on your own site

I revamped my car headlights with ws2812 and arduino nano! S

I revamped my car headlights with ws2812 and arduino nano! S

Story

Introduction

Previous attempts

Additionals car wiring

Long terms problems

PCB Schematic

CODE

Schematics

Harness schematic

PCB schematic

Code

Headlight firmware

Credits

NeedToDIY

Comments

Related channels and tags
