Automatic Tectum and Aqua Rehash System; (SVECW)

Ozone to the Earth, Automatic tectum and aqua rehash system to the fields.

IntermediateFull instructions provided24 hours7,864
Automatic Tectum and Aqua Rehash System; (SVECW)

Things used in this project

Hardware components

MSPEXP430FR2355
Value line microcontroller
×1
hdc1080evm
humidity and temperature sensor
×1
12v dc motor
To rotate the roof
×2
Dual H-Bridge motor drivers L293D
Texas Instruments Dual H-Bridge motor drivers L293D
×1
12v water pumping motor
×1

Software apps and online services

Code Composer Studio
Texas Instruments Code Composer Studio

Hand tools and fabrication machines

roof

Story

Read more

Custom parts and enclosures


Schematics


Code

Untitled file

Arduino
const int S = A3;
const int cl= A2;
const int LED = 13;
const int motorpin1= 8;
const int motorpin2= 7;
int temp;
void setup() {
  // put your setup code here, to run once:

 pinMode(motorpin1,OUTPUT);
 pinMode(motorpin2,OUTPUT);
 pinMode(LED,OUTPUT);
 pinMode(S,INPUT);
 pinMode(cl,INPUT);
  Serial.begin(9600);
}

void loop() {
  // put your main code here, to run repeatedly:
temp=analogRead(S);
Serial.print("\nanalog read value  ");
Serial.print(temp);
Serial.print(" ");
 if(temp<400)
 {
  Serial.print("wet");
  digitalWrite(LED,LOW);
  digitalWrite(motorpin1,HIGH);
  digitalWrite(motorpin2,HIGH);
 }
  else
  {
    Serial.println("dry");
      digitalWrite(LED,HIGH);
    digitalWrite(motorpin1,LOW);
     digitalWrite(motorpin2,HIGH);

    }
    delay(1000);
  }
