How to Use Buzzer HW-508 with "skiiiD"

Before start, below URL link is a basic tutorial for how to use skiiiD

https://www.hackster.io/skiiid/getting-started-with-skiiid-editor-f69b5d

Video Instruction

Step 1. Launch skiiiD and select Arduino UNO

#1 Launch skiiiD and select New button

#2 Select ①Arduino Uno and then click ②OK button

*This is Tutorial, and we use Arduino UNO. Other boards(Mega, Nano) have the same process.

Step 2. Add Component

#1 Click '+' (Add Component Button) to search and select the component.

#2 ① Type'Buzzer' on the search bar or find theBuzzermodule on the list.

#3②Select Buzzer

#4 then you can see ③ pin indication. (You can configure it.)

*This module has 2 pins to connect

skiiiD Editor automatically indicate pin setting *configuration available

[Default Pin Indication for HW-503 (or KY-006) PassiveBuzzer] in case of Arduino UNO

Signal: 3

NC: NONE (Don't have to connect)

GND: GND

#5 After configuring pins ④ click ADD button on the right below side

#6⑤Added Modulehas appeared on theright panel

skiiiD Code of Passive Buzzer HW-503(or KY-006)

skiiiD Code is intuitive function-based codes. This is based on skiiiD libraries.

on() - Turn on Buzzer ("Notes", Octave, DelayTime)
    Example - ("C",4,200);  = Play C Note  4th octave during 200ms

off() - Turn off Buzzer
examples() - Play a music as an example.
    There are two pre-registered pieces of music. Put 1 or other numbers on the parenthesis.
