This guide explains how to build a custom Object Detection system using the Google Coral Dev Board Micro, and a custom dataset trained with Tensorflow, in Google Colab.
This approach allows the Machine Learning (ML) model to run inference locally on the Dev Board Micro using its' onboard Edge Tensor Processing Unit (TPU), with no need for internet connectivity!
The TPU to Machine Learning what a GPU is to graphics (both are Application Specific Integrated Circuits (ASICs)), allowing the model to execute on-chip at impressive speeds, with over 2 trillion operations per second! (See the Specs).
Dataset CollectionAs we need a lot of images of the object to train our model, we decided Bus Stops were a common item locally we could use.
First we took some video footage whilst driving around locally one day in slow motion.
Then from that we extracted 70 images at 640px square (to include some differing backgrounds).
Images can be any size, ours are 2x the resolution of the on-board Coral camera, however the larger the images the longer they will take.
The larger the images the longer training will take however.
These need to be put into a folder called "images" (case sensitive).
Create another folder "Annotations" next to the images folder.
Then we used the LabelImg tool.
Click the "Save Dir" button on the left, and select the "Annotations" folder next to our images folder from the previous step.
Set the Default Label on the right hand side (if using one class), and check the "Use fdafult label" checkbox next to it.
Then we draw our bounding boxes around each bus stop by left clicking and dragging.
Now click Save on the left hand side, ensuring the format option below it is set to PascalVOC.
Once all images are annotated we can ZIP both folders together into a file called "dataset.zip"
Now we can open the Colab Notebook, and connect to a runtime. If youre just trying it out select CPU as this is free and has the longest runtime. GPU Processing is faster but may require purchasing compute units to run at peak times.
Once the runtime is connected, we can upload our dataset.zip by clicking on the file manager on the left, and drag and drop it there....
Now we can start running each code block one by one... and at the end the model will be downlaoded to your PC's Downloads folder.
You can use our prebuilt Bus Stop Models from this link if preferred.
This will take about 45m to 1h to complete depending on Runtime in use and internet connection speed for upload/download, and image quantity and size
Once completed and the files are downloaded the runtime can be disconnected.
The Additional Board Package URL is needed to add the Coral Micro Boards, which can be added on the IDE Locations Screen:
https://dl.google.com/coral/micro/package_coral_index.json
Once Added the boards can be installed from the Micro Explorer.
Download the Sketch ExampleDownload the CoralCustomObjectDetection ZIP from this link, and extract it to a location on your PC.
Update TFLite FilesUsing the files from the ZIP downloaded from Colab (or our pre-trained ones):
- The
model_int8_edgetpu.tflite
file needs to go into the data folder inside the project. - The
metadata.hpp
goes in the project next to the INO file.
Open the Solution in Visual Micro as normal, and select the Dev Board Micro + Wifi Add-on from the boards list.
Also ensure you set the board option for Upload Sketch + Data.
Connect the board to your PC with a USB-C Lead and check the COM port is selected correctly.
If your board just has the orange light showing, and no COM Port, you may need to force it into SDP mode first.See the Coral Micro Troubleshooting Guide.
In the INO File there are two #defines for WIFI credentials at the top, amend these to suit the network you are using.
Upload to your BoardClick the Build and Upload button to compile and flash the code, and after a minute or so the board should spring into action.
View Serial Output and Open WebpageThe Serial output will print a list of all files on the board, and it will show the address its serving the webpage on.
Copy and paste the URL into your browser and hit enter to load the page.
Watch it work!Now the page has loaded you can see your camera stream on the page. If you point it at one of the objects you have trained it for, you should see the bounding box and condfidence for a recognised item. If you don't have a real world example of an object you can point it to one of the images it was trained on on your computer screen.
Wrapping UpSo there we have it! A customisable embedded object detection system, which runs completely on board without the cloud. Of course if you used this in e.g. a robot mower, you could set the board to be an access point, and only view the webpage when you're close by.... Or once you're happy with it remove the Wifi code altogether. It doesn't have be on a network of any form to work.
Video Guide/**
* Adapted from Shawn Hymel's sketch to add WiFi capability, and complete webpage with bounding box drawing
* Example Model created with Colab Notebook:
* https://colab.research.google.com/drive/163JTsZU_bthrhiIh5QncyuzGeHCC6e_r?usp=sharing
* (Clone Of: https://colab.research.google.com/github/ShawnHymel/google-coral-micro-object-detection/blob/master/notebooks/mediapipe-object-detection-learning.ipynb)
*
* This code is additions to the below article:
* https://github.com/ShawnHymel/google-coral-micro-object-detection/tree/master/firmware/object-detection-http
* Which uses tasks though is still a single threaded infinitely looped execution.
*
* MLModels can be reviewed using Netron Website, which helps visualise the inputs and outputs
* https://netron.app/
*
* TODO: Does being able to fit the tensors etc help us to use Teachable Machine?
* This could be the in depth version, and that the nice click and go version for classification....
*
* -----------------------------------------------------------------------------------------
* Object Detection with HTTP server over WiFi (via USB does not work on Windows Clients)
*
* Perform object detection with the provided TFLite file running on the TPU.
* Image and object detection data is streamed to an HTTP server that can be
* accessed via Ethernet-over-USB connection.
*
* Based on the following code examples from Google LLC:
* - https://github.com/google-coral/coralmicro/tree/main/examples/camera_streaming_http
* - https://github.com/google-coral/coralmicro/tree/main/examples/detect_objects
*
* WARNING: There is a bug in HTTP handler part of this code that seems to
* corrupt the bounding box info when requested by the client. I suspect this is
* due to the server not being able to handle multiple requests at the same time
* or there is a race condition with the bounding box info being updated. If you
* solve this, please let me know. You will get a metaphorical gold star.
*
* Author: Shawn Hymel
* Date: November 25, 2023
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* http://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
// WiFi Credentials for the Wifi HTTP Server
#define WIFI_SSID "xxxxxxxxxxx"
#define WIFI_PASS "xxxxxxxxxxx"
// Wifi HTTP Server - 0: Disable, 1: Enable
#define ENABLE_HTTP_SERVER 1
// Ethernet Over USB (Linux Only) - 0: Disable, 1: Enable
#define USEETHERNETOVERUSB 0
// Show Files on-chip on startup - 0: Disable, 1: Enable
#define PRINTFSTOSERIAL_ONBOOT 1
// Show Detection Information via Serial (Bounding Box, Confidence etc) - 0: Disable, 1: Enable
#define DEBUG 1
#include <cstdio>
#include <vector>
#include <cmath>
#include "libs/base/filesystem.h"
#include "libs/base/http_server.h"
#include "libs/base/led.h"
#include "libs/base/strings.h"
#include "libs/base/utils.h"
#include "libs/camera/camera.h"
#include "libs/libjpeg/jpeg.h"
#include "libs/tensorflow/detection.h"
#include "libs/tensorflow/utils.h"
#include "libs/tpu/edgetpu_manager.h"
#include "libs/tpu/edgetpu_op.h"
#include "third_party/freertos_kernel/include/FreeRTOS.h"
#include "third_party/freertos_kernel/include/task.h"
#include "third_party/freertos_kernel/include/semphr.h"
#include "third_party/tflite-micro/tensorflow/lite/micro/micro_error_reporter.h"
#include "third_party/tflite-micro/tensorflow/lite/micro/micro_interpreter.h"
#include "third_party/tflite-micro/tensorflow/lite/micro/micro_mutable_op_resolver.h"
#include "metadata.hpp"
#include <WiFi.h>
// NOTE: These MUST Be present to ensure floats can be printed and used in strings!!
asm(".global _printf_float"); // This should be defined in cxxflags.txt
asm(".global _scanf_float"); // this is missing altogether!
namespace coralmicro {
namespace {
// Image result struct
typedef struct {
std::string info;
std::vector<uint8_t>* jpeg;
} ImgResult;
// Bounding box struct
typedef struct {
float id;
float score;
float ymin;
float xmin;
float ymax;
float xmax;
} BBox;
// Camera settings
constexpr auto camRotation = CameraRotation::k270; // Default: CameraRotation::k0
// Globals
constexpr char kIndexFileName[] = "/index.html";
constexpr char kCameraStreamUrlPrefix[] = "/camera_stream";
constexpr char kBoundingBoxPrefix[] = "/bboxes";
constexpr char kModelPath[] =
"/model_int8_edgetpu.tflite";
constexpr int kTensorArenaSize = 8 * 1024 * 1024;
STATIC_TENSOR_ARENA_IN_SDRAM(tensor_arena, kTensorArenaSize);
static std::vector<uint8_t>* img_ptr;
static SemaphoreHandle_t img_mutex;
static SemaphoreHandle_t bbox_muchtex;
static SemaphoreHandle_t websrv_muchtex;
static int img_width;
static int img_height;
static constexpr float score_threshold = 0.5f;
static constexpr float iou_threshold = 0.3f;
static constexpr size_t max_bboxes = 5;
static constexpr unsigned int bbox_buf_size = 100 + (max_bboxes * 200) + 1;
static char bbox_buf[bbox_buf_size];
// Copy of image data for HTTP server
#if ENABLE_HTTP_SERVER
static std::vector<uint8_t>* img_copy;
#endif
/*******************************************************************************
* Functions
*/
void Blink(unsigned int num, unsigned int delay_ms);
bool CalculateAnchorBox(unsigned int idx, float* anchor);
float CalculateIOU(BBox* bbox1, BBox* bbox2);
#if ENABLE_HTTP_SERVER
/**
* Handle HTTP requests
*/
HttpServer::Content UriHandler(const char* uri) {
// Give client main page
if (StrEndsWith(uri, "index.shtml") ||
StrEndsWith(uri, "coral_micro_camera_something.html")) {
return std::string(kIndexFileName);
}
// Deliver our file from the FileSystem
else if (StrEndsWith(uri, "coral_micro_camera.html")) {
printf("Loading Camera HTML From LittleFS...\r\n");
lfs_dir_t root;
CHECK(lfs_dir_open(Lfs(), &root, "/") >= 0);
std::string readstr;
printf("Reading File...\r\n");
CHECK(LfsReadFile("/web/coral_micro_camera.html", &readstr));
CHECK(lfs_dir_close(Lfs(), &root) >= 0);
printf("Parsing to Vector...\r\n");
// If we return a string its treated as a file.... which would be right really! (if it would serve the file by default)
std::vector<uint8_t> response;
response.reserve(5000);
StrAppend(&response, readstr.c_str());
printf("Parsing to Vector...\r\n");
return response;
}
// Give client compressed image data
else if (StrEndsWith(uri, kCameraStreamUrlPrefix)) {
// Read image from shared memory and compress to JPG
std::vector<uint8_t> jpeg;
if (xSemaphoreTake(img_mutex, portMAX_DELAY) == pdTRUE) {
JpegCompressRgb(
img_copy->data(),
img_width,
img_height,
75, // Quality
&jpeg
);
xSemaphoreGive(img_mutex);
}
return jpeg;
// Give client bounding box info
}
else if (StrEndsWith(uri, kBoundingBoxPrefix)) {
// Read bounding box info from shared memory and convert to vector of bytes
char bbox_info_copy[bbox_buf_size];
std::vector<uint8_t> bbox_info_bytes;
if (xSemaphoreTake(bbox_muchtex, portMAX_DELAY) == pdTRUE) {
std::strcpy(bbox_info_copy, bbox_buf);
bbox_info_bytes.assign(
bbox_info_copy,
bbox_info_copy + std::strlen(bbox_info_copy)
);
if (bbox_info_copy[25] == ']' && bbox_info_copy[24] == '[') {
printf("No Boxes");
}
else {
printf("BBoxes:%s\r\n", bbox_info_copy);
}
xSemaphoreGive(bbox_muchtex);
}
// TODO: Figure out the multi-request or race condition bug that is causing
// the bbox_info_bytes to be corrupted. The workaround is to have the
// client timeout if it doesn't get a response in some amount of time.
// vMicro: We haven't seen corruption per-se but the float objects broke the JSON string
// as soon as one was included so it was never fully formed.
// This was due to the missing ASM instructions at the top (or additional cxxflags.txt entries required)
return bbox_info_bytes;
}
return {};
}
#endif
void PrintDirectory(lfs_dir_t* dir, const char* path, int num_tabs) {
constexpr int kMaxDepth = 3;
if (num_tabs > kMaxDepth) {
return;
}
lfs_info info;
while (lfs_dir_read(Lfs(), dir, &info) > 0) {
if (info.name[0] == '.') {
continue;
}
for (int i = 0; i < num_tabs; ++i) {
printf("\t");
}
printf("%s", info.name);
if (info.type == LFS_TYPE_DIR) {
char subpath[LFS_NAME_MAX];
printf("/\r\n");
lfs_dir_t subdir;
snprintf(subpath, LFS_NAME_MAX, "%s/%s", path, info.name);
CHECK(lfs_dir_open(Lfs(), &subdir, subpath) >= 0);
PrintDirectory(&subdir, subpath, num_tabs + 1);
CHECK(lfs_dir_close(Lfs(), &subdir) >= 0);
}
else {
printf("\t\t%ld\r\n", info.size);
}
}
}
void PrintFilesystemContents() {
lfs_dir_t root;
CHECK(lfs_dir_open(Lfs(), &root, "/") >= 0);
printf("Printing filesystem:\r\n");
PrintDirectory(&root, "", 0);
printf("Finished printing filesystem.\r\n");
CHECK(lfs_dir_close(Lfs(), &root) >= 0);
}
/**
* Loop forever taking images from the camera and performing inference
*/
[[noreturn]] void InferenceTask(void* param) {
#if !USEETHERNETOVERUSB
// Wait for the Webserver to startup
while (xSemaphoreTake(websrv_muchtex, configTICK_RATE_HZ * 1000) != pdTRUE) {
delay(500);
}
#endif
// Used for calculating FPS
unsigned long dtime;
unsigned long timestamp;
unsigned long timestamp_prev = xTaskGetTickCount() *
(1000 / configTICK_RATE_HZ);
// x_center, y_center, w, h
float anchor[4] = { 0.0f, 0.0f, 0.0f, 0.0f };
// Load model
std::vector<uint8_t> model;
if (!LfsReadFile(kModelPath, &model)) {
printf("ERROR: Failed to load %s\r\n", kModelPath);
vTaskSuspend(nullptr);
}
// Initialize TPU
auto tpu_context = EdgeTpuManager::GetSingleton()->OpenDevice();
if (!tpu_context) {
printf("ERROR: Failed to get EdgeTpu context\r\n");
vTaskSuspend(nullptr);
}
// Initialize ops
tflite::MicroErrorReporter error_reporter;
tflite::MicroMutableOpResolver<3> resolver;
resolver.AddDequantize();
resolver.AddDetectionPostprocess();
resolver.AddCustom(kCustomOp, RegisterCustomOp());
// Initialize TFLM interpreter for inference
tflite::MicroInterpreter interpreter(
tflite::GetModel(model.data()),
resolver,
tensor_arena,
kTensorArenaSize,
&error_reporter
);
if (interpreter.AllocateTensors() != kTfLiteOk) {
printf("ERROR: AllocateTensors() failed\r\n");
vTaskSuspend(nullptr);
}
// Check model input tensor size
if (interpreter.inputs().size() != 1) {
printf("ERROR: Model must have only one input tensor\r\n");
vTaskSuspend(nullptr);
}
// Configure model inputs and outputs
auto* input_tensor = interpreter.input_tensor(0);
img_height = input_tensor->dims->data[1];
img_width = input_tensor->dims->data[2];
img_ptr = new std::vector<uint8>(img_height * img_width *
CameraFormatBpp(CameraFormat::kRgb));
std::vector<tensorflow::Object> results;
#if ENABLE_HTTP_SERVER
// Copy image to shared memory for HTTP Server to send on request
img_copy = new std::vector<uint8_t>(img_ptr->size());
#endif
// Get output tensor shapes
TfLiteTensor* tensor_bboxes = interpreter.output_tensor(0);
TfLiteTensor* tensor_scores = interpreter.output_tensor(1);
unsigned int num_boxes = tensor_bboxes->dims->data[1];
unsigned int num_coords = tensor_bboxes->dims->data[2];
unsigned int num_classes = tensor_scores->dims->data[2];
// Get quantization parameters
const float input_scale = input_tensor->params.scale;
const int input_zero_point = input_tensor->params.zero_point;
const float locs_scale = tensor_bboxes->params.scale;
const int locs_zero_point = tensor_bboxes->params.zero_point;
const float scores_scale = tensor_scores->params.scale;
const int scores_zero_point = tensor_scores->params.zero_point;
// Convert threshold to fixed point
uint8_t score_threshold_quantized =
static_cast<uint8_t>(score_threshold * 256);
// Print input/output details
#if DEBUG
printf("num_boxes: %d\r\n", num_boxes);
printf("num_coords: %d\r\n", num_coords);
printf("num_classes: %d\r\n", num_classes);
printf("bytes in tensor_bboxes: %d\r\n", tensor_bboxes->bytes);
if (tensor_scores->data.data == nullptr) {
printf("tensor_scores.data is empty!\r\n");
}
printf("input_scale: %f\r\n", input_scale);
printf("input_zero_point: %d\r\n", input_zero_point);
printf("locs_scale: %f\r\n", locs_scale);
printf("locs_zero_point: %d\r\n", locs_zero_point);
printf("scores_scale: %f\r\n", scores_scale);
printf("scores_zero_point: %d\r\n", scores_zero_point);
printf("score_threshold_quantized: %d\r\n", score_threshold_quantized);
#endif
// Do forever
while (true) {
std::vector<std::vector<float>> bbox_list;
// Calculate time between inferences
timestamp = xTaskGetTickCount() * (1000 / configTICK_RATE_HZ);
dtime = timestamp - timestamp_prev;
timestamp_prev = timestamp;
// Turn status LED on to let the user know we're taking a photo
LedSet(Led::kUser, true);
// Get frame from camera using the configuration we set (~38 ms)
if (xSemaphoreTake(img_mutex, portMAX_DELAY) == pdTRUE) {
// Configure camera image
CameraFrameFormat fmt{
CameraFormat::kRgb,
CameraFilterMethod::kBilinear,
camRotation,
img_height,
img_width,
false, // Preserve ratio
img_ptr->data(), // Where the image is saved
true // Auto white balance
};
// Take a photo
if (!CameraTask::GetSingleton()->GetFrame({ fmt })) {
printf("ERROR: Could not capture frame from camera\r\n");
continue;
}
// Turn status LED off to let the user know we're done taking a photo
LedSet(Led::kUser, false);
// Copy image to input tensor (~6 ms)
std::memcpy(
tflite::GetTensorData<uint8_t>(input_tensor),
img_ptr->data(),
img_ptr->size()
);
// Perform inference (~65 ms)
if (interpreter.Invoke() != kTfLiteOk) {
printf("ERROR: Inference failed\r\n");
continue;
}
// Get data
uint8_t* scores = tensor_scores->data.uint8;
uint8_t* raw_boxes = tensor_bboxes->data.uint8;
// Find bounding boxes with scores above threshold
for (unsigned int i = 0; i < metadata::num_anchors; ++i) {
for (unsigned int c = 0; c < num_classes; ++c) {
// Only keep boxes above a particular score threshold
if (scores[i * num_classes + c] > score_threshold_quantized) {
// Calculate anchor box coordinates based on index
if (!CalculateAnchorBox(i, anchor)) {
printf("ERROR: Could not calculate anchor box\r\n");
continue;
}
// Assume raw box output tensor is given as YXHW format
float y_center = raw_boxes[(i * num_coords) + 0];
float x_center = raw_boxes[(i * num_coords) + 1];
float h = raw_boxes[(i * num_coords) + 2];
float w = raw_boxes[(i * num_coords) + 3];
// De-quantize the output boxes (move to x, y, w, h format)
x_center = (x_center - locs_zero_point) * locs_scale;
y_center = (y_center - locs_zero_point) * locs_scale;
w = (w - locs_zero_point) * locs_scale;
h = (h - locs_zero_point) * locs_scale;
// Scale the output boxes from anchor coordinates
x_center = x_center / metadata::x_scale * anchor[2] + anchor[0];
y_center = y_center / metadata::y_scale * anchor[3] + anchor[1];
if (metadata::apply_exp_scaling) {
w = exp(w / metadata::w_scale) * anchor[2];
h = exp(h / metadata::h_scale) * anchor[3];
}
else {
w = w / metadata::w_scale * anchor[2];
h = h / metadata::h_scale * anchor[3];
}
// Convert box coordinates to top left and bottom right
float x_min = x_center - w / 2.0f;
float y_min = y_center - h / 2.0f;
float x_max = x_center + w / 2.0f;
float y_max = y_center + h / 2.0f;
// Clamp values to between 0 and 1
x_min = std::max(std::min(x_min, 1.0f), 0.0f);
y_min = std::max(std::min(y_min, 1.0f), 0.0f);
x_max = std::max(std::min(x_max, 1.0f), 0.0f);
y_max = std::max(std::min(y_max, 1.0f), 0.0f);
// De-quantize the score
float score = (scores[(i * num_classes) + c] - scores_zero_point) *
scores_scale;
// Add to list of bboxes
bbox_list.push_back({ (float)c, score,
y_min, x_min, y_max, x_max });
}
}
}
// Copy image to separate buffer for HTTP server
#if ENABLE_HTTP_SERVER
std::memcpy(
img_copy->data(),
img_ptr->data(),
img_ptr->size()
);
#endif
// Unlock critical section
xSemaphoreGive(img_mutex);
}
// Sort bboxes by score
std::sort(bbox_list.begin(), bbox_list.end(),
[](const std::vector<float>& a, const std::vector<float>& b) {
return a[1] > b[1];
}
);
// Perform non-maximum suppression
for (unsigned int i = 0; i < bbox_list.size(); ++i) {
for (unsigned int j = i + 1; j < bbox_list.size(); ++j) {
BBox bbox1 = {
bbox_list[i][0],
bbox_list[i][1],
bbox_list[i][2],
bbox_list[i][3],
bbox_list[i][4],
bbox_list[i][5]
};
BBox bbox2 = {
bbox_list[j][0],
bbox_list[j][1],
bbox_list[j][2],
bbox_list[j][3],
bbox_list[j][4],
bbox_list[j][5]
};
float iou = CalculateIOU(&bbox1, &bbox2);
if (iou > iou_threshold) {
bbox_list.erase(bbox_list.begin() + j);
--j;
}
}
}
// Determine number of bboxes to send
size_t num_bboxes_output = (bbox_list.size() < max_bboxes) ?
bbox_list.size() : max_bboxes;
// Convert top k bboxes to JSON string
std::string bbox_string = "{\"dtime\": " + std::to_string(dtime) + ", ";
bbox_string.append("\"bboxes\": [");
for (unsigned int i = 0; i < num_bboxes_output; ++i) {
int class_id = static_cast<int>(bbox_list[i][0]);
bbox_string.append("{\"id\": " + std::to_string(class_id) + ", ");
bbox_string += "\"score\": " + std::to_string(bbox_list[i][1]) + ", ";
bbox_string.append("\"xmin\": " + std::to_string(bbox_list[i][3]) + ", ");
bbox_string.append("\"ymin\": " + std::to_string(bbox_list[i][2]) + ", ");
bbox_string.append("\"xmax\": " + std::to_string(bbox_list[i][5]) + ", ");
bbox_string.append("\"ymax\": " + std::to_string(bbox_list[i][4]) + "}");
if (i != num_bboxes_output - 1) {
bbox_string.append(", ");
}
}
bbox_string.append("]}");
// Check length of JSON string
if (int(bbox_string.length()) > bbox_buf_size) {
printf("ERROR: Bounding box JSON string too long\r\n");
continue;
}
// Convert global char array
if (xSemaphoreTake(bbox_muchtex, portMAX_DELAY) == pdTRUE) {
std::strcpy(bbox_buf, bbox_string.c_str());
xSemaphoreGive(bbox_muchtex);
}
// Print bounding box JSON string
printf("%s\r\n", bbox_buf);
// Sleep to let other tasks run (Webserver)
vTaskDelay(pdMS_TO_TICKS(10));
}
}
/**
* Blink error codes on the status LED
*/
void Blink(unsigned int num, unsigned int delay_ms) {
static bool on = false;
for (unsigned int i = 0; i < num * 2; i++) {
on = !on;
coralmicro::LedSet(Led::kStatus, on);
vTaskDelay(pdMS_TO_TICKS(delay_ms));
}
}
/**
* Calculate anchor box coordinates based on index and metadata
*/
bool CalculateAnchorBox(unsigned int idx, float* anchor) {
unsigned int sector = 0;
float x_idx;
float x_center;
float y_idx;
float y_center;
float w;
float h;
// Check index
if (idx >= metadata::num_anchors) {
return false;
}
// Find the sector that the index belongs in
for (unsigned int s = 0; s < metadata::num_sectors; ++s) {
if (idx >= metadata::reset_idxs[s]) {
sector = s;
}
}
// Find the X centert
x_idx = (idx % metadata::num_xs_per_y[sector]) /
metadata::num_anchors_per_coord;
x_center = (metadata::x_strides[sector] / 2.0f) +
(x_idx * metadata::x_strides[sector]);
// Find the Y center
y_idx = (idx - metadata::reset_idxs[sector]) /
metadata::num_xs_per_y[sector];
y_center = (metadata::y_strides[sector] / 2.0f) +
(y_idx * metadata::y_strides[sector]);
// Find the width and height
w = metadata::widths[sector][idx % metadata::num_anchors_per_coord];
h = metadata::heights[sector][idx % metadata::num_anchors_per_coord];
// Save anchor box coordinates
anchor[0] = x_center;
anchor[1] = y_center;
anchor[2] = w;
anchor[3] = h;
return true;
}
/**
* Calculate intersection over union (IOU) between two bounding boxes
*/
float CalculateIOU(BBox* bbox1, BBox* bbox2) {
// Calculate intersection
float x_min = std::max(bbox1->xmin, bbox2->xmin);
float y_min = std::max(bbox1->ymin, bbox2->ymin);
float x_max = std::min(bbox1->xmax, bbox2->xmax);
float y_max = std::min(bbox1->ymax, bbox2->ymax);
float intersection = std::max(0.0f, x_max - x_min) *
std::max(0.0f, y_max - y_min);
// Calculate union
float bbox1_area = (bbox1->xmax - bbox1->xmin) *
(bbox1->ymax - bbox1->ymin);
float bbox2_area = (bbox2->xmax - bbox2->xmin) *
(bbox2->ymax - bbox2->ymin);
float union_area = bbox1_area + bbox2_area - intersection;
// Calculate IOU
float iou = 0.0f;
if (union_area > 0.0f) {
iou = intersection / union_area;
}
return iou;
}
/*******************************************************************************
* Main
*/
void Main() {
// Say hello
Blink(3, 500);
#if DEBUG
printf("Object detection inference and HTTP server over USB\r\n");
#endif
// Initialize image mutex
img_mutex = xSemaphoreCreateMutex();
if (img_mutex == NULL) {
printf("Error creating image mutex\r\n");
while (true) {
Blink(2, 100);
}
}
// Initialize bounding box mutex
bbox_muchtex = xSemaphoreCreateMutex();
if (bbox_muchtex == NULL) {
printf("Error creating bbox mutex\r\n");
while (true) {
Blink(2, 100);
}
}
// Initialize WebServer mutex
websrv_muchtex = xSemaphoreCreateBinary();
if (websrv_muchtex == NULL) {
printf("Error creating websrv mutex\r\n");
while (true) {
Blink(2, 100);
}
}
// Initialize camera
CameraTask::GetSingleton()->SetPower(true);
CameraTask::GetSingleton()->Enable(CameraMode::kStreaming);
// Start capture and inference task
#if DEBUG
printf("Starting inference task\r\n");
#endif
xTaskCreate(
&InferenceTask,
"InferenceTask",
configMINIMAL_STACK_SIZE * 30,
nullptr,
kAppTaskPriority - 1, // Make inference lower than console/server
nullptr
);
#if PRINTFSTOSERIAL_ONBOOT
// Show Files onboard as part of startup
PrintFilesystemContents();
#endif
#if ENABLE_HTTP_SERVER
#if USEETHERNETOVERUSB
// Initialize IP over USB
std::string usb_ip;
if (GetUsbIpAddress(&usb_ip)) {
#if DEBUG
printf("Serving on: http://%s/coral_micro_camera.html\r\n", usb_ip.c_str());
#endif
}
#else
// Initialize WIFI
WiFiConnect(WIFI_SSID, WIFI_PASS, 20);
while (!WiFiIsConnected()) {
delay(1000);
}
#if DEBUG
printf("Serving on: http://%s/coral_micro_camera.html\r\n", WiFiGetIp().value().c_str());
#endif
#endif
// Initialize HTTP server (attach request handler)
HttpServer http_server;
http_server.AddUriHandler(UriHandler);
UseHttpServer(&http_server);
xSemaphoreGive(websrv_muchtex);
#endif
// Main will go to sleep
vTaskSuspend(nullptr);
}
} // namespace
} // namespace coralmicro
void setup() {
coralmicro::Main();
}
void loop() {
}
///**
// * Entrypoint
// */
//extern "C" void app_main(void* param) {
// (void)param;
// coralmicro::Main();
//}
Local Board.txt Overrides
Arduinorecipe.hooks.sketch.prebuild.3.pattern.windows=cmd.exe /c if exist "{data.dir}" ( xcopy /Y /E "{data.dir}\*" "{build.path}\data\" )
coral_micro_wifi.upload.pattern={cmd.path} --elfloader_path {elfloader.file} --flashloader_path {flashloader.file} --build_dir . --elf_path {build.path}/{build.project_name}.elf --toolchain {build.compiler_path} --arduino --data_dir={build.path}/data {upload.extra_flags}
recipe.hooks.sketch.prebuild.2.pattern.windows=cmd.exe /c if exist "{build.source.path}\data" ( xcopy /Y /E "{build.source.path}\data\*" "{build.path}\data\" )
Comments
Please log in or sign up to comment.
